TomTom NAVIGATOR Manual de usuario

TomTom NAVIGATOR

Before you start...1.

Before you start...

Setting up

To start using your phone as a navigation device, tap the TomTom button in

the Windows Mobile start menu.

To set up your navigation device, you need to answer a few questions by

tapping the screen.

Important: Take care to select the correct language, since the language you

choose will be used for all menus and written instructions.

Activation

You will be asked how you want to activate the map that comes with

NAVIGATOR. There are two ways to do this:

• Automatically

To activate automatically, your device must have an active wireless data

connection (GPRS, EDGE, UMTS or CDMA).

Tap Automatic, then enter your product code. The product code is printed

on the product code card that is included with your product.

TomTom NAVIGATOR will connect to TomTom using the wireless data

connection and activate the map.

• Manually

To activate a map manually, do the following:

1. Tap Manual.

2. Go to this website: www.ttcode.com

3. Follow the instructions on this page to get an activation code.

4. Enter the activation code on your device to activate the map.

Improving reception

If your TomTom NAVIGATOR takes longer than 5 minutes to find your current

position, make sure that the device is in an open space away from tall objects,

such as buildings or trees.

Important: Some vehicles have heat reflective shielding in the windscreen.

This may prevent your NAVIGATOR from locating your current position.

Switching on and off

To switch your TomTom NAVIGATOR on or off, press and hold the On/Off

button for 2 seconds. The first time you switch on, it may take a short while for

your device to start.

Note: In rare cases, your NAVIGATOR may not start correctly. If this happens,

press the reset button, then switch on the device again.

To use your TomTom NAVIGATOR on your telephone, tap the NAVIGATOR

button.

Exit

application

To close TomTom NAVIGATOR, tap Exit application in the Main Menu. We

recommend that you close NAVIGATOR whenever you finish using the

application, since some of the phone settings are managed by NAVIGATOR

to enable you to place and receive phone calls while you are driving.

Driving View2.

Driving View When your TomTom NAVIGATOR starts, you are shown the Driving View

along with detailed information about your current location.

Tap the centre of the screen at any time to open the Main Menu.

Note: The Driving View is shown in black and white until your NAVIGATOR

locates your current position.

ATap + and - to zoom in and out.

BQuick menu - switch this on in the Preferences menu.

CYour current position.

DThe name of the next major road or road sign information, if applicable.

ENavigation instruction for the road ahead.

Tap this area to repeat the last spoken instruction and to change the

volume.

FThe name of the street you are on.

GInformation about your journey such as journey time, remaining distance

and arrival time.

To change the information shown, tap Status bar preferences in the

Preferences menu.

HTraffic bar. For more information about how to subscribe to and receive

TomTom Traffic, go to tomtom.com/traffic.

To set up Traffic information, tap TomTom Traffic in the Main Menu.

Making your first journey3.

Making your first journey Planning a route with your TomTom NAVIGATOR is easy. To plan your first

route, follow the steps below.

Important: You should always plan your journey before you start driving. It is

dangerous to plan a route while driving.

1. Tap the screen to bring up the Main Menu.

Note: The buttons on your NAVIGATOR are shown in full colour unless a

button is currently unavailable. For example, the button named Find

alternative... in the Main Menu is not available until you have planned a route.

2. Tap Navigate to...

3. Tap Address.

When you enter an address, you can choose from the following options:

•City centre - tap this button to set your destination as the centre of a city

or town.

•Street and house number - tap this button to set an exact address as your

destination.

•Postcode - tap this button to enter a postcode as your destination.

Note: You can enter a postcode for any country. In the UK and the

Netherlands, postcodes are detailed enough to identify a house on their own.

In other countries you can enter a postcode to identify a town or area. You will

then have to enter a street and house number.

•Crossing or intersection - tap this button to set your destination as the

point where two streets meet.

In this example, we will enter an exact address.

4. Tap Street and house number.

Note: When planning a trip for the first time your NAVIGATOR asks you to

choose a country. Your choice is saved and used for all routes you plan.

