TP-Link TL-MR3040 Manual de usuario

Page 1 | 03/16

Provisioning a TP-Link Portable Router for

XM360 X-Tractor

The following instructions step a user through the configuration of a TP-Link Portable Wireless Router (model TL-

MR3040) to be used with XM360 X-Tractor. These instructions make no assumptions pertaining to the current

state of the TP-Link, so they will be valid for a new or previously provisioned TP-Link.

This guide will start with general instructions on how to

identify and reset the TP-Link, and then will branch

depending on which type of device the user has available

with which to provision the TP-Link (*Windows

laptop/desktop with ethernet cable, Windows

laptop/desktop over Wi-Fi, Android or iOS device over Wi-

Fi). *preferred method

Section 1: Resetting the TP-Link to Default State

1. Power on the TP-Link by toggling the Power Switch (as seen

in Figure 2), and confirm that power indicator light on front

panel illuminates green

If light does not turn or or is red, plug in TP-Link with

provided power cable before continuing

2. With a paperclip or narrow object, press and hold the reset

button for at least 10 seconds (as seen in Figure 2)

At the 10 second mark, front indicator lights will all flash

once

3. On the back panel, identify if your particular TP-Link has the

mode switch (Version 2) or does not have a mode switch

(Version 1) (as seen in Figure 3)

If Version 2, move Mode Switch to “WISP”

4. Remove battery cover by prying off the cover from the

corner indicated by an arrow next to the ethernet port

(circled in red in both Figure 2 and Figure 3)

Make note of the Default Settings sticker found

underneath the cover, above the battery

5. Depending on device/connection type, continue on to

step 2 (Windows w/ ethernet), step 3 (Windows w/ Wi-

Fi), or step 4 (Android or iOS w/ Wi-Fi)

FIGURE 1: TP-LINK TL-MR3040

FIGURE 2: FRONT PANEL

FIGURE 3: BACK PANEL

Page 2 | 03/16

Section 2: Connecting to TP-Link Using Windows Laptop/Desktop via Ethernet

1. Connect TP-Link to Windows device using ethernet cable (ethernet port on TP-Link seen in Figure 2)

Confirm that device has ethernet adapter enabled with no static IP set, as well as no other active

network connections

A. In the system tray, right click the network icon and select Open Network and Sharing Center

B. In the left navigation bar, select Change adapter settings

C. Confirm that desired Local Area Connection is enabled and connected, and that any other

connection is Not Connected

D. Right click on Local Area Connection and select

Properties (if User Account Control prompt appears,

click Yes to allow change)

E. In the Local Area Connection Properties window in the

Networking tab, select Internet Protocol Version 4

(TCP/IPv4), then click the Properties button just below

F. Confirm that both Obtain an IP address automatically

and Obtain DNS server address automatically are

selected, and press OK

2. Open a web browser (such as Internet Explorer), and navigate to

192.168.0.1

3. When prompted, authenticate with:

Username: admin Password: admin

This information can be found on the Default Settings sticker under the battery cover

If no prompt appears, confirm:

A. TP-Link has power and is turned on

B. Ethernet connection

C. PC network adapter enabled and connected

D. No other network connections exist

E. No static IP set on PC

F. TP-Link has been restored to factory defaults (as explained in Section 1)

4. Continue to Section 5 to provision TP-Link

Section 3: Connecting to TP-Link Using Windows Laptop/Desktop via Wi-Fi

1. In Windows, connect to TP-Link’s Wi-Fi network

Name of network, as well as potential Wi-Fi password (TP-Link version-dependent), can be found on

the Default Settings sticker under the battery cover

Confirm that device has Wi-Fi adapter enabled with no static IP set, as well as no other active

network connections:

FIGURE 4: WINDOWS NETWORK CONNECTIONS -LAN

FIGURE 5: LAN PROPERTIES

Page 3 | 03/16

A. In the system try, right click on the network icon and select Open Network and Sharing Center

B. In the left navigation bar, select Change adapter settings

C. Confirm that desired Wireless Network Connection is enabled and connected, and that any other

connection is Not Connected

D. Right click on Wireless Network Connection and select Properties (if User Account Control prompt

appears, click Yes to allow change)

E. In the Wireless Network Connection Properties window in the Networking tab, select Internet

Protocol Version 4 (TCP/IPv4), then click the Properties button just below

F. Confirm that both Obtain an IP address automatically and Obtain DNS server address

automatically are selected, and press OK

2. Open a web browser (such as Internet Explorer), and navigate to 192.168.0.1

3. When prompted, authenticate with:

Username: admin Password: admin

This information can be found on the Default Settings sticker under the battery cover

If no prompt appears, confirm:

