TP-Link TD-8840 Manual de usuario

TD-8840 User Guide

External ADSL2+ Router

Rev: 1.0.2

1910010008

Specifications are subject to change without notice. is a registered trademark of

TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or

registered trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by any means or used to make any

derivative such as translation, transformation, or adaptation without permission from TP-LINK

http://www.tp-link.com

III

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

•Consult the dealer or an experienced radio/ TV technician for help.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1) This device may not cause harmful interference.

2) This device must accept any interference received, including interference that may

cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

CE Mark Warning

This is a class B product. In a domestic environment, this product may cause radio interference, in

which case the user may be required to take adequate measures.

EC DECLARATION OF CONFORMITY (EUROPE)

In compliance with the EMC Directive 89/336/EEC, Low Voltage Directive 73/23/EEC, this product

meets the requirements of the following standards:

• EN55022

• EN55024

• EN60950

SAFETY NOTICES

Caution:

Do not use this product near water, for example, in a wet basement or near a swimming pool.

Package Contents

The following items should be found in your package:

¾One TD-8840 External ADSL2+ Router

¾One AC power Adapter for TD-8840 ExternalADSL2+ Router

¾One Resource CD for TD-8840 External ADSL2+ Router, including:

•This Guide

•Other Helpful Information

•Quick installation Guide Program

¾Quick installation Guide

¾One RJ45 cable

¾Two RJ11 cables

¾One ADSL splitter

)Note:

Make sure that the package contains the above items. If any of the listed items are damaged or

missing, please contact with your distributor.

CONTENTS

Chapter 1. Introduction ........................................................................................1

1.1 Product Overview...................................................................................................... 1

1.2 Main Features ........................................................................................................... 1

1.3 Supporting Protocol................................................................................................... 1

1.4 Transmit Data-rate .................................................................................................... 2

1.5 ATM Property............................................................................................................ 2

1.6 System Support......................................................................................................... 2

1.7 Working Environment................................................................................................ 2

1.8 Conventions .............................................................................................................. 3

Chapter 2. Hardware Installation.........................................................................4

2.1 System Requirement................................................................................................. 4

2.1.1 LED Explanation...............................................................................................................4

2.2 Rear-panel ................................................................................................................4

2.3 Hardware Installation Procedures............................................................................. 5

Chapter 3. System Configuration........................................................................6

3.1 Computer Configuration............................................................................................ 6

3.2 Login .........................................................................................................................7

3.3 Web Setup ................................................................................................................ 9

3.4 Software Dial........................................................................................................... 18

Chapter 4. Advantage Management Setup.......................................................20

Appendix A: FAQ....................................................................................................21

Appendix B: Default Config...................................................................................23

TD-8840 External ADSL2+ Router User Guide

Chapter 1.Introduction

Thank you for choosing the TD-8840 External ADSL2+ Router.

1.1 Product Overview

With the excellent circuit design and high quality production, we guarantee the ADSL2+ Router’s

high performance, great stability and easy to use.

The TD-8840 uses integrated ADSL2+ transceiver. The AFE supports full-rate ADSL connectivity

conforming to the ITU and ANSI specifications.

In addition to the basic DMT physical layer functions, the ADSL PHY supports dual latency ADSL

framing (fast and interleaved) and the I.432 ATM Physical Layer.

The TD-8840 is a complete plug-and-play solution. With standard Ethernet interface, it can be

directly connected to any 10M/100M Ethernet devices, support Auto-MDIX.

The TD-8840 not only uses html (web mode through Ethernet port) to configure the Router but

also uses external utility software. You can download it from our website (http://www.tp-link.com).

1.2 Main Features

¾High speed and asymmetry data transmit mode, built-in 4-port switch realize multi-user to

share wide-band internet access

¾Support All ADSL2+ industrial standards

¾Compatible with all mainstream DSLAM (CO)

¾Firmware upgradeable

¾Provide integrated access of internet and route function which face to SOHO user

¾Advanced DMT modulation and demodulation

¾Real-time Configuration and device monitoring

¾Quick response semi-conductive surge protect circuit, provides reliable ESD and

surge-protect function

1.3 Supporting Protocol

- G.992.1 (G.dmt) - Annex A/B/C

- G.992.2 (G.lite) - Annex A/B/C

- ANSI T1.413

- G.992.3 (ADSL2) - Annex A/B/C/M and Annex L (RE-DSL) compliant

- G.992.5 (ADSL2+) Annex A/B/C and Annex L (RE-DSL) compliant

TD-8840 External ADSL2+ Router User Guide

- ADSL dual latency (fast path and interleaved path)

- I.432 ATM physical layer compliant

- Supports RFC2364 (PPPoA)

- Supports RFC2516 (PPPoE)

- Supports RFC1483 (EoA) (Bridged *and Router)

- Supports RFC1577 (IPoA)

)Note:

“*” Needs the third-party software.

1.4 Transmit Data-rate

¾Max download data-rate: 24Mbps

¾Max upload data-rate: 3.5Mbps

¾Max line length: 6Km

1.5 ATM Property

¾AAL0, AAL5, OAM, RM, and raw cell types supported

¾Direct hardware support for 4 Receive VCs, with additional RX VCs and TX VCs supported in

software

¾Full 24-bit Virtual Path Identifier (VPI) and Virtual Circuit Identifier (VCI)

1.6 System Support

¾Support PVC

¾Support NAT、DHCP and so on

¾Support IEEE 802.3、IEEE 802.3u

¾Support 10Base-T/100BASE-TX full-duplex or half duplex Ethernet

¾Support Auto-MDIX

1.7 Working Environment

¾Operating temperature: 0 ~40℃℃

¾Storage temperature: -40 ~70℃℃

TD-8840 External ADSL2+ Router User Guide

¾Humidity: 10%~90% (non-condensing)

1.8 Conventions

The Router or TD-8840, or device mentioned in this User guide stands for TD-8840 External

ADSL2+ Router without any explanations.

Parameters provided in the pictures are just references for setting up the product, which may

differ from the actual situation.

You can set the parameters according to your demand.

TD-8840 External ADSL2+ Router User Guide

Chapter 2.Hardware Installation

The TD-8840 maintains five separate interfaces, four Ethernet and one ADSL interface. The

Router should not be located where it will be exposed to moisture or excessive heat. Place the

Router in a location where it can be safely connected to the various devices as well as to a power

source.

2.1 System Requirement

Confirm your computer has been installed with networking interface card (NIC) before connecting

ADSL2+ Router to your computer, with operating system supporting the TCP/IP protocol.

2.1.1 LED Explanation

The front panel of ADSL2+ Router includes one power indicator (RED) and seven function

indicators (GREEN), as explained in chart below:

Name Status Indication

On Power on

PWR Off Power off

Slow flash Self-detecting when power on

Quick flash The LINE port is connecting to the ISP’s network

On The LINE port has connected to ISP’s network

ADSL

Off The LINE port has no connection

On There is mistake when ADSL transmitting data or receiving data

ALARM Off ADSL normal

On There is data transmitting or receiving on WAN port

ACT Off No data transmitting or receiving on WAN port

On 1~4(LAN) port normal

Off Connection on 1~4(LAN) port abnormal

LAN(1-4)

Flash Data transmitting or receiving on 1~4(LAN) port

2.2 Rear-panel

¾ON/OFF: Turn on/off the ADSL2+ Router’s power.

¾Power (9VAC/0.8A input): Please do not use any unknown power adaptor; otherwise your

ADSL2+ Router may be damaged.

¾RESET (reset default): Press the reset button, then turn on the Router's power (keep the
