FormNo.3454-889RevA

PowerHarnessKit

Groundsmaster®3200or3300SeriesTractionUnit

ModelNo.140-1559

InstallationInstructions

Installation

PreparingtheMachine

NoPartsRequired

Procedure

1.Parkthemachineonalevelsurface.

2.Engagetheparkingbrake.

3.Lowertheattachments.

4.Shutofftheengineandremovethekey.

DisconnectingtheBattery

NoPartsRequired

RemovingtheBatteryCables

WARNING

Batteryterminalsormetaltoolscouldshort

againstmetalcomponents,causingsparks.

•Whenremovingorinstallingthebattery,

donotallowthebatteryterminalstotouch

anymetalpartsofthemachine.

•Donotallowmetaltoolstoshortbetween

thebatteryterminalsandmetalpartsofthe

machine.

WARNING

Electricalsparkscancausethebatterygasses

toexplode,resultinginpersonalinjury.

Incorrectbatterycableroutingcoulddamage

themachineandcables,causingsparks.

•Alwaysdisconnectthenegative(black)

batterycablebeforedisconnectingthe

positive(red)cable.

•Alwaysconnectthepositive(red)battery

cablebeforeconnectingthenegative

(black)cable.

1.Removethenegativebatterycablefromthe

batterypost(Figure1).

g252591

Figure1

1.Negativebatterycable2.Positivebatterycable

2.Lifttheinsulatorandremovethepositivebattery

cablefromthebatterypost(Figure1).

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.T oro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved*3454-889*

RoutingthePowerHarness

Partsneededforthisprocedure:

1Powerharness

6Cabletie

1Relay

1Fuse(10A)

Procedure

Important:Routethewireharnessawayfrom

anyhot,sharp,ormovingparts;securewithcable

tiesasneeded.

1.Unlatchandopenthehood.

g285428

Figure2

2.Installtherelayintotheharness(Figure3).

3.Routethe2ringterminalsforthebatteryaround

theengine(Figure3).

g398735

Figure3

1.Positive(+)battery

connector

4.Cabletie7.Optionalcontrolconnection10.Accessorypower

connections

2.Battery5.Relay8.Mainharnessconnection11.Optionalwasheruid

connection

3.Negative(-)battery

connector

6.Fuses9.Usecabletiestosecure

excesswire.

12.Auxiliarypowerconnector

4.Routetheharnesstotheconnectorpositions

showninFigure3.

5.Securetheharnesstothemachinewiththe

cabletiesshowninFigure3.

6.Rotatethelatchesandremovethesidecoveron

thearmrest(Figure4).

g333069

Figure4

1.Cover

7.Installthe10Afuseintothefuseblockasshown

inFigure5.

g333070

Figure5

1.Installed10Afuse

8.Installthecoverandsecureitwiththelatches.

ConnectingtheBattery

NoPartsRequired

Procedure

WARNING

Electricalsparkscancausethebatterygasses

toexplode,resultinginpersonalinjury.

Incorrectbatterycableroutingcoulddamage

themachineandcables,causingsparks.

•Alwaysdisconnectthenegative(black)

batterycablebeforedisconnectingthe

positive(red)cable.

•Alwaysconnectthepositive(red)battery

cablebeforeconnectingthenegative

(black)cable.

1.Connectthepositivecabletothebatteryand

tightenthebattery-clampnut(Figure6).

g252786

Figure6

1.Positivebatterycable2.Negativebatterycable

2.Connectthenegativecabletothebatteryand

tightenthebattery-clampnut(Figure6).

3.Assembletheinsulatoroverthepositivebattery

terminal(Figure6).

Notes:
