TP-Link T2500G-10MPS Manual de usuario

Business Networking Solution

Installation Guide

JetStream Gigabit L2 Managed Switch

T2500G-10TS (TL-SG3210)

T2500G-10MPS

Related Document

Contents

Chapter 1 Introduction ——————————— 01

1.1 Product Overview......................................................01

1.2 Appearance .................................................................01

Chapter 2 Installation———————————— 07

2.1 Package Contents.....................................................07

2.2 Safety Precautions....................................................07

2.3 Installation Tools ........................................................09

2.4 Product Installation...................................................09

Chapter 3 Lightning Protection ——————— 11

3.1 Cabling Reasonably ..................................................11

3.2 Connect to Ground ..................................................13

Chapter 4 Connection ——————————— 16

4.1 Ethernet Port...............................................................16

4.2 SFP Port ........................................................................16

4.3 Console Port................................................................16

4.4 Verify Installation .......................................................17

4.5 Power On .....................................................................18

4.6 Initialization ..................................................................18

Chapter 5 Conguration —————————— 19

5.1 Congure the Switch via GUI.................................19

5.2 Congure the Switch Using CLI ...........................20

Appendix A Troubleshooting ———————— 23

Appendix B Hardware Specications ————— 25

Gigabit L2 Managed Switch

Introduction

Chapter 1 Introduction

1.1 Product Overview

TP-Link JetStream Gigabit L2 Managed Switch, designed for workgroups and

departments, provides wire-speed performance and abundant layer 2 management

features. It provides a variety of service features and multiple powerful functions

with high security.

The EIA-standardized framework and smart configuration capacity can provide

flexible solutions for a variable scale of networks. ACL, 802.1x and Dynamic ARP

Inspection provide robust security strategies. QoS and IGMP snooping/filtering

optimize voice and video application. Link aggregation (LACP) increases aggregated

bandwidth, optimizing the transport of business critical data. SNMP, RMON, WEB

and CLI Log-in bring abundant management policies. TP-Link JetStream Gigabit L2

Managed Switch integrates multiple functions with excellent performance, and is

friendly to manage, which can fully meet the need of the users demanding higher

networking performance.

T2500G-10MPS L2 Managed PoE+ Switch is also a Power Sourcing Equipment (PSE*).

All the RJ45 ports on the switch support Power over Ethernet (PoE*) function, which

can automatically detect and supply power with those powered devices (PDs*)

complying with IEEE 802.3af and IEEE 802.3at.

*PSE: a device (switch or hub for instance) that provides power through an Ethernet

cable.

*PoE: This technology describes a system to transmit electrical power, along with

data, to remote devices over standard twisted-pair cable in an Ethernet.

*PD: a device powered by a PSE and thus consumes energy. Examples include

powering network cameras, wireless LAN access points, IP telephones, network

hubs, embedded computers etc.

1.2 Appearance

■Front Panel

The front panel of T2500G-10TS is shown as the following figure.

Figure 1-1 Front Panel of T2500G-10TS

LEDs

Console Port (USB)

SFP Port

10/100/1000Mbps RJ45 Port

Console Port (RJ-45)

Gigabit L2 Managed Switch

Introduction

LEDs

LED Status Indication

PWR

On The switch is powered on

Off The switch is powered off or power supply is

abnormal

Flashing Power supply is abnormal

SYS Flashing The switch works properly

On/Off The switch works improperly

10/100/1000M

Green A 1000Mbps device is linked to the corresponding

port, but no activity

Yellow A 10/100Mbps device is linked to the corresponding

port, but no activity

Flashing Data is being transmitted or received

Off Not linked

SFP1, SFP2

On A 1000Mbps device is linked to the corresponding

port, but no activity

Flashing Data is being transmitted or received

Off Not linked

Console (RJ-45) Port

Designed to connect with the serial port of a computer or terminal for monitoring

and configuring the switch.

Console (USB) Port

Designed to connect with the USB port of a computer for monitoring and

configuring the switch. The switch has an RJ-45 console port and a micro-USB

console port available. Console input is active on only one console port at a

time. By default, the micro-USB connector takes precedence over the RJ-45

connector.

10/100/1000Mbps RJ45 Port

Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps

or 1000Mbps. Each 10/100/1000Mbps RJ45 port has a corresponding

10/100/1000M LED.

SFP Port

Designed to install the SFP module. T2500G-10TS features 2 individual SFP ports

and supports 1000M SFP module connection only.

Gigabit L2 Managed Switch

Introduction

The front panel of T2500G-10MPS is shown as the following figure.

Figure 1-2 Front Panel of T2500G-10MPS

LEDs

Console Port (USB)

SFP Port

10/100/1000Mbps RJ45 Port

Console Port (RJ-45)

LED Mode Switch Button

LEDs

T250 0 G -10 M PS has an LED mode switch button which is for switching the LED

status indication. When the Speed LED is on, the port LED is indicating the data

transmission status. When the PoE LED is on, the port LED is indicating the power

supply status. By default, the Speed LED is on. Pressing the mode switch button,

the Speed LED will turn off and the PoE LED will light up. Then the PoE LED will

turn off after being on for 60 seconds and the Speed LED will light up again.

When the Speed LED is on, the port LED is indicating the data transmission

status.

