Manual

DALI button interface

TA 4 S DALI-2

TA 4 DALI-2 - 4960094

Manual DALI button interface TA 4 S DALI-2 2

Contents

1General 3

1.1 Safety information 3

1.2 Proper use 3

1.3 Explanation of terms 3

2Function description 4

2.1 Application examples 4

2.2 Overview of available instances 5

3Technical data 6

4Product characteristics 7

4.1 Usage 7

4.2 Functionality 7

4.3 Dimensions 8

5Connection 9

6Installation 10

7Settings 11

7.1 Settings via the DALI bus 11

8Operating modes 12

8.1 Memory bank 2 – push button instance 12

8.2 Memory bank 3 – absolute input device 13

8.3 Assignment of short addresses 16

8.4 Button function C1-C4 16

8.5 Determining measurement values T1/T2 via the DALI bus 16

9Accessories 18

10 Contact 20

Manual DALI button interface TA 4 S DALI-2 3

1General

1.1 Safety information

ATTENTION

Installation should only be carried out by a qualified electrician!

1.2 Proper use

The DALI button interface TA 4 S DALI-2 is a compact DALI-2 controller with 4 inputs for

connecting potential-free buttons and 2 inputs for connecting variable resistors, e.g. sliders,

potentiometers or various Theben temperature sensors. It can be easily installed in flush-

mounted boxes and is intended for indoor installation.

TA 4 S DALI-2 is exclusively intended for use as contractually agreed between the manufacturer

and the user. Any other use is considered to be unacceptable. The manufacturer does not accept

liability for any resulting damages.

1.3 Explanation of terms

The TA 4 S DALI-2 DALI button interface is a push button processing unit of an input control

device according to standard IEC 62386 Part 301 as well as an absolute input device according

to standard IEC 62386 Part 302 and DiiA Guidelines "Clarifications & Recommendations for IEC

62386" Version 1.2, April 2020.

The term push button processing unit of an input control device is used in this document in the

English spelling "push button input device", absolute input device as "absolute input device"

and short address as "short address".

Manual DALI button interface TA 4 S DALI-2 4

2Function description

The TA 4 S DALI-2 button interfaces are integrated into a DALI system. Thanks to the DALI-2

standard, an application controller from any manufacturer may be used. This controller must

support standard IEC 62386 Parts 101/103/301 – and if variable resistors or temperature

sensors are used – also Part 302.

The TA 4 S DALI-2 button interfaces and other DALI components are connected to the DALI line.

The DALI supply is provided by the application controller or an external DALI supply. The

assignment of the short addresses (random addressing) for the button interfaces is carried out

via the application controller.

After start-up, the TA 4 S DALI-2 button interface captures the binary states of the connected

buttons and transmits this information to the higher-level controller (application controller) as a

DALI telegram. If variable resistors or temperature sensors are connected, the measured values

are transmitted to the higher-level controller as a DALI telegram (absolute input device).

2.1 Application examples

Application with a higher-level controller

Conventional buttons, sliders and Theben temperature sensors can be connected to the TA 4 S

DALI-2 button interface for the desired application, also for blinds, lighting control, heating

control, etc.

Manual DALI button interface TA 4 S DALI-2 5

Application with a DALI-2 presence detector

For switching or dimming lamps, conventional buttons are connected to the TA 4 S DALI-2

button interface.

2.2 Overview of available instances

Instance

no.

Instance name

Instance

type

Standard

Memory bank

Absolute input device T1

IEC 62386-302

Absolute input device T2

IEC 62386-302

Button C1

IEC 62386-301

Button C2

IEC 62386-301

Button C3

IEC 62386-301

Button C4

IEC 62386-301

Manual DALI button interface TA 4 S DALI-2 6

3Technical data

Operating voltage

DALI (in accordance with IEC 62386-101): 10 V – 22.5 V

Power input

max. 10 mA

Type of installation

Flush-mounted box according to DIN 49073

Type of contact

NO contact or opening contact, potential-free

Contact voltage

5 V

Contact current

0.5 mA (5 mA peak)

