SpeedTouch™510v5/v6

Residential ADSL Gateway

Installation and Setup Guide

Release R5.4

SpeedTouch™

510v5/v6

Installation and Setup Guide

R5.4

Distribution and copying of this document, use and communication of its contents is not permitted without written authorization

from THOMSON. The content of this document is furnished for informational use only, may be subject to change without notice,

and should not be construed as a commitment by THOMSON. THOMSON assumes no responsibility or liability for any errors or

inaccuracies that may appear in this document.

Thomson Telecom Belgium

Prins Boudewijnlaan, 47

B-2650 Edegem

Belgium

www.speedtouch.com

Trademarks

The following trademarks are used in this document:

SpeedTouch™ is a trademark of THOMSON.

Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc.

Ethernet™ is a trademark of Xerox Corporation.

Wi-Fi® and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance. "Wi-Fi CERTIFIED", "Wi-Fi ZONE", "Wi-Fi Alli-

ance", their respective logos and "Wi-Fi Protected Access" are trademarks of the Wi-Fi Alliance.

UPnP™ is a certification mark of the UPnP™ Implementers Corporation.

Microsoft®, MS-DOS®, Windows® and Windows NT® are either registered trademarks or trademarks of Microsoft Corpo-

ration in the United States and/or other countries.

Apple® and Mac OS® are registered trademarks of Apple Computer, Incorporated, registered in the United States and

other countries.

UNIX® is a registered trademark of UNIX System Laboratories, Incorporated.

Adobe®, the Adobe logo, Acrobat and Acrobat Reader are trademarks or registered trademarks of Adobe Systems, Incor-

porated, registered in the United States and/or other countries.

Netscape® and Netscape Navigator® are registered trademarks of Netscape Communications Corporation.

Other brands and product names may be trademarks or registered trademarks of their respective holders.

Document Information

Status: v1.0 (November 2005)

Reference: E-DOC-CTC-20051017-0010

Short Title: Installation and Setup Guide ST510v5/v6 R5.4 (en)

Contents

E-DOC-CTC-20051017-0010 v1.0 i

Contents

About this Installation and Setup Guide ................... 1

1 Introducing the SpeedTouch™....................................3

2 Basic Installation...........................................................5

2.1 Setting up your SpeedTouch™....................................................... 6

2.2 Installing your SpeedTouch™......................................................... 7

2.2.1 Guided Installation........................................................................................................... 8

2.2.2 Manual Installation ........................................................................................................16

2.3 The SpeedTouch™ Setup CD........................................................ 18

2.4 SpeedTouch™ Connection Essentials .......................................... 19

2.5 Connections Overview and Powering .......................................... 20

2.6 Basic Security .............................................................................. 21

3 Web-Based User Interface..........................................23

Contents

E-DOC-CTC-20051017-0010 v1.0

4 Internet Connection Troubleshooting.......................25

4.1 Checking the Hardware................................................................ 26

4.2 LED Diagnostics ........................................................................... 27

4.3 Web Diagnostics .......................................................................... 29

4.4 SpeedTouch™ Setup CD Troubleshooting ................................... 31

4.5 Easy Setup Troubleshooting ........................................................ 34

About this Installation and Setup Guide

E-DOC-CTC-20051017-0010 v1.0

About this Installation and Setup Guide

Used symbols The following symbols are used in this Installation and Setup Guide:

Terminology Generally, the SpeedTouch™510v5/v6(i) will be referred to as SpeedTouch™ in this

Installation and Setup Guide.

Documentation and

software updates

THOMSON continuously develops new solutions, but is also committed to improve

its existing products.

For suggestions regarding this document, please contact

documentati[email protected]et.

For more information on THOMSON's latest technological innovations, documents

and software releases, visit us at: www.speedtouch.com.

A note provides additional information about a topic.

A tip provides an alternative method or shortcut to perform an action.

!A caution warns you about potential problems or specific precautions that

need to be taken.

About this Installation and Setup Guide

2E-DOC-CTC-20051017-0010 v1.0

E-DOC-CTC-20051017-0010 v1.0

Chapter 1

Introducing the SpeedTouch™

1 Introducing the SpeedTouch™

Introduction In a minute you will be able to access the Internet using your

SpeedTouch™510v5/v6(i) Residential ADSL Gateway.

This Installation and Setup Guide will show you how to set up your SpeedTouch™

and how to connect a computer or a local area network (LAN) to the Internet.

Identifying your

SpeedTouch™

The label on the bottom of your SpeedTouch™ informs you about the

SpeedTouch™’s:

Product name

Model number

Serial number

Power requirements

DSL variants The SpeedTouch™ comes in two ADSL variants:

POTS: The SpeedTouch™510v5/v6 connects to an analogue Plain Old Telephone

Service (POTS) line.

ISDN: The SpeedTouch™510v5/v6iconnects to an Integrated Service Digital

Network (ISDN) line, enabling residences with an ISDN line to use the ADSL

service.

You can easily identify your variant by checking the product name printed on the

label on the bottom of your SpeedTouch™.

!Do not remove or cover the label.

The ... variant supports ...

POTS ADSL

ADSL2

ADSL2+

RE-ADSL

ISDN ADSL

ADSL2

ADSL2+

!Only use the SpeedTouch™ variant which is appropriate for the DSL service

provided to your premises.

4E-DOC-CTC-20051017-0010 v1.0

Chapter 1

Introducing the SpeedTouch™

SpeedTouch™ Setup CD Your SpeedTouch™ comes with a Setup CD.

If you insert the CD into a Microsoft Windows PC or Mac OS X computer:

The first time, an intuitive SpeedTouch™ Quick-Install Wizard will guide you

through the hardware setup of your SpeedTouch™ and will help you to

connect to the Internet.

See “2.2 Installing your SpeedTouch™” on page 7 for more information.

For future reference, the SpeedTouch™ CD Menu provides links to all contents

See “2.3 The SpeedTouch™ Setup CD” on page 18 for more information.

If you use another operating system, a set of subdirectories allows you to easily

browse for user documentation, SpeedTouch™ system software, service templates,

etc.

SpeedTouch™ Home Install

Wizard

The SpeedTouch™ Home Install Wizard has been designed to help you on the

Internet very quickly.

First, the wizard tries to detect your SpeedTouch™. As soon as you have connected

your SpeedTouch™ to your computer, the wizard configures your SpeedTouch™

and - if necessary - your computer.

The Home Install Wizard was designed for Microsoft Windows operating systems

and Mac OS X - in the latter case provided you use a wired connection to your

SpeedTouch™.

You can start the SpeedTouch™ Home Install Wizard:

Automatically from the SpeedTouch™ Quick-Install Wizard when you insert

the SpeedTouch™ Setup CD into a computer for the first time.

See “2.2 Installing your SpeedTouch™” on page 7 for more information.

From the SpeedTouch™ CD Menu Home page, via Run Quick Installation. This

will in fact re-run the Quick-Install Wizard and subsequently start the Home

Install Wizard as if you started the Setup CD for the first time.

From the SpeedTouch™ CD Menu Maintenance page, via Reconfigure my

SpeedTouch™.

If you do not want to use the guided installation procedure, you can also

install and configure your SpeedTouch™ manually. See “2.2.2 Manual

Installation” on page 16 for more information.
