THE WORLD MODELS Ultimate EP Manual de usuario

THE WORLD MODELS

MANUFACTURING CO., LTD.

FACTORY PRE-FABRICATED

ALMOST-READY-TO-FLY (ARF) SERIES

MADE IN CHINA

www.theworldmodels.com

Wing Span

Wing Area

Flying Weight

Fuselage Length

36 in / 910 mm

440 sq in / 28.4 sq dm

27 oz / 770 g

38 in / 970 mm

Warning! This model is not a toy.

It is designed for maximum performance. Please seek advice if one is not familiar with this kind

of engine powered precision model. Operating this model without prior preparation may cause

injuries. Remember, safety is the most important thing. Always keep this instruction manual at

hand for quick reference.

HIGH

PERFORMANCE

KM0283010KM0283010

Outrunner Motor Included!

Max Speed 12000 rpm

Operating Power 180 W

Operating Voltage 6-12 V

Peak Current 20 A (max 15 s)

Shaft diameter 3 mm

Diameter 28 mm

Lengthe 30 mm

Weight 60 g

Outrunner Motor

Requires : 4-channel radio w/ 4 micro servos,

20A Brushless ESC, 3 cells 11. 1V

2100mAh Li - Po battery & charger.

Specifications

*Specifications are subject to change without notice.*

INSTRUCTION MANUAL

INDEX

BEFORE YOU BEGIN

PARTS LIST

ASSEMBLY

SAFETY PRECAUTIONS

P.1

P.2

P.3-P.10

P.10

Check all parts. If you find any defective or missing parts contact your local dealer. Please

DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly.

Any parts you find to be defective after the gluing process may be difficult to remove for

warranty replacement. The manufacturer will replace any defective parts, but will not extend

to the parts that are good before gluing to defective parts during assembly. Warranty will

not cover any parts modified by customer.

Symbols used throughout this instruction manual comprise of the following :-

Read through the manual before you begin, so you will have an overall idea of what to do.

Apply epoxy glue.

Assemble left and right

sides the same way.

Peel off shaded portion

covering film.

Drill holes with the specified

diameter (here: 3mm)

Pay close attention here!

Pierce the shaded portion

covering film.

Apply instant glue

(C.A.glue, super glue.)

Ensure smooth non-binding

movement while assembling.

Cut off shaded portion.

Must be purchased separately!

Do not overlook this symbol!

3mm

P.1

Parts List

P.2

COVERING:--

PURPLE COLOR SCHEME:

LIGHTEX SGX100 WHITE

LIGHTEX SGX201 BLACK

LIGHTEX SGX312 BRIGHT RED

LIGHTEX SGX370 SILVER

LIGHTEX SGX561 PEARL PURPLE

YELLOW COLOR SCHEME:

LIGHTEX SGX100 WHITE

LIGHTEX SGX201 BLACK

LIGHTEX SGX312 BRIGHT RED

LIGHTEX SGX370 SILVER

LIGHTEX SGX330 CADMIUM YELLOW

1. MAIN WING (Lower) -- 1 pc.

2. SCREW PM2x12mm -- 4 pcs

FUEL TUBE d2xD4x4mm -- 4 pcs

STRAPER -- 2 pcs

CLEVIS -- 2 pcs

HORN -- 2 sets

PUSHROD Ø1.4x75mm w/ Threads (For Aileron) -- 2 pcs

PLYWOOD 3x6x15mm (For Aileron Servos) -- 4 pcs

3. MAIN WING (Upper) -- 1 pc.

4. STABILIZER & ELEVATOR -- 1 set

FUSELAGE -- 1 pc.

SCREW PM2x8mm -- 2 pcs

ELEVATOR LINK PL4510010 -- 1 pc.

BASLA 4x12x34.7mm -- 1 pc.

5. VERTICAL FIN & RUDDER -- 1 set

6. TAIL LANDING GEAR -- 1 set

TAIL WHEEL Ø23mm -- 1 pc.

PLASTIC COLLAR d1xD5x2mm -- 2 pcs

SCREW PA2x8mm -- 2 pcs

SCREW PM2x8mm -- 1 pc.

M2 NUT -- 1 pc.

ALUMINUM PLATE 0.3x8x22mm -- 1 pc.

7. SCREW PM2x10mm -- 2 pcs

CLEVIS -- 1 pc.

