TRENDnet TBW-104UB Manual de usuario

TBW-104UB

Quick Installation Guide

Table of Contents

(Version 03.21.2007)

English ......................................................................................................

Troubleshooting .........................................................................................

1. Before You Start

2. How to Install .....................................................................................

3. Configuring the Bluetooth Adapter ....................................................

................................................................................

System Requirements

1. Before You Start

English

Package Contents

TBW-104UB

Quick Installation Guide

Utility& Driver CD-ROM

CD-ROM drive

Computer With An Available USB 1.1 or 2.0 Port

CPU: Pentium 300MHz or Above

Memory: 256 MB or Above

Hard Drive Space: 50MB or Above

Windows 2000/XP/Vista

Application

Note: Do not insert the TBW-104UB USB adapter until instructed to do so.

2. How to Install

English

1. Insert the Utility & Driver

CD-ROM into your CD-ROM drive

and click Install Utility.

2. Select Language from the drop

down menu. Click OK

4. Select I accept the terms in the

license agreement. Click Next

3. Click Next.

5. Follow the InstallShield Wizard

instructions and then click Finish.

6. Click Yes to restart the computer.

(Windows 2000 only)

7. Connect the TBW-104UB into the

computer's USB port.

English

Drivers for Window Vista and 2000 will install automatically. Proceed to

section 3. For Windows XP, continue on to step 8.

English

10. Click Finish.

Your installation is now complete.

For detailed information regarding the TBW-104UB configuration and

advanced settings, please refer to the User's Guide included on the Utility &

Driver CD-ROM or TRENDnet's website at www.trendnet.com

8. Select No, not this time and then

click Next.

9. Select Install the software

automatically (Recommended)

and then click Next.

Windows XP

English

3. Configuring the Bluetooth Adapter

1. Double-click the Bluetooth icon on

your system tray.

4. Right click on your Bluetooth

device and select Pair Device.

5. Type in a Passkey (for example:

0000. Please consult your

Bluetooth device's manual for more

information) and then click OK.

Then put in the same Passkey on

your Bluetooth device.

3. Go to View -> Refresh Devices.

Note: Make sure your Bluetooth device is powered on and in pairing mode.

2. Click OK.

6. Double left-click on your Bluetooth

device to show the available

services.

Your configuration is now complete.

For detailed information regarding the TBW-104UB configuration and

advanced settings, please refer to the User's Guide included on the Utility &

Driver CD-ROM or TRENDnet's website at www.trendnet.com

English

To ensure the highest level of customer service and support, please take a moment to

Thank you for choosing TRENDnet

Q1:

A1:

Q2:

A2:

Q3:

A3:

Q4:

A4:

Windows is unable to recognize my hardware. What should I do?

First, make sure your computer meets the minimum requirements as specified

in Section 1 of this quick installation guide. Second, you must install the Bluetooth utility

BEFORE you physically install your Bluetooth Adapter. Third, plug the adapter into a

different USB slot.

The Bluetooth software is unable to detect my Bluetooth-enabled device. What should I

do?

First, disable any software firewall programs such as ZoneAlarm or Norton Internet

Security. If your have Windows XP/Vista installed on your computer, make sure to disable

the built-in firewall. Second, make sure Bluetooth enabled device is powered on.

I cannot pair my Bluetooth enabled device to the TBW-104UB USB Adapter. What

should I do?

First, make sure that Bluetooth device is powered on. Second, make sure that your

Bluetooth enabled device is in pairing mode. Third, make sure to put in the same Passkey

on both devices.

I am not receiving 3Mbps data rate through the adapter. What should I do?

In order to get the full data rate, your Bluetooth device must support Bluetooth v2.0 with

Enhanced Data Rate (EDR).

If you still encounter problems or have any questions regarding the TBW-104UB, please refer to

the User's Guide included on the Utility & Driver CD-ROM or contact TRENDnet's Technical

Support Department.

Troubleshooting

Certifications

This equipment has been tested and found to comply with FCC and CE Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received. Including interference that may

cause undesired operation.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV

INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS

EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO

OPERATE THE EQUIPMENT.

Waste electrical and electronic products must not

be disposed of with household waste. Please

recycle where facilities exist. Check with you Local

Authority or Retailer for recycling advice.

ADVERTENCIA

En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de

alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al

mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador

de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria

existente en el pais o zona de instalación.
