TRENDnet TW100 S4W1CA Manual de usuario

TW100-S4W1CA 4-port Cable/DSL Broadband router provides the

easiest and securest way to share your high-speed Cable/xDSL

Internet connection. It has four 10/100Mbps half/full duplex switch

ports that directly connect to workstations or uplink to another hub or

switch. The TW100-S4W1CA also functions as a firewall for your

PC, protecting your computer from hackers. It allows up to 253 users

to access the Internet using a single ISP account. By sharing just

one TW100-S4W1CA, one IP address, and one Cable/xDSL

modem, dozens of network users can surf the Internet

simultaneously. TRENDnet’s Cable/DSL Modem Internet Station is

a feature-rich product that provides cost-effective functionality and

an easy configuration.

TW100-S4W1CA(G1.0R)

Cable/DSL 4-Port Broadband Router

• Supports Cable/DSL Modem with Dynamic IP, Fixed IP, PPPoE or PPTP Connection Types

• Provides NAT (Network Address Port Translation) Firewall

• Supports Virtual Servers (Port Forwarding) and DMZ

• Supports Client Filtering by Date/Time (10 Entries)and Special Applications Filter (10 Entries)

• Supports MAC Address Control to Allow or Deny Access (32 Entries)

• Supports DNS (Domain Name System) Account for Server Mapping and Dynamic DNS Service

• Supports IPSec and PPTP VPN Pass-Through (when each VPN client connects to a different VPN endpoint)

• Supports UPnP (Universal Plug & Play)

• DHCP Server Supports up to 253 Users

• Easy Web Browser Configuration and Remote Management

• Flash Memory for Firmware Upgrade and Save/Restore Router Configurations

• 5-Year Limited Warranty

• Multiple VPN pass-through sessions for IPSec, L2TP and PPTP

FEATURES

TW100-S4W1CA

rev:01.19.2009

Protocols

LED Indicator

Connection Type

Firewall

VPN

Management

WAN

LAN

Dimensions

Temperature

Power Adapter

Weight

Humidity

Certifications

• IEEE 802.3 10Base-T Ethernet; IEEE 802.3u 100Base-TX Fast Ethernet

• 5V DC, 800mA

• TCP/IP, NAT, PPPoE, UPnP, HTTP, DHCP Server/Client, SNTP

• Ethernet: Cat. 3, 4, 5, UTP EIA/ITA-568 100 Ohms, 100meters max.

• FCC & CE

• 225g (8 oz.)

• 95%(Non-Condensing)

• Dynamic IP, Static (Fixed) IP, PPPoE, PPTP

• NAT, IP / MAC Address Filter, Domain / URL Blocking, Scheduling, UPnP

• 4 x 10/100Mbps Auto-MDIX Ports

• Ethernet : 10Mbps/20Mbps (Half-Duplex/Full-Duplex)

• Fast Ethernet: 100Mbps/200Mbps (Half-Duplex/Full-Duplex)

• Power, WAN, Link/Act, LAN ports

• 0° ~ 55°C ( 32°~ 131°F)

• 154 x 110 x 33mm (6 x 4.3 x 1.3 inches)

• IPSec, PPTP pass-through

• Web Browser Configuration & Remote Management

• 1 x 10/100Mbps Port (Internet)

• Fast Ethernet: Cat. 5, UTP EIA/TIA-568 100 Ohms, 100meters max.

Cabling

Data Transfer Rate

Standards

Hardware

Router

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

Cable/DSL 4-Port Broadband Router

TW100-S4W1CA (G1.0R)

NETWORKING SOLUTIONS

SPECIFICATIONS

4-Port

(TW100-S4W1CA)

Cable/DSL Broadband Router

Workstations with

Fast Ethernet Adapter

(TE100-PCIWN)

Server with

Fast Ethernet Adapter

(TE100-PCIWN)

Cable/DSL

Modem

Internet

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

RELATED PRODUCTS

PACKAGE CONTENTS

TE100-PCBUSR

TE100-P1P

TE100-PCIWN 10/100Mbps PCI Fast Ethernet Adapter

• User’s Guide CD-ROM

10/100Mbps CardBus Ethernet Card

• TW100-S4W1CA

Print Server

• Multi-Language Quick Installation Guide

• RJ-45 Cable (1.5m/5 ft)

• Power Adapter