FUEL TUBE d2xD4x4mm -- 1 pc.

HORN -- 1 set

PUSHROD Ø1.4x520mm w/ Threads (For Rudder) -- 1 pc.

8. FUEL TUBE d2xD4x4mm -- 1 pc.

CLEVIS -- 1 pc.

PUSHROD Ø1.4x490mm w/ Threads (For Elevator) -- 1 pc.

9. KM0283010 OUTRUNNER MOTOR -- 1 set

HW2340100 PROPELLER ADAPTOR (d3 D5) -- 1 set

FOLDING PROPELLER SET PL6314020 -- 1 set

SCREW PWA2x8mm -- 4 pcs

SCREW PM3x6mm -- 4 pcs

WASHER d3xD7mm -- 4 pcs

COWLING -- 1 pc.

SPINNER Ø45mm -- 1 set

10. MAIN LANDING GEAR -- 1 pc.

MAIN WHEEL Ø40mm -- 2 pcs

WHEEL PANTS -- 1 pair

SCREW PM2x6mm -- 7 pcs

SCREW PM3x25mm -- 2 pcs

M3 NUT -- 2 pcs

WASHER d3xD7mm -- 2 pcs

WASHER d2xD5mm -- 4 pcs

M2 NUT -- 4 pcs

10. MAIN LANDING GEAR -- 1 pc.

MAIN WHEEL Ø40mm -- 2 pcs

WHEEL PANTS -- 1 pair

SCREW PM2x6mm -- 3 pcs

SCREW PM3x25mm -- 2 pcs

WASHER d2xD5mm -- 7 pcs

WASHER d3xD7mm -- 4 pcs

M3 NUT -- 2 pcs

SCREW PA2x6mm -- 4 pcs

COLLAR Ø3.1mm w/ Set Screw -- 2 sets

COPPER TUBE d3.1xD4x5mm -- 2 pcs

ALUMINUM PLATE 0.5mm -- 2 pcs

11. STRAPER -- 2 pcs

FUEL TUBE d2xD4x4mm -- 2 pcs

SCREW PM2x10mm -- 1 pc.

WASHER d2xD5mm -- 1 pc.

M2 NYLON INSERT LOCK NUT -- 1 pc.

BATTERY TIE -- 1 pc.

SPONGE 10x80x150mm (For Radio Equipment) -- 1 pc.

DOUBLE-SIDED TAPE 30x35mm -- 1 pc.

MOUNTING PLATE 5x15mm PL4114015 -- 1 pc.

PLYWOOD 2x56x96mm -- 1 pc.

12. CANOPY -- 1 pc.

SCREW PWA2x8mm -- 4 pcs

PILOT (050) -- 1 pc.

13. NYLON BOLT M2.5x20mm -- 2 pcs

NYLON WASHER d2.6xD9mm -- 2 pcs

PLASTIC PLATE 1x25.5x63.7mm (Wing Protection) -- 1 pc.

14. SCREW PWA2.3x12mm -- 4 pcs

SCREW PM2x14mm -- 2 pcs

SCREW PM2x8mm -- 4 pcs

WASHER d2xD5mm -- 12 pcs

M2 NYLON INSERT LOCK NUT -- 6 pcs

PLYWOOD 3x53x170mm (Side Cabane) -- 2 pcs

FOAM 3x204x209mm (Wing IncidenceAngle Template) -- 2 pcs

ALUMINIUM PLATE (Brace: Fueslage to Wing) -- 1 set

15. SCREW PM2x8mm -- 8 pcs

HORN -- 4 sets

CLEVIS -- 4 pcs

FUEL TUBE d2xD4x4mm -- 4 pcs

PUSHROD Ø1.4x138mm w/ Threads (For Aileron to Aileron) -- 2 pcs

16. DECALS -- 1 set

Main Wing (Lower)

Apply instant type CA glue to both sides of each hinge.

Completed

Aileron Servo (Lower)

Aileron Servo Lead

Cabane Mount

PM2x12mm Screw

Clevis

Horn

Straper

PLYWOOD

3x6x15mm Fuel Tube

d2xD4x4mm

Fuel Tube

d2xD4x4mm

PM2x12mm

Pushrod Ø1.4x75mm

2mm

Ø1mm pilot holes for World Models tri-horn are pre-drilled.

