TRENDnet TV-IR500 Manual de usuario

TV-IR500

1.01

Quick Installation Guide

Table of Contents

Version 07.29.2009

English 1

1. Before You Start

2. Hardware Installation 2

3. Power-over-Ethernet Installation for TV-IP512P/TV-IP512WN 4

1

Troubleshooting 5

ENGLISH

1. Before You Start

Package Contents

?TV-IR500

*Note:

1. A separate 12V DC power adapter is necessary if the power adapter on your IP

camera is less than 12V (e.g. 5V, 9V)

2. If you are using the TV-IP512P/TV-IP512WN, please verify the hardware

version. The hardware version of the TV-IP512P/TV-IP512WN must be V1.1R

or newer in order to work properly with the IR lens.

3. No splitter is necessary to use the PoE feature of the TV-IP512P. However, if

you would like to use IR lens and PoE feature together, you will need to add a

splitter to provide all necessary power to the IR lens and IP Camera

System Requirements

?IP Camera with CS-Mount type connector (TV-IP512WN, TV-IP512P)

?AC Power Adapter (12V DC)*

?Allen Wrench (1.5mm)

?VGA Resolution: 800 x 600 or above

?Splitter (e.g. TPE-102S)(Optional)*

?PoE Switch (TPE-224WS) (Optional)*

1

ENGLISH

2. Hardware Installation

2

2. Turn the lens counter-clockwise unit to remove

it from the IP Camera.

1. Using an Allen wrench, turn the set screw

counter-clockwise to loosen the lens.

4. Insert the male power plug to the IP camera

and the female power plug to the IP camera's

power adapter.

3. Insert the TV-IR500 into the camera. Turn the

TV-IR500 clockwise to secure the lens.

ENGLISH

6. Log in to your IP camera and adjust the lens as

necessary.

3

5. Plug the power adapter into a power outlet.

7. Using an Allen wrench, turn the set screw

clockwise to tighten the lens.

ENGLISH

4

3. Power-over-Ethernet Installation for TV-IP512P/TV-IP512WN

2. Connect an Ethernet cable from a PoE switch

to the DATA-IN port on the TPE-102S.

1. Select 12V for the voltage.

3. Connect the built-in Ethernet cable on the TPE-

102S to the TV-IP512P/TV-IP512WN's LAN

port.

5. Connect the provided 2.0mm jumper cable to

the female power connector and to the TPE-

102S.

4. Insert the male power plug to the IP camera.

Will this work with the TV-IP201/P/W?

The TV-IR500 is a CS mount type lens, which is compatible with the TV

IP201/P/W. However the TV-IR500 will require a separate 12V DC power source.

The TV-IP201/P/W requires 5V DC power source and will not provide adequate

power for the TV-IR500. You will need to connect the TV-IP201/W/P's power

adapter directly to the IP camera and a separate 12V DC power adapter to the TV-

IR500.

How far will I be able toview video at night?

You will be able to view video up to 10 meters (32.8ft) in a low light environment.

If you still encounter problems or have any questions regarding the TV-IR500, please

contact TRENDnet's Technical Support Department.

Troubleshooting

5

Copyright ©2009. All Rights Reserved. TRENDnet.

Product Warranty Registration

Please take a moment to register your product online.

Go to TRENDnet’s website at http://www.trendnet.com/register