Output voltage

5 V DC

Debounce time

50 ms

Resistance range for slider or

potentiometer

0 … 100 kΩ

Max. temperature measurement

range

- 25 °C … + 75 °C or 0 °C … + 85 °C

Protection rating

IP 20 (IP 40 when installed)

Protection class

II (subject to designated use)

Ambient temperature

-15 °C … + 50 °C

Pollution degree

Rated impulse voltage

4 kV

Connection type DALI

Screw terminals

Cable cross-section

0.14 – 1.5 mm² one wire

0.14 – 1.5 mm² fine wire

0.25 – 0.5 mm² fine wire with crimp terminal (with and

without plastic sleeve)

Length of connecting wires for

buttons or temperature sensor

25 cm

Max. cable length for buttons or

temperature sensor

30 m

CE Declaration of Conformity

This device corresponds to EN 60669-1/-2-1/-2-5

RCM conformity

This device is compliant with the ACMA guidelines.

DALI conformity

IEC 62386-101/103/301/302

1can be installed with conventional buttons/switches in flush-mounted boxes

2Measurement range depends on the temperature sensor used. Further information can be

found in chapter 8.2 Memory bank 3 – absolute input device.

Manual DALI button interface TA 4 S DALI-2 7

4Product characteristics

4.1 Usage

The button interface TA 4 S DALI-2 can be used in many different ways. It can be used for

applications such as blinds control, lighting control, heating control, etc.

The focus is on applications in residential and commercial construction:

•Office building

•Schools

•Hospitals

•Hotels

•Sports halls or warehouses

Only for use in closed and dry rooms.

4.2 Functionality

•Compact DALI-2 controller with 4 inputs for the connection of potential-free

buttons according to standard IEC 62386 Part 301.

•Buttons of contact type "NO contact" or "opening contact" can be used. The contact

type can be set in the memory bank.

•Additionally, 2 inputs are available to connect variable resistors, e.g. sliders,

potentiometers or various Theben temperature sensors according to standard

IEC 62386 Part 302. The sensor is selected in the memory bank.

•The measurement values can be corrected with an adjustable offset if, for example,

the measurement deviates from a reference instrument.

•For the inputs for variable resistors or temperature sensors, an adjustable filter is

available for noise suppression.

•The DALI bus load of the event telegrams of the measurement values can be flexibly

reduced by means of hysteresis.

•The TA 4 S DALI-2 is a DALI bus participant and can be correspondingly addressed

according to IEC 62386 Part 103.

•The identification of the button interface is indicated by the LED.

•The TA 4 S DALI-2 button interface is supplied via the DALI bus.

•Easy installation in conventional flush-mounted boxes.

All of the product characteristics are described in detail in the following sections.

Manual DALI button interface TA 4 S DALI-2 8

4.3 Dimensions

Manual DALI button interface TA 4 S DALI-2 9

5Connection

The TA 4 S DALI-2 button interfaces are connected to the DALI line.

For operation of the TA 4 S DALI-2, an external DALI supply is required. This DALI supply

must be able to ensure a reliable power supply for all connected DALI participants.

A minimum current of 10 mA per TA 4 S DALI-2 device must be provided.

Plug for connection

lead

DALI connection

A connection lead with plug is supplied for connecting buttons C1 to C4, variable resistors or

Theben temperature sensors T1 and T2. The cable length is 25 cm and can be extended up to

max. 30 m if required.

Connection of buttons C1 to C4

Connection of variable resistors or Theben temperature sensors T1 and T2

BK = Black; BN = Brown; RD = Red; OG = Orange, YE = Yellow; GN = Green; BU = Blue

Only connect potential-free buttons.

Do not connect 230 V to the device. Otherwise the device will be destroyed.

Manual DALI button interface TA 4 S DALI-2 10

6Installation

The TA 4 S DALI-2 button interfaces are installed in conventional flush-mounted boxes

according to DIN 49073.