Please look for pin-hole marks at side of control surfaces.

P.3

Vertical Fin & Rudder

Temporary install the main wing, adjust

leveling of the stabilizer to make is as

parallel to the main wing as possible.

Ø1mm pilot holes for World Models tri-horn are pre-drilled.

Please look for pin-hole marks at side of control surfaces.

*Also refer to step 13 Wing Setting

(Stabilizer)

(Main Wing)

B=B

A=A

A A

2mm

c=c'

P.4

PM2x8mm Screw

PM2x8mm

Balsa

4x12x34.7mm

Stabilizer & Elevator

Main Wing (Upper)

Apply instant type CA glue to both sides of each hinge.

Cabane Mount

Bottom View

Completed

Tail Landing Gear

PA2x8mm Screw

PA2x8mm

PM2x8mm Screw

PM2x8mm

Bottom View

Elevator Pushrod

Rudder Pushrod

M2 Nut M2 Nut

PM2x10mm Screw

Plastic Collar

1mm

27mm

125mm

57mm

130mm

Clevis

Horn

Fuel Tube

d2xD4x4mm

PM2x10mm

Pushrod

Ø1.4x520mm

Pushrod

Ø1.4x520mm

2mm

Pushrod

Ø1.4x490mm

Clevis

Fuel Tube

d2xD4x4mm

P.5

Ø1mm pilot holes for World Models tri-horn are pre-drilled.

Please look for pin-hole marks at side of control surfaces.

Outrunner Motor / Cowling

PM3x6mm Screw

d3xD7mm

Washer

PWA2x8mm Screw

PA2.6x8mm Screw

Completed

Main Landing Gear

3.1mm

Wheel Collar

PM2x12mm

PM3x6mm

d3xD7mm

Washer

PA2.6x8mm

PWA2x8mm

Don’t over-tighten the PM2 screws, let the propeller

blades align themselves when spinning.

1.5mm

Ø45mm Spinner

M5 Nut

Bottom View

PM3x25mm Screw

d3xD7mm Washer

M3 Nut

PM2x6mm Screw

PM2x6mm

d2xD5mm

Washer

PA2x6mm Screw

d2xD5mm Washer

Completed

Make sure rotating motor casing

is not in contact with wirings or

anything.

d3.1xD4x5mm Copper Tube

PM3x25mm

Plate 0.5mm

PA2x6mm

Copper Tube

d3.1xD4x5mm

d3xD7mm Washer

d2xD5mm Washer

d3xD7mm Washer

d2xD5mm Washer

Wheel

Ø40mm

3mm

Set Screw

3.1mm

Collar

P.6

Radio Equipment

PWA2x8mm Screw

PWA2x8mm

Bottom View

Canopy

Front

Install and arrange the servo as shown

in the diagram.

Battery

Double-Sided Tape

Mounting Plate

PM2x10mm

PLYWOOD 2x56x96mm

M2 Nylon Insert Lock Nut

Straper

Pilot

Rudder Servo

Sponge Rudder Pushrod

Elevator Pushrod

Elevator Servo

d2xD5mm

Washer

Fuel Tube

d2xD4x4mm

20A Speed Controller

Battery Tie

1mm

2mm

PM2x10mm Screw

d2xD5mm Washer

P.7

Main Wing (Lower)

M2.5x20mm Nylon Bolt

Wing Protection

1x25.5x63.7mm

d2.6xD9mm Nylon Washer

Bottom View

Main Wing

PM2x8mm Screw

PM2x8mm

PWA2.3x12mm Screw

PWA2.3x12mm

PM2x14mm Screw

PM2x14mm

With the wing incidence angle

template still in place, position

the side cabanes, mark and drill

the side cabane mounts and

fasten with PM2x8mm screw

and nut.

Pierce the two pre-drill holes

at upper wing center cabane

mount and fasten the center

cabanes with PM2x14mm

screw and nut. With the lower

wing fastened to the fuselage,

insert the wing incidence angle

templates to both sides of upper

and lower wing to hold the upper

wing in position. Mark and drll

1.5mm pilot holes at the fuselage

and fasten the center cabane

with PWA2.3x12mm screws.

Outer wing cabane

should fit to the outside

of outer wing cabane

mounts.

