TP-Link Tapo S220 Manual de usuario

User Guide

Smart Light Switch 2 Gang 1 Way

Tapo S220

Contents

About This Guide ···········································································1

Introduction ······················································································2

Appearance ······················································································3

Set Up Your Switch ·······································································4

Main Device Controls··································································6

Schedule ····························································································8

Away Mode····················································································· 10

Timer·································································································· 12

Check Runtime·············································································14

Device Sharing·············································································15

Smart Actions···············································································16

Device Settings ··········································································· 21

How to Reset Your Switch······················································22

Authentication·············································································· 24

About This Guide

This guide provides a brief introduction to the Smart Light Switch 2 Gang 1 Way and the Tapo app, as well as regulatory information.

Please note that features available in Tapo may vary by model and software version. Tapo availability may also vary by region. All images, steps, and

descriptions in this guide are only examples and may not reect your actual Tapo experience.

Conventions

In this guide, the following convention is used:

Convention Description

Blue Key information appears in teal, including management page text such as menus, items, buttons and so on.

Underline Hyperlinks are in teal and underlined. You can click to redirect to a website.

Note: Ignoring this type of note might result in a malfunction or damage to the device.

More Info

• Specications can be found on the product page at https://www.tapo.com.

• Our Technical Support and troubleshooting information can be found at https://www.tapo.com/support/.

• The switch installation and setup video can be found at https://www.tp-link.com/support/download/tapo-s220/.

• The installation guide can be found at https://www.tp-link.com/support/faq/3359/.

Introduction

Make your traditional lighting smart with the Tapo Smart Switch. Turn your lights on and o with your voice, or control them from your phone. Thanks to

the switch's battery-powered design with 1+ year battery life, enjoy the smart lifestyle without rewiring your home or replacing your current bulbs.

The Tapo smart switch works with an IoT hub. Make sure you have set up your hub rst.

Remote Control Voice ControlSchedule & Timer Tool-Free Battery

Replacement

No Neutral

Required

Low-Battery

Reminder

• Remote Control – Instantly turn the light on/o wherever you are through the Tapo app.

• Schedule – Set a schedule to turn on the lights for you in advance.

• Timer – Set a countdown timer to turn o the lights after sleeping.

• Voice Control – Manage your lights with voice commands via Amazon Alexa or the Google Assistant.

• Low Battery Reminder – Send notications when the battery power is low.

• No Neutral Wire Required – Super easy wiring. No neutral wire required. No rewiring required.

• Tool-Free Battery Replacement – Easily replace batteries after installation, no need of other tools.

Appearance

Control the light connected to this button.

Right Button

Control the light connected to this button.

Left Button

Blinking red quickly:

Enter pairing mode.

LED

Solid red for 5s:

Pairing is completed.

Low battery.

Blinking 3 times when

pressing the switch: Press and hold for 5s:

SYNC/RESET button

Reset the switch and enter

pairing mode.

Set Up Your Switch

Tapo Smart Light Switch works with an IoT hub. You need to set up your hub rst, then add your switch to the app. Follow the steps below to get started

with your Tapo Smart Light Switch.

Step 1. Download Tapo App

Get the Tapo app from the App Store or

Google Play, or by scanning the QR code

below.

Step 2. Log In

Open the app, and log in with your TP-Link ID.

If you don't have an account, create one rst.

Step 3. Add Hub First

Tap the button in the app and select your

hub. Then follow app instructions to set up

your hub.

Step 4. Add Your Switch

Tap the button in the app and select your

switch. Then follow app instructions to set up

your switch.

Step 5. Wire Your Switch

Follow app instructions to wire your switch, or check the wiring diagram below.

Please make sure no bare wires are exposed after wiring. The recommended wire stripping length

is 7-8.5 mm.

The hot / line wire is usually connected to the terminal “C” or “L”

of your dumb switch.

If the dumb switch is connected with a Neutral wire,

cover it with the provided wire nut.

Lin Lout1 Lout2

Hot / Line

Lout1

Lout1 = Right Button

Lout2

Lout2 = Left Button

Lin

Home Page

This page lists all your devices you've added and you can view them

directly and manage them easily. Tap either button of your switch to

enter the Live View page.

Main Device Controls

After you successfully set up the switch, you will see the buttons of your switch listed on the home page. You can manage them separately from

anywhere at any time with the Tapo app.

Staus Page

You can turn on or o your device in this page. You can also congure

advanced features like Schedule, Away Mode, Timer to control your device

according to your daily rountine.

Switch Settings

On Status page, tap to enter the Device Settings page. You can

change your device name and icon, set Delayed Shut O, etc.

Step 1: Go to Status page and swipe upforward. Tap to set a

schedule.

Step 2: Tap on the top right corner.

Schedule

Set schedules for your switch to automatically turn on/o at set times to simplify your daily routine.
