TRENDnet TEW-651BR Manual de usuario

The 150Mbps Wireless N Home Router delivers the highest level of

security with 6x the speed and 3x the coverage of wireless g products.

Quickly install the router and use it with TRENDnet wireless n adapters to

receive the full benefits of wireless n speed and coverage.

The latest in wireless encryption and a secure firewall protect your

valuable data. Router setup is fast and intuitive. Wireless Protected

Setup (WPS) integrates other WPS supported wireless adapters at the

touch of a button. Seamlessly stream HD media, download files and surf

online with wireless n speed.

TEW-651BR (V1.0R)

150Mbps Wireless N Home Router

TEW-651BR

rev: 07.16.2010

wireless

Features

SPECIFICATIONS

WAN

Standards

LAN

WPS Button

Connection Type

Supported Web Browsers

• IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX), IEEE 802.11b, IEEE 802.11g, based on IEEE 802.11n technology

• 225g (7.8oz)

• 1 x 10/100Mbps Auto-MDIX WAN port (Internet)

• 4 x 10/100Mbps Auto-MDIX LAN port

• Enables Wi-Fi Protected Setup (WPS) function

• Dynamic IP, Static (fixed) IP, PPPoE, PPTP, L2TP

• MAC Address Filter (20 entries), Domain/URL Filter (40 entries), Protocol/IP Filter (20 entries)

Temperature

Hardware

SPECIFICATIONS

Wireless

Media Access Protocol

• 10% ~ 95% max (non-condensing)

Humidity

• CE, FCC

Certifications

• 802.11g: OFDM with BPSK, QPSK and 16/64-QAM

Module Technique

Weight

• 802.11b: up to 11Mbps

• 802.11g: 15dBm (typical) @ 54Mbps

Frequency

• 1 x 2dBi fixed dipole antenna

• 802.11b: CCK (11 and 5.5Mbps), DQPSK (2Mbps), DBPSK (1Mbps)

• 2.412 ~ 2.484 GHz ISM band

Antenna

• Power, Status, LAN1 - LAN4, WAN, WLAN

Internet Access Control

LED Indicators

• 802.11b: -85dBm (typical) @ 11Mbps

• 64/128-WEP, WPA-PSK/WPA2-PSK, WPA/WPA2-RADIUS

• 802.11n: BPSK, QPSK, 16QAM, 64QAM with OFDM

• 1-11 (FCC), 1-13 (ETSI)

• CSMA/CA with ACK

• 5V DC, 1.2A external power adapter

Power Supply

• 3.5 watts (max)

Power Consumption

• 150 x 110 x 30mm (5.9 x 4.3 x 1.2in)Dimensions (LxWxH)

• Internet Explorer 6.0 or above, Firefox, Safari

* Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending

on interference, network traffic, building materials and other conditions.

TEW-651BR (V1.0R)

150Mbps Wireless N Home Router

Data Rate (Auto Fallback)

Output Power

Receiving Sensitivity

Encryption

Channels

• Operating: 0° ~ 40°C (32° ~ 104°F) • Storage: -10°C ~ 70°C (-14° ~ 158°F)

• 802.11g: up to 54Mbps • 802.11n: up to 150Mbps

• 802.11b: 15dBm (typical) @ 11Mbps • 802.11n: 13dBm (typical) @ 150Mbps

• 802.11g: -68dBm (typical) @ 54Mbps • 802.11n: -62dBm (typical) @ 150Mbps

TEW-651BR

rev: 07.16.2010

• Multi-Language Quick Installation Guide

ORDER INFORMATION

RELATED PRODUCTS

PACKAGE CONTENTS

• TEW-651BR

• CD-ROM (User’s Guide)

TEW-624UB

TEW-638APB

300Mbps Wireless N USB Adapter

300Mbps Wireless N Access Point

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email:

To Order Please Call:

1-888-326-6061

[email protected]

www.trendnet.com

TEW-648UB 150Mbps Mini Wireless N USB Adapter

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

TEW-651BR (V1.0R)

150Mbps Wireless N Home Router

• Cat. 5 Ethernet cable (1.5m / 4.9ft)

• Power adapter (5V DC, 1.5A)

NETWORKING SOLUTIONS

Wireless N Connection

150Mbps Wireless N Home Router

(TEW-651BR)

Notebook with

Mini Wireless N USB Adapter

(TEW-648UB)

150Mbps

Workstation with

Wireless N Access Point

(TEW-638APB)

300Mbps Workstation with 300Mbps

Wireless N USB Adapter

(TEW-624UB)

Cable/DSL

Modem

Internet