SIDE CABANE

PLYWOOD 3x53x170mm

WING INCIDENCE ANGLE TEMPLATE

PLYWOOD 3x204x209mm

d2xD5mm Washer

d2xD5mm

Washer

M2 Nylon Insert Lock Nut

1.5mm

2mm

P.8

Main Wing

PM2x8mm Screw

Wing Setting

PM2x8mm Fuel Tube

d2xD2x4mm

Clevis

Horn

Pushrod

Ø 1.4x138mm

MainWing(Upper)

MainWing(Lower)

Ø1mm pilot holes for World Models tri-horn are pre-drilled.

Please look for pin-hole marks at under side of control surfaces.

Adjust the wing and fuselage configuration

as shown in the diagrams.

AA'

B'B C'

A=A' B=B' C=C' D=D' E=E' F=F' G=G'

G' F'F G

P.9

Tabla de contenidos

Otros manuales de Juguete de THE WORLD MODELS

THE WORLD MODELS

THE WORLD MODELS ARF Zen 30 Manual de usuario

THE WORLD MODELS

THE WORLD MODELS La-Flyer-40 Manual de usuario

THE WORLD MODELS

THE WORLD MODELS Sky Runner Manual de usuario

THE WORLD MODELS

THE WORLD MODELS ZERO FIGHTER 40 Manual de usuario

THE WORLD MODELS

THE WORLD MODELS PIPER PA-25 PAWNEE Manual de usuario

THE WORLD MODELS

THE WORLD MODELS P-51 MUSTANG EP 40 Manual de usuario

THE WORLD MODELS

THE WORLD MODELS 1/6 PIPER PA-25 PAWNEE Manual de usuario

THE WORLD MODELS

THE WORLD MODELS SUPER SPORTS 40S Manual de usuario

THE WORLD MODELS

THE WORLD MODELS Pilatus PC-6 Porter 40 Manual de usuario

THE WORLD MODELS

THE WORLD MODELS P-40 Warhawk Manual de usuario

THE WORLD MODELS

THE WORLD MODELS Rambler EP Manual de usuario

THE WORLD MODELS

THE WORLD MODELS At-6 Texan EP Manual de usuario

THE WORLD MODELS

THE WORLD MODELS Jeff Troy's TAMEcat Trainer 40 ARF Manual de usuario

THE WORLD MODELS

THE WORLD MODELS F4U CORSAIR EP Manual de usuario

THE WORLD MODELS

THE WORLD MODELS PIPER J-3 CUB EP Manual de usuario

THE WORLD MODELS

THE WORLD MODELS T-34 Mentor Manual de usuario

THE WORLD MODELS

THE WORLD MODELS 1/4 SUPER CUB Manual de usuario

THE WORLD MODELS

THE WORLD MODELS ARF AT-6 Texan Manual de usuario

THE WORLD MODELS

THE WORLD MODELS 1/3 PIPER J-3 CUB Manual de usuario

THE WORLD MODELS

THE WORLD MODELS The Big Wings Manual de usuario

THE WORLD MODELS

THE WORLD MODELS PAULISTINHA P-56 EP Manual de usuario

THE WORLD MODELS

THE WORLD MODELS A322S Manual de usuario

THE WORLD MODELS

THE WORLD MODELS RAMBLER-45 Manual de usuario

THE WORLD MODELS

THE WORLD MODELS ZERO FIGHTER EP Manual de usuario

Manuales populares de Juguete de otras marcas

marklin

marklin 37321 Manual de usuario

Canon

Canon PAPER CRAFT Manual de usuario

GREAT PLANES

GREAT PLANES Pitts M-12S Manual de usuario

NOCH

NOCH 14261 Manual de usuario

Hausler

Hausler 450 SE V2 Manual de usuario

Dynaflite

Dynaflite Daydream Manual de usuario

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Manual

Kenner

Kenner Batman 63651 Manual de usuario

LEGO

LEGO 8527 Manual de usuario

iKarus

iKarus ECO 8 Manual de usuario

Multiplex

Multiplex EasyStar II Manual de instrucciones

Walkera

Walkera 38 Manual de instrucciones

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE Manual de usuario

MD MXION SWD Manual de usuario

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway Manual de usuario

marklin

marklin 39671 Manual de usuario

Meccano

Meccano 15103 Manual de usuario

LEGO

LEGO TECHNIC 8735 Manual de usuario
