TP-Link JetStream T1500G-8T Manual de instrucciones de instalación

Wall Mounting Guide

Wall Mountable Switches

1.1 Wall Mounting Preparation

Before mounting the switch, you need to prepare the tools below:

ǴA screw driver.

ǴTwo screws which complies to the corresponding standard. For details, see Wall

Mounting Specification.

1.2 Wall Mounting Procedure

On the bottom of the panel, there are two mounting holes. You need to drive two screws

into the wall, then mount the switch on the wall. Note that the switch should be mounted

on the wall upright rather than sideways. For TL-SF1008P/TL-SF1008LP/TL-SF1009P/

TL-SG1008P, the switch should be mounted with the ports facing downward and the

LEDs facing upward.

1) Determine the location on the wall where you want to mount the switch.

2) Mark the wall where the two mounting holes are. The distance between the two marks

must be the same as that between the two mounting holes of the switch. For the wall-

mounting-holes distance, see Wall Mounting Specification.

3) Drive the screws into the wall at the marks using the screw driver. For the Screw-

Head-to-Wall Minimum Distance, see Wall Mounting Specification.

4) Mount the switch on the wall.

1.3 Wall Mounting Specification

Model

Screw Standard of

ANSI B1.1

Minimum Length

of Screw

Screw-Head-to-Wall

Minimum Distance

Wall-Mounting-Holes

Distance

DS105G 4#, (5#), 6#, 8# 7.5mm 1.5mm 39mm

DS105GE 4#, (5#), 6# 7.5mm 1.5mm 52mm

DS105G-M2 4#, (5#), 6# 7.5mm 1.5mm 52mm

DS105GP 4#, (5#), 6#, 8# 8.5mm 1.5mm 39mm

DS105X 4#, (5#), 6# 7.5mm 1.5mm 150mm

DS106GPP 4#, (5#), 6#, 8# 8.5mm 1.5mm 94mm

DS106P 4#, (5#), 6#, 8# 8.5mm 1.5mm 94mm

DS108G 4#, (5#), 6#, 8# 7.5mm 1.5mm 94mm

DS108GE 4#, (5#), 6# 7.5mm 1.5mm 110mm

DS108G-M2 4#, (5#), 6# 7.5mm 1.5mm 110mm

DS108GP 4#, (5#), 6#, 8# 8.5mm 1.5mm 94mm

DS110GMP 4#, (5#), 6# 8.5mm 1.5mm 150mm

Model Screw Standard of

ANSI B1.1

Minimum Length

of Screw

Screw-Head-to-Wall

Minimum Distance

Wall-Mounting-Holes

Distance

D S111P 4#, (5#), 6# 8.5mm 1.5mm 150mm

D S116 G E 4#, (5#), 6# 8.5mm 1.5mm 200mm

ES205G 4#, (5#), 6# 11m m 4.5mm 52mm

ES205GP 4# 10mm 4.5mm 39mm

ES210GP 4#, (5#), 6# 8.5mm 1.5mm 150mm

LS10 05G 4#, (5#), 6# 8.5mm 2.5mm 38mm

LS10 08G 4#, (5#), 6# 8.5mm 2.5mm 48mm

LS105G 4#, (5#), 6# 7.5mm 1.5mm 76mm

LS105GP 4#, (5#), 6# 7.5mm 1.5mm 65mm

LS105LP 4#, (5#), 6#, 8# 8.5mm 1.5mm 39mm

LS106LP 4#, (5#), 6#, 8# 8.5mm 1.5mm 94mm

LS10 8G 4#, (5#), 6# 7.5mm 1.5mm 65mm

LS10 8GP 4#, (5#), 6# 7.5mm 1.5mm 65mm

LS10 9P 4#, (5#), 6#, 8# 8.5mm 1.5mm 105mm

LS1210 GP 4#, (5#), 6# 7.5mm 1.5mm 150mm

S4500-16GP 4#, (5#), 6# 8.5mm 1.5mm 200mm

S4500-8G 4#, (5#), 6# 8.5mm 1.5mm 150mm

S4500-8GP 4#, (5#), 6# 8.5mm 1.5mm 150mm

