TP-Link TL-SG1008 Manual de usuario

TP-LINK TECHNOLOGIES CO.,LTD.

E-mailǖ[email protected]m

Websiteǖhttp:// www.tp-link.com.cn

ADDǖFI.3,Bldg.R1-B.High-Tech Industrial Park,Shenzhen Road.Shenzhen.China

71035787

User’s Guide

TL-SG1008

8-port Gigabit Ethernet Switch

TL-SG1016

16-port Gigabit Ethernet Switch

TL-SG1024

24-port Gigabit Ethernet Switch

TL-SG1048

48-port Gigabit Ethernet Switch

Specifications are subject to change without notice. is a

registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands

and product names are trademarks or registered trademarks of their

respective holders.

No part of the specifications may be reproduced in any form or by any means

or used to make any derivative such as translation, transformation, or

adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.

http://www.tp-link.com

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to pro-vide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference in which case the user

will be required to correct the interference at his own expense.

CE Mark Warning

This is a class A product. In a domestic environment, this product may cause

radio interference, in which case the user may be required to take adequate

measures.

SAFETY NOTICES

Cautions

Do not use this product near water, for example, in a wet basement or near a

swimming pool.

Avoid using this product during an electrical storm. There may be a remote risk

of electric shock from lightning.

CONTENTS

Package Contents .................................................................. 1

Chapter 1 Introduction of the Product.............................. 2

1.1 Overview of the Product...............................................................2

1.2 Features..........................................................................................2

Chapter 2 Installation......................................................... 4

2.1 Mounting the Switch on a Desk.......................................................4

2.2 Mounting the Switch in a Rack........................................................4

2.3 Power On........................................................................................5

Chapter 3 Identifying External Components.................... 7

3.1 Rear Panel......................................................................................7

3.2 LED Indicators ................................................................................7

Appendix A: Specifications ................................................... 9

Appendix B: Troubleshooting ............................................. 10

TL-SG1008/TL-SG1016/TL-SG1024/TL-SG1048

Gigabit Ethernet Switch User Guide

Package Contents

The following contents should be found in your box:

¾One Gigabit Ethernet Switch

¾One power cord

¾This User's Guide

¾Rubber footpads for Desk-mount

¾Rack-mount kit for installing the switch in a 19-inch rack

Note: If any of the above contents is damaged or missing, please

contact the retailer from whom you purchased the Gigabit Ethernet Switch for

assistance.

TL-SG1008/TL-SG1016/TL-SG1024/TL-SG1048

Gigabit Ethernet Switch User Guide

Chapter 1 Introduction of the Product

This chapter describes the features of the Gigabit Ethernet Switch.

1.1 Overview of the Product

The Gigabit Ethernet Switch provides you with a high-performance, low-cost,

easy-to-use, seamless and standard upgrade to boost your old network to

1000Mbps. Increase the speed of your network server and backbone

connections make Gigabit a reality. Power users in the home, office,

workgroup or creative production environment can now move large,

bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia

files and other applications that have to move large files across the network

almost instantly.

The Gigabit Ethernet Switch features a non-blocking switching architecture

that forwards and filters packets at full wire-speed for maximum throughput. It

is compatible with all 10,100, and 1000Mbps Ethernet devices because it is

standard-based, it protects your existing network investments while providing

you with a straightforward migration path to faster Gigabit speeds.

The Gigabit Ethernet Switch is plug-and-play and no configuration is required.

Auto MDI/MDI-X cable detection on all ports eliminate the need for crossover

cable or Uplink port. Each port can be used as general ports or Uplink ports,

and any port can be simply plugged into a server, a hub, a router or a switch,

using the straight cable or crossover cable. Diagnostic LEDs which display link

status and activity, allowing you to quickly detect and correct problems on the

network.

1.2 Features

¾Complies with IEEE802.3, IEEE802.3u, IEEE802.3ab standards

TL-SG1008/TL-SG1016/TL-SG1024/TL-SG1048

Gigabit Ethernet Switch User Guide

¾8/16/24/48 10/100/1000Mbps Auto-Negotiation RJ45 ports

supporting Auto- MDI/MDIX

¾All ports Support full/half-duplex mode for 10/100Mbps and full

duplex- mode for 1000Mbps

¾Supports IEEE802.3x flow control for full-duplex mode and

backpressure for half-duplex mode

¾Non-blocking switching architecture that forwards and filters packets

at full wire-speed for maximum throughput

¾4K entry MAC address table of the TL-SG1008 and 8K entry MAC

address table of the TL-SG1016, TL-SG1024 and TL-SG1048 with

auto-learning and auto-aging

¾LED indicators for monitoring power, link, speed and activity

¾Store-and-Forward switching method

TL-SG1008/TL-SG1016/TL-SG1024/TL-SG1048

Gigabit Ethernet Switch User Guide

Chapter 2 Installation

2.1 Mounting the Switch on a Desk

Before placing the Switch on a desk, attach four rubber footpads to the flutes

on the Switch bottom, then lay the Switch on the desktop, where can be able

to withstand 5kg of weight.

TL-SG1008, TL-SG1016, TL-SG1024 and TL-SG1048 are different in the

number of LED indicators and RJ45 ports. All figures are of TL-SG1008 in this

user's guide.

Note

¾Make sure there is a grounded AC outlet within 1.5 meters, and working

well.

¾Make sure there is free space for radiating heat and air.

¾Make sure not too place anything to heavy on top of the switch.

2.2 Mounting the Switch in a Rack

The dimension of the Gigabit Ethernet Switch is designed according to the

standard 19” rack-mountable steel case of Electronic Industries Association.

Turn off all the equipment connected to the Switch before mounting it in the

rack, then rivet the two “L” brackets onto each side of the Switch, fasten it with

screws in the rack.

TL-SG1008/TL-SG1016/TL-SG1024/TL-SG1048

Gigabit Ethernet Switch User Guide

Figure 2-1 Rivet the “L” brackets onto the Switch

Figure 2-2 Fasten the Switch in the rack

2.3 Power On

The Gigabit Ethernet Switch is powered by AC power supply. Powering on the

Switch, it will automatically initialize and its LED indicators should respond as

follows:

1) All of the 10/100Mbps Link/Act and 1000Mbps Link/Act LED indicators of

the TL-SG1008 will flash momentarily at first, flash sequence later and

flash momentarily lastly, which represent a resetting of the system.

All of the 10/100Mbps Link/Act and 1000Mbps Link/Act LED indicators of the
