TRENDnet TPL-102E Manual de usuario

TRENDnet

TRENDware, USA

What's Next in Networking

The Powerline 10/100 Mbps Ethernet Bridge transforms existing power lines in your home or

small office into a high-speed network solution. The Powerline Ethernet bridge meets Home

Plug 1.0.1 compatibility, ensures privacy through 56-bit Data Encryption, and supports data

rates of up to 14Mbps. Included software measures data performance and enhances

network security.

TPL-102E

Powerline 10/100Mbps Ethernet Bridge

FEATURES

TPL-102E (08.03.05)

• Up to 14Mbps High-Speed Data Transfer Rate over Powerlines

• Allows Concurrent Shared Internet Access across existing Electrical Outlets

• Supports up to 12 Clients per Network

• Fully HomePlug 1.0.1 Compliant

• Supports 56-bit Data Encryption Security

• Compatible with Windows 98(SE), ME, 2000 and XP

• Connect to a Network using Existing Powerlines with Wall-Plugged design

• Range of up to 300 Meters (depends on the environment)

• Supports Plug & Play and Easy Installation

• 3-Year Warranty

POWERLINE

SPECIFICATIONS

TPL-102E

Powerline 10/100Mbps Ethernet Bridge

TRENDnet is a registered trademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit ____________________

http://www.TRENDNET.com.

RELATED PRODUCTS

PACKAGE CONTENTS

TPL-101U

TPL-110AP

TPL-111BR

• Powerline USB Adapter

• 125Mbps 802.11g Wireless Powerline Access Point

• 125Mbps 802.11g Wireless Powerline Router

• TPL-102E

NETWORKING SOLUTIONS

To Order Please Call:

1-888-326-6061

ORDERING INFORMATION

TRENDware International, Inc.

3135 Kashiwa Street,Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com

• Quick Installation Guide

• Utility CD-ROM

Outlet

Notebook with

Wireless PC Card

(TEW-421PC)

Workstation with

Wireless PCI Adapter

(TEW-423PI)

Cable/DSL

Modem

Internet

Outlet

Powerline 10/100Mbps

Ethernet Bridge

(TPL-102E)

Cat.5 Cable

Workstation with

Fast Ethernet PCI Adapter

(TE100-PCIWN)

Powerline 10/100Mbps

Ethernet Bridge

(TPL-102E)

Powerline

USB Cable

Cat.5 Cable

54Mbps

Powerline

Cat.5 Cable

Powerline Powerline

125Mbps 802.11g

Wireless Powerline Router

(TPL-111BR)

Outlet

Powerline USB Adapter

(TPL-101U)

Workstation

USB Cable

Standards

Frequency Band

Interface

Access Method

Modulation

Speed

OS Compliant

LED

Nodes

Dimension (L x W X H)

Encryption

Weight

• IEEE 802.3, IEEE 802.3U HomePlug 1.0.1

• 10/100Mbps Auto-MDIX RJ45 Port Power Prongs

• 4.3 ~ 20.9 MHz

• CSMA/CA

• OFDM

• Powerline: Up to 14Mbps

• RJ45: 10/100Mbps

• Windows 98SE/ME/2000/XP

• Power, Link, Activity, Collision

• Up to 12 client notes

• 68 x 43 x 95 mm (2.7 x 1.7 x 3.7 inches)

• 56-bit DES with key management

• 113g (4 oz.)

Hardware

Power Source

Temperature

Certifications

Operating Humidity

• 100~240VAC, 50/60 Hz

• 0° ~ 70° C (32° ~ 158° F)

• 0% to 90% (Non-Condensing)

• FCC, CE, HomePlug 1.0.1