You can change this setting at any time by tapping the country flag.

5. Start to type the name of the town where you want to go.

As you type, the names of the towns that match what you have typed are

shown. When your destination appears in the list, tap the name of the town

to set the destination.

6. Start to type the name of the street and select it when it is shown.

As with the name of the town, the names of the streets that match what you

have typed are shown. When your destination appears in the list, tap the

name of the street to set the destination.

7. Now enter the house number of your destination and then tap Done.

8. Your NAVIGATOR asks if you need to arrive at a particular time. For this

exercise, tap NO.

The route is calculated by your NAVIGATOR.

9. When the route has been calculated, tap Done.

Your NAVIGATOR will immediately begin to guide you to your destination,

using both spoken instructions and on-screen directions.

Arrival times

When you plan a route, your TomTom NAVIGATOR asks you if you need to

arrive at a particular time.

Tap YES to enter a preferred arrival time.

Your NAVIGATOR calculates your arrival time and shows you whether you will

arrive on time.

You can also use this information to work out when you need to leave. If your

NAVIGATOR shows that you will arrive 30 minutes early, you can wait and

leave in 30 minutes time, rather than arrive early.

Your arrival time is constantly recalculated during your journey. The status bar

shows whether you will arrive on time or if you are going to be late, as shown

below:

You will arrive 55 minutes before the arrival time you entered.

If the estimated arrival time is more than five minutes before

the time you entered, it is shown in green.

You will arrive 3 minutes before the arrival time you entered.

If the estimated arrival time is less than 5 minutes before the

time you entered, it is shown in yellow.

What are the other navigation options?

When you tap Navigate to..., you can set your destination in many ways, not

just by entering the address. The other options are listed below:

You will arrive 19 minutes late.

If the estimated arrival time is later than the time you entered,

it is shown in red.

Status bar

preferences

Tap Status bar preferences in the Preferences menu, to enable or disable

arrival time notifications.

Select the required options on the first menu screen and then tap Done.

To enable arrival time notifications, select Show leeway to arrival time.

Home

Tap this button to navigate to your Home location.

You will probably use this button more than any other.

Favourite

Tap this button to select a Favourite as your destination.

Address

Tap this button to enter an address as your destination.

Recent

destination

Tap this button to select your destination from a list of places you have

recently used as destinations.

Point of

Interest

Tap this button to navigate to a Point of Interest (POI).

Point on map

Tap this button to select a point on the map as your destination using the

map browser.

Latitude

Longitude

Tap this button to enter a destination using latitude and longitude values.

Planning a route in advance

You can also use your NAVIGATOR to plan journeys in advance by selecting

both your starting point and your destination. You could, for example, do the

following:

• Find out how long a journey is going to take before you start.

• Check the route of a journey you are planning.

• Check a route for someone who is coming to visit you, so that you can

explain the route to them.

To plan a route in advance, follow these steps:

1. Tap the screen to bring up the main menu.

2. Tap the arrow button to move to the next menu screen and tap Prepare

route.

3. Select the starting point for your journey in the same way that you would

select your destination.

4. Set the destination for your journey.

5. Choose the type of route that should be planned.

•Fastest route - the route which takes the least time.

•Shortest route - the shortest distance between the locations you set. This

may not be the quickest route, especially if the shortest route is through

a town or city.

•Avoid motorways - a route which avoids motorways.

•Walking route - a route designed for making the journey on foot.

•Bicycle route - a route designed for making the journey on a bicycle.

•Limited speed - a route for a vehicle which can only be driven at a limited

speed. You have to specify the maximum speed.

6. Your TomTom NAVIGATOR plans the route between the two locations you

selected.

More information about a route

You can access these options for the route you last planned by tapping View

route in the Main Menu or the Details button on the route summary screen.

TomTom

Buddy

Tap this button to navigate to the last known position of a TomTom Buddy.

Don’t forget that the Buddy may move before you reach him.

Contact

Tap this button to navigate to the address of a contact on your device.

Prepare route