A. TP-Link has power and is turned on

B. PC Wi-Fi network adapter enabled and connected

C. No other network connections exist

D. No static IP set on PC

E. TP-Link has been restored to factory defaults (as explained in Section 1)

4. Continue to Section 5 to provision TP-Link

Section 4: Connecting to TP-Link Using Android or iOS Device via Wi-Fi

1. On device, connect to TP-Link’s Wi-Fi network

Name of network, as well as potential Wi-Fi password (TP-Link

version-dependent), can be found on the Default Settings

sticker under the battery cover

Confirm that connection has no static IP set

A. Go to device’s Settings, then Wi-Fi (can be found under

Wireless & networks on Android)

B. Click on TP-Link’s network

C. Select FORGET to remove any prior configurations for this

connection (as seen in Figures 7 & 8)

D. Reconnect to the TP-Link (after clicking FORGET, Android

will not reconnect automatically)

2. Open a web browser (such as Chrome (Android) or Safari (iOS)), and

navigate to 192.168.0.1

FIGURE 6: WINDOWS NETWORK CONNECTIONS -WI-FI

FIGURE 7: ANDROID WI-FI DETAILS

Page 4 | 03/16

3. When prompted, authenticate with:

Username: admin Password: admin

This information can be found on the Default Settings

sticker under the battery cover

If no prompt appears, confirm:

A. TP-Link has power and is turned on

B. Wi-Fi is turned on and connected

C. No static IP is set for TP-Link’s Wi-Fi network

D. TP-Link has been restored to factory defaults (as

explained in Section 1)

4. Continue to Section 5 to provision TP-Link

Section 5: Provisioning TP-Link

1. Navigate to Operation Mode in the left-hand

navigation bar

2. Change Operation Mode to WISP Client Router

Mode and click Save

After clicking Save, TP-Link will reset (will take

approximately one minute)

If webpage fails to appear after reboot when

using Wi-Fi, make sure that TP-Link is still the

device’s active connection

3. Navigate to Network in the left-hand navigation bar,

then select LAN from Network’s submenu

4. Change IP Address to 192.168.100.5 and click Save

After clicking Save, TP-Link will reset (will take

approximately one minute)

After saving, you must go to 192.168.100.5 to

configure device (instead of 192.168.0.1)

If webpage fails to appear after reboot when

using Wi-Fi, make sure that TP-Link is still the

device’s active connection

If webpage still fails to appear after reboot and device is connected, forget the network

connection on user’s device, then try again

5. Navigate to DHCP in the left-hand navigation bar, then select DHCP Settings from DHCP’s submenu

6. Confirm/Set the following (if any changes made, user must perform steps 9 & 10):

A. DHCP Server is enabled

B. Start IP Address is set to 192.168.100.100

C. End IP Address is set to 192.168.100.199

7. Navigate to Wireless in the left-hand navigation bar, then select Wireless Security from submenu

8. Select Disable Security to remove any Wi-Fi password

If a password is desirable, select WPA/WPA2 –Personal and enter desired password

If any changes made, user must perform steps 9 & 10

9. Navigate to System Tools, then select Reboot from System Tools’ submenu

10. Click Reboot to reboot device and commit any changes made in steps 5-8

If webpage fails to appear after reboot when using Wi-Fi, make sure that TP-Link is still the device’s

active connection

FIGURE 8: IOS WI-FI DETAILS

FIGURE 9: TP-LINK CONFIGURATION START-SCREEN

Page 5 | 03/16

Section 6: Using Other Routers

In the event that a TP-Link TL-MR3040 Portable Router is not available to use, it is possible to use XM360 X-Tractor

with a different router, however not every router will work. In order to use a different router successfully, it must

be a Wi-Fi enabled router capable of serving DHCP over LAN. Typically, any Wi-Fi router meant for home use will

work (with the caveat that it will require an open power outlet). However, travel routers more often than not are

not capable of serving DHCP over LAN (with the TP-Link TL-MR3040 being the exception), so other travel routers

should be avoided.

Once acquired, a router must first be provisioned properly in order to work with XM360 X-Tractor:

1. The router’s IP address must be set to “192.168.100.5”

2. DHCP must be enabled (this is typically enabled by default)

3. The DHCP IP Range must be in the “192.168.100.X”subnet and MUST NOT include “192.168.100.1”(it is

recommended to set the range to start with “192.168.100.100”and end with “192.168.100.200”)

Then, once properly configured, the transponder must be connected to the router via the LAN port (if there are

multiple, they will often be numbered) and NOT the WAN port (sometimes labeled “Internet”or “Modem”).

NOTE: When using a router in this way, it is neither necessary nor recommended to have a static IP address

defined for this connection on your tablet/computer.