LED Status Indication

PWR

On The switch is powered on

Off The switch is powered off or power supply is

abnormal

Flashing Power supply is abnormal

SYS Flashing The switch works properly

On/Off The switch works improperly

FAN

Green All the fans work properly

Yellow Not all the fans work properly

Off The switch works improperly

PoE MAX

On The remaining PoE power≤7W

Flashing The remaining PoE power keeps ≤7W after this

LED is on for 2 minutes

Off The remaining PoE power>7W

Speed or PoE

Green On A 1000Mbps device is connected to the

corresponding port, but no activity

Flashing Data is being transmitted or received

Yellow On A 10/100Mbps device is connected to the

corresponding port, but no activity

Flashing Data is being transmitted or received

Off No device is connected to the corresponding port

Gigabit L2 Managed Switch

Introduction

LED Status Indication

SFP1, SFP2

Green On A 1000Mbps device is connected to the

corresponding port, but no activity

Flashing Data is being transmitted or received

Yellow On A 100Mbps device is connected to the

corresponding port, but no activity

Flashing Data is being transmitted or received

Off No device is connected to the corresponding port

When the PoE LED is on, the port LED is indicating the power supply status.

LED Status Indication

PWR

On The switch is powered on

Off The switch is powered off or power supply is

abnormal

Flashing Power supply is abnormal

SYS Flashing The switch works properly

On/Off The switch works improperly

FAN

Green All the fans work properly

Yellow Not all the fans work properly

Off The switch works improperly

PoE MAX

On The remaining PoE power≤7W

Flashing The remaining PoE power keeps ≤7W after this

LED is on for 2 minutes

Off The remaining PoE power>7W

Speed or PoE

Green

On The port is supplying power normally

Flashing The supply power exceeds the corresponding

port's maximum power

Yellow On Overload or short circuit is detected

Flashing Power-on self-test has failed

Off No PoE power supply is provided on the port

SFP1, SFP2

Green On A 1000Mbps device is connected to the

corresponding port, but no activity

Flashing Data is being transmitted or received

Yellow On A 100Mbps device is connected to the

corresponding port, but no activity

Flashing Data is being transmitted or received

Off No device is connected to the corresponding port

Console (RJ-45) Port

Designed to connect with the serial port of a computer or terminal for monitoring

and configuring the switch.

Console (USB) Port

Designed to connect with the USB port of a computer for monitoring and

configuring the switch. The switch has an RJ-45 console port and a micro-USB

console port available. Console input is active on only one console port at a

time. By default, the micro-USB connector takes precedence over the RJ-45

connector.

Gigabit L2 Managed Switch

Introduction

10/100/1000Mbps RJ45 Port and PoE Port

Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or

1000Mbps. Each has a corresponding Speed or PoE LED.

SFP Port

Designed to install the SFP module. T2500G-10 MP S features 2 SFP transceiver

ports.

■Rear Panel

The rear panel of T2500G-10TS is shown as the following figure.

Figure 1-3 Rear Panel of T2500G-10TS

Grounding Terminal

Power Socket

Kensington Security Slot

Secure the lock (not provided) into the security slot to prevent the device from

being stolen.

Grounding Terminal

The switch already comes with lightning protection mechanism. You can also

ground the switch through the PE (Protecting Earth) cable of AC cord or with

Ground Cable. For detailed information, please refer to Chapter 3 Lightning

Protection.

Power Socket

Connect the female connector of the power cord here, and the male connector to

the AC power outlet. Please make sure the voltage of the power supply meets the

requirement of the input voltage (100-240V~ 50/60Hz).

The rear panel of T2500G-10MPS is shown as the following figure.

Figure 1-4 Rear Panel of T2500G-10MPS

Power Socket

Grounding Terminal

Kensington Security Slot

Secure the lock (not provided) into the security slot to prevent the device from

being stolen.

Gigabit L2 Managed Switch

Introduction

Grounding Terminal

The switch already comes with lightning protection mechanism. You can also

ground the switch through the PE (Protecting Earth) cable of AC cord or with

Ground Cable. For detailed information, please refer to Chapter 3 Lightning

Protection.

Power Socket

Connect the female connector of the power cord here, and the male connector to

the AC power outlet. Please make sure the voltage of the power supply meets the

requirement of the input voltage (100-240V~ 50/60Hz).

Caution: Please use the provided power cord.

Otros manuales para T2500G-10MPS

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de TP-Link

TP-Link

TP-Link JetStream T1500G-10MPS Manual de usuario

TP-Link

TP-Link JetStream TL-SG2008 Manual de usuario

TP-Link

TP-Link KS205 Manual de usuario

TP-Link

TP-Link Tapo S500D Manual de usuario

TP-Link

TP-Link TL-SG105 Manual de instrucciones de instalación

TP-Link

TP-Link JetStream TL-SL3452 Manual de usuario

TP-Link

TP-Link TL-SG605E Manual de usuario

TP-Link

TP-Link JetStream TL-SL5428E Manual de usuario

TP-Link

TP-Link TL-SG1048 Manual de usuario

TP-Link

TP-Link HS200 Manual de usuario

TP-Link

TP-Link LiteWave LS1005G Manual de usuario

TP-Link

TP-Link JetStream T1500G-10MPS Manual de usuario

TP-Link

TP-Link TL-SG1008MP Manual de usuario

TP-Link

TP-Link TL-SL2428 Manual de usuario

TP-Link

TP-Link TL-SG2452 Manual de usuario

TP-Link

TP-Link TL-SF1008P Manual de usuario

TP-Link

TP-Link TL-SG108PE Manual de usuario

TP-Link

TP-Link TL-SF1008D - 10/100M FAST ETHERNET SWITCH Manual de usuario

TP-Link

TP-Link JetStream TL-SG3424 Manual de usuario

TP-Link

TP-Link TL-SG2200 Manual de usuario

TP-Link

TP-Link TL-SG108PE Manual de usuario

TP-Link

TP-Link TL-SG2424 Manual de usuario

TP-Link

TP-Link JetStream TL-SL3428 Manual de instrucciones

TP-Link

TP-Link Tapo S500 Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
