TP-Link TD-W8968 Manual de usuario

www.tp-link.com

Features：

300Mbps Wireless N USB ADSL2+

Modem Router

High speed DSL modem, NATrouter and wireless access point

in one device providing a one-stop networking solution

Wireless N speed up to 300Mbps makes it ideal for heavy

bandwidth consuming or interruption sensitive applications

like online gaming, Internet calls and even the HD video

streaming

USB Port for Storage Sharing, Printer Sharing1

, 3G Modem

Sharing, FTP Server and Media Server

Supports the latest Internet Protocol IPv6

to future-proof your

network

IP based Bandwidth Control makes it easier for you to manage

Ethernet WAN (EWAN) oers another broadband connectivity

option for connecting to Cable, VDSL or Fiber modems

the bandwidth of devices that connected to the modem router

Wi-Fi On/O Switch lets you simply turn the wireless radio

on or o

SPI and NAT rewall protects end-user devices from potential

attacks from the Internet

One-stop IPTV setting solution makes it easier to set up your

IPTV

EasySetup Assistant2

with multi-language support provides a

quick &hassle free installation

TD-W8968

Description：

TP-LINK’s 300Mbps Wireless N USB ADSL2+ Modem Router TD-W8968 is an incredibly robust all-in-one device allowing users to

port and share it wirelessly at 300Mbps wireless 802.11n speeds. With its multi-function USB port, users can share printers, les,

3G Modem, and play media across the local network or access les from attached USB storage across the internet using the

access high-speed internet connection via ADSL, 3G Modem or Ethernet WAN (EWAN) using its interchangeable LAN/WAN

TD-W8968’s FTP server function. Moreover, it supports the latest Internet Protocol IPv6 to future-proof your network.

1The USB Printer Setup Wizard supports Windows 7/Vista/XP/2003/2000 currently. For the printer compatibility information, please visit www.tp-link.com.

The Easy Setup Assistant utility supports Windows 2000/XP/Vista and Windows 7 operating system at present.

IPTV application may require subscribing to IPTV services from an ISP.

Guest Network Access provides secure Wi-Fi access for

guests sharing your home or oce network

www.tp-link.com

Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are

trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make

any derivative such as translation, transformation, or adaptation without permission from TP-LINK Technologies Co., Ltd.

TD-W8968

300Mbps Wireless N USB ADSL2+ Modem Router

Specifications：

External Power Supply

IEEE Standards

ADSL Standards

ADSL2 Standards

Port Forwarding

VPN Pass-Through

ATM/PPP Protocols

Advanced Features

Security

Management

USB Sharing

ADSL2+ Standards

Antenna Type

Antenna Gain

Wireless Standards

Wireless Security

Quality of Service

Frequency

EIRP

Button

Interface

Product Description 300Mbps Wireless N USB ADSL2+ Modem Router

4 10/100Mbps RJ45 Ports

1 RJ11 Port

1 USB 2.0 Ports

1 WPS Button

1 RESET Button

12VDC/1A

IEEE 802.3, 802.3u

Full-rate ANSI T1.413 Issue 2

ITU-T G.992.3 (G.dmt.bis)

ITU-T G.992.4 (G.lite.bis)

ITU-T G.992.1(G.DMT), ITU-T G.992.2(G.Lite)

ITU-T G.994.1 (G.hs),

ITU-T G.992.5

ITU-T G.995.1

Omni directional, Detachable, Reverse SMA

2 x 5dBi

IEEE 802.11b, 802.11g, 802.11n

2.400-2.4835GHz

<20dBm(EIRP)

Support 64/128 bit WEP, WPA-PSK/WPA2-PSK,

Wireless MAC Filtering

Bandwidth Control (IP QoS)

Virtual server, DMZ, ACL(Access Control List)

PPTP, L2TP, IPSec Pass-through

ATM Forum UNI3.1/4.0

PPP over ATM (RFC 2364)

PPP over Ethernet (RFC2516)

IPoA (RFC1577/2225)

PVC - Up to 8 PVCs

Ethernet WAN (EWAN)

Guest Network, Wireless Schedule, Parent Control

Trac Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt

Dynamic Host Conguration Protocol (DHCP), DHCP relay

Network Address Translation (NAT)

PVC/Ethernet Port Grouping

Static Routing, RIP v1/v2 (optional)

DNS Relay, DDNS

UPnP

NAT Firewall, SPI Firewall, MAC / IP / Packet / URL Filtering

Storage Sharing, 3G Sharing, FTP Server, Media Server, Print Server

Remote management,

Telnet management,

Command Line Interface,

SSL for TR-069,

SNMP V1/V2C, SNMP over EOC,

Web Based Firmware Upgrade,

CWMP(TR-069), Diagnostic Tools

www.tp-link.com

Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are

trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make

any derivative such as translation, transformation, or adaptation without permission from TP-LINK Technologies Co., Ltd.

TD-W8968

300Mbps Wireless N USB ADSL2+ Modem Router

Specifications：

IPv6

System Requirements

Operating Humidity

Storage Humidity

Dimensions (W X D X H)

Operating Temperature

Storage Temperature

IGMP IGMP snooping V1/V2/V3

IGMP Multicast

IPv6 and IPv4 dual stack

Supported IPv6 Tunnels: DS-Lite, 6RD, 6 to 4

Supported IPv6 Connection Type: PPPoEv6, DHCPv6, Static IPv6

CE, FCC, RoHS

IPv6

Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, MAC® OS, NetWare®, UNIX® or

Linux.

0°C~40°C (32°F~104°F)

-40°C~70°C (-40°F~158°F)

10%~90% non-condensing

5%~90% non-condensing

7.7*5.1*1.4 in. (195×130×36mm)

www.tp-link.com

Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are

trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make

any derivative such as translation, transformation, or adaptation without permission from TP-LINK Technologies Co., Ltd.

300Mbps Wireless N USB ADSL2+ Modem Router

TD-W8968

Diagram:

Package: Related Products:

- 300Mbps Wireless NUSB ADSL2+Modem Router

TD-W8968

- One Power Adapter

- One External splitter (Optional)

- Two RJ-11 Telephone Lines

- One RJ-45 Ethernet Cable

- Resource CD

- Quick Installation Guide

- 300Mbps Wireless NUSB Adapter

TL-WN821N

- 300Mbps Wireless NPCI Adapter

TL-WN851N

Online Gaming

Video and Audio Streaming

Wi-Fi Phone

300Mbps Wireless N USB Adapter

TL-WN821N

300Mbps Wireless N PCI Adapter

TL-WN851N

Printer or Hard drive5

/Flash disk connection

300Mbps Wireless N USB

ADSL2+ Modem Router

TD-W8968

5Some USB hard drive that works at a high power without using any external power adapter might not be supported.
