TomTom START Manual de usuario

TomTom Start

Getting started1.

Getting started

Mounting your navigation device

1. Push the EasyPort™ Mount on your TomTom Start against the windscreen

in your car.

2. Adjust the angle of your device.

3. Lock the EasyPort Mount by twisting the base.

4. Insert the Car Charger into your device.

5. Insert the Car Charger into the cigarette lighter in your car.

6. Switch your device on by pressing the On/Off button on the back of your

device.

7. You now have to answer some questions to set up your device. Tap the

screen to answer the questions.

1 2

8. To remove the Mount from your windscreen, first unlock the EasyPort

Mount, then gently pull one of the tabs. The Mount comes away from the

windscreen.

GPS reception

When you first start your TomTom Start navigation device, the device may

need a few minutes to determine your GPS position and show your current

position on the map. In future, your position will be found much faster, usually

within a few seconds.

To ensure good GPS reception, you should use your device outdoors. Large

objects such as tall buildings can sometimes interfere with reception.

Changeable covers

You can personalise your TomTom Start by changing the covers. Go to tom-

tom.com/startskins to check which covers are available.

Toremovethecoverfromthedevice,firstremovethemount.Thenholdeither

sideofthecover and pushthroughthecentreofthecovertodetachthedevice

from the cover as shown in the diagram.

Troubleshooting

In rare cases, your TomTom Start navigation device may not start correctly or

may stop responding to your taps.

First, check that the battery is properly charged. To charge the battery, con-

nect your device to the car charger.

If this does not solve the problem, you can reset the device. To do this, do the

following.

1. Remove the Mount from the device by pressing the release button on the

Mount.

2. Pull the back cover off the device by holding either side of the cover and

pushing the device through the centre of the cover.

3. Use a straightened paper clip, or something similar, to push the reset but-

ton. The reset button is on the bottom of your device.

123

Driving View2.

Driving View The Driving View shows your current location on the map together with

detailed information such as current speed and route instructions.

Tap the centre of the screen at any time to open the Main Menu.

AYour current position.

BThe name of the next major road or road sign information, if applicable.

CYour speed and the speed limit, if known.

Tap this panel on the status bar to adjust the volume.

When the volume control is displayed, the next route instruction is spoken.

This is a useful way to hear and adjust the current volume level.

DNext route instruction.

Tap this panel on the status bar to switch between 2D and 3D views of the

Driving View.

EThe name of the street you are on.

FInformation about your journey: journey time, remaining distance and

arrival time.

Tap this panel on the status bar to see a route summary.

Main Menu3.

Main Menu The Main Menu is the starting point for planning a route, looking at a map or

changing your device settings.

To open the Main Menu from the Driving View, tap the centre of the Driving

View screen.

To return to the Driving View from the Main Menu, tap done.

Main Menu buttons

The following buttons are shown on the Main Menu.

Sound

Plan route

Tap this button to plan a new route.

This button is shown when you have not planned a route.

Change route

Tap this button to plan a new route.

This button is shown when you have planned a route.

Browse map

Tap this button to look at the map.

sound

Tap this button to turn the sound off.

Night /Day

Options

Help

sound

Tap this button to turn the sound on.

night

Tap this button to set the night colour scheme, which reduces the bright-

ness of the screen and shows the map using dark colours.

This is useful when driving at night or in dark environments such as long

tunnels.

day

Tap this button to set the day colour scheme, which increases the bright-

ness of the screen and shows the map using bright colours.

options

Tap this button to adjust the settings for your device.

For more information, see the chapters Options and Advanced settings.

help

Tap this button to see the contact details and plan a route to an emergency

services centre or another specialist service such as a veterinary service.

For more information, see the chapter Help.

Browse Map4.

Browse Map To look at the map in the same way as you might look at a traditional paper

map, tap Browse map in the Main Menu.

You can use your finger to move the map by touching the screen and sliding

your finger across the screen.

AThe scale bar

BMarker

Markers point to your current location, your home location and your desti-

nation. The marker shows the distance to the location.

Tap a marker to centre the map on the location pointed to by the marker.

CGPS button

Tap this button to centre the map on your current position.

DThe POI button

Tap this button to select which POIs are shown.

EThe cursor

FThe Find button

Tap this button to find specific addresses.

GThe Cursor button

Tap this button to plan a route to the cursor position, create a Favourite at

the cursor position or find a Point of Interest near to the cursor position.

HThe zoom bar

Zoom in and out by moving the slider.

Planning a route5.

Planning a route 1. Tap the screen to open the Main Menu.

2. Tap Plan route.

You are asked if you want to leave from where you are.

Tap YES to plan a route from your current location. You will probably plan

most of your routes this way.

Tap NO to select another starting point. You might decide to do this so you

can view the route before you intend to start travelling.

You can select your destination in different ways.

In this example, we'll enter an address.

3. Tap Address.

4. Start to type the name of the town and tap on the name when it appears in

the list.

Tip: When you plan a route for the first time you are asked to select the coun-

try or state. Your choice is saved and used for all future routes. You can

change this setting by tapping on the flag and selecting a new coutry or state.

5. Enter the street name in the same way and then enter the house number.

Tip: The name at the top of the list is a city/town centre. Instead of entering

the street name and house number, you can tap the name at the top of the list

to set the address as the town centre.

The route is planned and a summary of the route is shown.