S4500-8GP2F 4#, (5#), 6# 8.5mm 1.5mm 150mm

SG2008 4#, (5#), 6# 8.5mm 1.5mm 150mm

SG2008P 4#, (5#), 6# 8.5mm 1.5mm 150mm

SG2016P 4#, (5#), 6# 8.5mm 1.5mm 200mm

SG2210P 4#, (5#), 6# 8.5mm 1.5mm 150mm

SG2210XMP-M2 4#, (5#), 6# 8.5mm 1.5mm 150mm

T1500G-8T 4#, (5#), 6# 8.5mm 1.5mm 150mm

TL-RP108GE 4#, (5#), 6# 8.5mm 1.5mm 65mm

TL-SF1005LP 4#, (5#), 6#, 8# 8.5mm 1.5mm 39mm

TL-SF1005P 4#, (5#), 6#, 8# 8.5mm 1.5mm 39mm

TL-SF1006P 4#, (5#), 6#, 8# 8.5mm 1.5mm 94mm

TL-SF1008LP 4#, (5#), 6#, 8# 8.5mm 1.5mm 105mm

TL-SF1008P 4#, (5#), 6#, 8# 8.5mm 1.5mm 105mm

Model Screw Standard of

ANSI B1.1

Minimum Length

of Screw

Screw-Head-to-Wall

Minimum Distance

Wall-Mounting-Holes

Distance

TL-SF1009P 4#, (5#), 6#, 8# 8.5mm 1.5mm 105mm

TL-SF1016D 4#, (5#), 6# 9mm 3mm 157.2mm

TL-SG1005D 4# 10mm 4.5mm 60mm

TL-SG1005LP 4#, (5#), 6#, 8# 8.5mm 1.5mm 39mm

TL-SG1005P 4#, (5#), 6#, 8# 8.5mm 1.5mm 39mm

TL-SG1005P-PD 4#, (5#), 6#, 8# 8.5mm 1.5mm 94mm

TL-SG1006PP 4#, (5#), 6#, 8# 8.5mm 1.5mm 94mm

TL-SG1008D 4# 10mm 4mm 100mm

TL-SG1008P 4#, (5#), 6#, 8# 8.5mm 1.5mm 105mm

TL-SG105 4#, (5#), 6#, 8# 7.5mm 1.5mm 39mm

TL-SG105E 4#, (5#), 6# 7.5mm 1.5mm 52mm

TL-SG105-M2 4#, (5#), 6# 7.5mm 1.5mm 150mm

TL-SG105MPE 4#, (5#), 6#, 8# 8.5mm 1.5mm 39mm

TL-SG105PE 4#, (5#), 6#, 8# 7.5mm 1.5mm 39mm

TL-SG105PP-M2 4#, (5#), 6# 7.5mm 1.5mm 150mm

TL-SG105S 4#, (5#), 6#, 8# 7.5mm 1.5mm 39mm

TL-SG105S-M2 4#, (5#), 6# 7.5mm 1.5mm 52mm

TL-SG108 4#, (5#), 6#, 8# 8.5mm 1.5mm 94mm

TL-SG108E 4#, (5#), 6# 7.5mm 1.5mm 110mm

TL-SG108-M2 4#, (5#), 6# 7.5mm 1.5mm 150mm

TL-SG108PE 4#, (5#), 6#, 8# 8.5mm 1.5mm 94mm

TL-SG108S 4#, (5#), 6#, 8# 7.5mm 1.5mm 94mm

TL-SG108S-M2 4#, (5#), 6# 7.5mm 1.5mm 110mm

TL-SG116 4#, (5#), 6# 8.5mm 1.5mm 200mm

TL-SG116E 4#, (5#), 6# 8.5mm 1.5mm 200mm

TL-SG116P 4#, (5#), 6# 8.5mm 1.5mm 200mm

TL-SG1210MP 4#, (5#), 6# 8.5mm 1.5mm 150mm

TL-SG1210MPE 4#, (5#), 6# 8.5mm 1.5mm 150mm

TL-SG1210P 4#, (5#), 6# 7.5mm 1.5mm 150mm

TL-SG1210PP 4#, (5#), 6# 7.5mm 1.5mm 150mm

TL-SG2008 4#, (5#), 6# 8.5mm 1.5mm 150mm

Model Screw Standard of

ANSI B1.1

Minimum Length

of Screw

Screw-Head-to-Wall

Minimum Distance

Wall-Mounting-Holes

Distance

TL-SG2008P 4#，，5#，，6# 8.5mm 1.5mm 150mm

TL- SG2016P 4#，，5#，，6# 8.5mm 1.5mm 200mm

TL-SG2210P 4#，，5#，，6# 8.5mm 1.5mm 15 0mm

TL-SG605 4#, (5#), 6#, 8# 7.5mm 1.5mm 39mm

TL-SG605E 4#, (5#), 6# 7.5mm 1.5mm 52mm

TL-SG605P 4#, (5#), 6#, 8# 7.5mm 1.5mm 39mm

TL-SG608 4#, (5#), 6#, 8# 8.5mm 1.5mm 94mm

TL-SG608E 4#, (5#), 6# 7.5mm 1.5mm 110m m

TL-SG608P 4#, (5#), 6#, 8# 8.5mm 1.5mm 105mm

T L- S L13 11MP 4#, (5#), 6# 8.5mm 1.5mm 150 mm

T L- S L13 11P 4#, (5#), 6# 8.5mm 1.5mm 15 0 mm

TL-SX105 4#, (5#), 6# 7.5mm 1.5mm 150mm
