TRENDnet TE100-S16 - DATA SHEETS Manual de usuario
TE100-S16
TE100-S24
Quick Installation Guide
Table of Contents
Table of Contents
Version 08.08.2006
Deutsch .....................................................................................................
Technical Specifications .............................................................................
Troubleshooting ..........................................................................................
1
2
1
4
6
1. Bevor Sie anfangen ...........................................................................
2. Installation der Hardware ..................................................................
Anwendung
Systemanforderungen
1. Bevor Sie anfangen
Deutsch
1
Packungsinhalt
Kurzanleitung zur Installation
Montagesatz für Gestell
TE100-S16/TE100-S24
Stromkabel
Computer mit korrekt installiertem Netzwerkadapter
Ausreichend kühle und trockene Umgebung
Lassen Sie vor und hinter dem Umschalter mindestens 10 cm
Entlüftungsabstand
Abwesenheit von starken Quellen elektromagnetischer Felder (wie
Motoren), Vibrationen, Staub und direkter Sonneneinstrahlung
19-Zoll-Gestell nach EIA-Standard oder feste, ebene Oberfläche, die das
Gewicht des Umschalters tragen kann
16/24 Ports 10/100Mbps Fast Ethernet Switch
(TE100-S16 or TE100-S24)
10/100Mbps Multi-Port
Print Server
(TE100-P21)
Printers
Cable/DSL
Modem Router
Workstations with PCI Adapter
(TE100-PCIWN)
Laptop with PC Card
(TE100-PCBUSR)
Server with PCI Adapter
(TE100-PCIWA)
Internet
2. Installation der Hardware
Deutsch
2
1. Schließen Sie das Stromkabel an
der Rückseite des TE100-S16/
TE100-S24 an und stecken
Sie es in eine Steckdose.
2. Verbinden Sie den Computer über
ein Kat.5 RJ-45-Netzwerkkabel mit
einem freien Ethernet-Port des
TE100-S16/TE100-S24.
3. Bringen Sie die Befestigungsbügel
mit den mitgelieferten Schrauben
an beiden Seiten des Umschalters
an.
4. Setzen Sie den Umschalter
sorgfältig in das Gestell ein.
Richten Sie den Bügel an den
Schraubenlöchern im Gestell aus
und befestigen Sie den Umschalter
mit den zum Gestell gehörenden
Schrauben.
Der Umschalter lässt sich in ein standardmäßiges 19-Zoll EIA-Gestell
einbauen, das seinerseits gemeinsam mit anderen Geräten in einen
Kabelschrank montiert werden kann.
Deutsch
3
Montage in Gestell
4
Standards
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3x Full-Duplex Flow Control
Protocol CSMA/CD
Data Transfer Rates
Ethernet:
10Mbps (Half-Duplex), 20Mbps (Full-Duplex)
Fast Ethernet:
100Mbps (Half-Duplex), 200Mbps (Full-Duplex)
Network Cables Ethernet: UTP/STP CAT-3, 4, 5
Fast Ethernet: UTP/STP CAT-5, 5E, 6
Number of Ports 16 or 24 x 10/100Mbps Auto-negotiation,
Auto-MDIX
General
Topology Star
Technical Specifications
Transmission Method
MAC Address Learning
Store-and-forward
Self-learning, Auto-aging
Switching Capacity
RAM Buffer
TE100-S16 : 3.2Gbps
TE100-S24 : 4.8Gbps
TE100-S16: 512Kbits per device
TE100-S24: 2.5Mbits per device
Packet Filtering/
Forwarding Rate
Filtering Address Table
Ethernet: 14,880pps (packet per second)
Fast Ethernet: 148,800pps (packet per second)
8K entries per device
Performance
5
Power 100-240VAC. 50/60Hz. Internal Power Supply
Power Consumption TE100-S16: 6W (Max)
TE100-S24: 10W (Max)
Temperature Operating: 0 ~ 40 C, Storage: -10 ~ 70 C° ° ° °
Dimensions (L x W x H) 440 x 140 x 44 mm
Weight 2kg
Physical and Environmental
Humidity
Certification
Operating: 10% ~ 90%, Storage:5% ~ 90%
FCC, CE
6
Troubleshooting
Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
After connecting the Switch to a power outlet, the LEDs do not turn on.
Check the connection of the external power adapter to the TE100-S16/
TE100-S24 and the power outlet. Also check that the power outlet is receiving
power.
When I connect a computer to the Switch's port, the LINK/ACT LED turns on,
but the 100Mbps LED remains off.
When the 100Mbps LED remains off, the computer's connection speed is
10Mbps.
After I connect my PCs to the Switch, I am unable to share files.
First, check the LEDs on the Switch. Make sure the LINK/ACT LED is on.
Second, check the network cable. The minimum length of the cable is 1.5 meters
and the maximum length of the cable is 100 meters. Third, disable any software
firewall program. Fourth, verify that you have file sharing enabled. Please contact
your operating system provider for more information.
After I connect my PCs to the Switch, I can only get onto the Internet from one
computer.
The Switch was not designed to share Internet between multiple computers.
You need to install an Internet router such as the TRENDnet TW100-S4W1CA.
If you still encounter problems or have any questions regarding the TE100-S16/
TE100-S24 please contact TRENDnet's Technical Support Department.
Limited Warranty
- 5-Year Warranty
TRENDnet warrants its products against defects in material and workmanship, under
normal use and service, for the following lengths of time from the date of purchase.
TE100-S16/TE100-S24
If a product does not operate as warranted above during the applicable warranty period,
TRENDnet shall, at its option and expense, repair the defective product or deliver to
customer an equivalent product to replace the defective item. All products that are
replaced will become the property of TRENDnet. Replacement products may be new or
reconditioned.
TRENDnet shall not be responsible for any software, firmware, information, or memory
data of customer contained in, stored on, or integrated with any products returned to
TRENDnet pursuant to any warranty.
There are no user serviceable parts inside the product. Do not remove or attempt to
service the product through any unauthorized service center. This warranty is voided if
(i) the product has been modified or repaired by any unauthorized service center, (ii) the
product was subject to accident, abuse, or improper use (iii) the product was subject to
conditions more severe than those specified in the manual.
Warranty service may be obtained by contacting TRENDnet office within the applicable
warranty period for a Return Material Authorization (RMA) number, accompanied by a
copy of the dated proof of the purchase. Products returned to TRENDnet must be pre-
authorized by TRENDnet with RMA number marked on the outside of the package, and
sent prepaid, insured and packaged appropriately for safe shipment.
7
WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE
AS WARRANTED ABOVE, THE CUSTOMER’S SOLE REMEDY SHALL BE, AT
TRENDNET’S OPTION, REPAIR OR REPLACEMENT. THE FOREGOING
WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER
WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF
LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. TRENDNET
NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT
ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION,
MAINTENANCE OR USE OF TRENDNET’S PRODUCTS.
TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND
EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES
NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S
MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED
ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE BEYOND THE
RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER
HAZARD.
LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET
ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER
BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL,
CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND,
OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE,
PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY OF SUCH
DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND
OF THE PURCHASE PRICE PAID, AT TRENDNET’S OPTION. THIS DISCLAIMER OF
LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED
HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.
Governing Law: This Limited Warranty shall be governed by the laws of the state of
California.
Note: AC/DC Power Adapter, Cooling Fan, and Power Supply carry 1-Year Warranty
8
