CC3235MODSF SimpleLink™ Wi-Fi®and IoT

Solution With MCU LaunchPad™ Hardware

User's Guide

Literature Number: SWRU548

February 2019

2SWRU548–February 2019

Submit Documentation Feedback

Contents

1 CC3235MODSF LaunchPad™ Development Kit (LAUNCHCC3235MOD)...................................... 3

1.1 Introduction ................................................................................................................... 5

1.1.1 CC3235MODSF LaunchPad™ ................................................................................... 5

1.1.2 LAUNCHCC3235MOD Key Features............................................................................ 6

1.1.3 What's Included ..................................................................................................... 6

1.1.4 Regulatory Compliance ........................................................................................... 6

1.1.5 First Steps: Out-of-Box Experience .............................................................................. 7

1.1.6 Next Steps: Looking into the Provided Code ................................................................... 7

1.2 Hardware ..................................................................................................................... 8

1.2.1 Block Diagram....................................................................................................... 9

1.2.2 Hardware Features................................................................................................ 11

1.2.3 BoosterPack Header Pin Assignment ......................................................................... 25

1.2.4 Electrical Characteristics ........................................................................................ 26

1.2.5 Antenna Characteristics ......................................................................................... 26

1.3 Layout Guidelines .......................................................................................................... 27

1.3.1 LAUNCHCC3235MOD Board Layout........................................................................... 27

1.3.2 General Layout Recommendations............................................................................. 31

1.3.3 RF Layout Recommendations .................................................................................. 31

1.3.4 Antenna Placement and Routing ............................................................................... 33

1.3.5 Transmission Line Considerations ............................................................................. 33

1.4 Operational Setup and Testing .......................................................................................... 35

1.4.1 Measuring the CC3235MOD Current Draw ................................................................... 35

1.4.2 RF Connections ................................................................................................... 36

1.4.3 Design Files ....................................................................................................... 37

1.4.4 Software ........................................................................................................... 37

1.5 Development Environment Requirements .............................................................................. 37

1.5.1 CCS................................................................................................................. 37

1.5.2 IAR .................................................................................................................. 37

1.6 Additional Resources ..................................................................................................... 38

1.6.1 CC3235MODx Product Page ................................................................................... 38

1.6.2 Download CCS, IAR ............................................................................................. 38

1.6.3 SimpleLink™ Academy for CC3235 SDK ..................................................................... 38

1.6.4 TI E2E Community ............................................................................................... 38

1.7 Assembly Drawing and Schematics .................................................................................... 39

1.7.1 Assembly Drawing ................................................................................................ 39

1.7.2 Schematics ........................................................................................................ 40

SWRU548–February 2019

CC3235MODSF LaunchPad™ Development Kit (LAUNCHCC3235MOD)

Chapter 1

SWRU548–February 2019

CC3235MODSF LaunchPad™ Development Kit

(LAUNCHCC3235MOD)

Start your design with the industry's first programmable FCC, IC/ISED, ETSI/CE, and MIC Certified

wireless microcontroller (MCU) module with built-in Dual-Band (2.4 GHz and 5 GHz) Wi-Fi®connectivity.

Created for the Internet-of-Things (IoT), the SimpleLink™ CC3235MODx family of devices from Texas

Instruments™ are wireless modules that integrate two physically separated, on-chip MCUs:

• An application processor – ARM®Cortex®-M4 MCU with a user-dedicated 256KB of RAM and an

optional 1MB of Serial Flash.

• A network processor MCU to run all Wi-Fi and Internet logic layers. This ROM based subsystem

includes an 802.11 a/b/g/n radio, baseband, and MAC with a powerful crypto engine for fast, secure

internet connections with 256-bit encryption.

The LAUNCHCC3235MODis a low-cost evaluation platform for MCUs based on ARM Cortex-M4 devices.

The LaunchPad™ design highlights the CC3235MODSF fully-integrated industrial module solution and

Dual-Band Wi-Fi capabilities. The LAUNCHCC3235MOD also features temperature and accelerometer

sensors, programmable user buttons, an RBG LED for custom applications, and onboard emulation for

debugging. The stackable headers interface demonstrates how easy it is to expand the functionality of the

LaunchPad when interfacing with other peripherals on existing BoosterPack™ add-on boards, such as

graphical displays, audio codec, antenna selection, environmental sensing, and more.

Figure 1-1 shows the CC3235MODSF LaunchPad development kit.

www.ti.com

4SWRU548–February 2019

Submit Documentation Feedback

CC3235MODSF LaunchPad™ Development Kit (LAUNCHCC3235MOD)

Figure 1-1. CC3235MODSF SimpleLinkTM Wi-Fi® LaunchPad Development Kit

www.ti.com

Introduction

SWRU548–February 2019

CC3235MODSF LaunchPad™ Development Kit (LAUNCHCC3235MOD)

1.1 Introduction

1.1.1 CC3235MODSF LaunchPad™

Created for the Internet of Things (IoT), the SimpleLink CC3235MODx is a wireless module with built-in

Dual-Band Wi-Fi connectivity for the LaunchPad ecosystem, which integrates a high-performance ARM

Cortex-M4 MCU and lets customers develop an entire application with one device. With on-chip Wi-Fi,

Internet, and robust security protocols, no prior Wi-Fi experience is required for fast development.

The CC3235MODSF LaunchPad, referred to by its part number LAUNCHCC3235MOD, is a low-cost

evaluation platform for ARM Cortex-M4-based MCUs. The LaunchPad design highlights the

CC3235MODSF Internet-on-a chip solution and Dual-Band Wi-Fi capabilities. The CC3235MODSF

LaunchPad also features temperature and accelerometer sensors, programmable user buttons, an RGB

LED for custom applications, and onboard emulation for debugging. The stackable headers of the

CC3235MODSF LaunchPad XL interface demonstrate how easy it is to expand the functionality of the

LaunchPad when interfacing with other peripherals on many existing BoosterPack add-on boards, such as

graphical displays, audio codecs, antenna selection, environmental sensing, and more. Figure 1-1 shows

the CC3235MOD LaunchPad.

Multiple development environment tools are also available, including TI’s Eclipse-based Code Composer

Studio™ (CCS) integrated development environment (IDE) and IAR Embedded Workbench®. More

information about the LaunchPad, the supported BoosterPack modules, and the available resources can

be found at TI’s LaunchPad portal.

NOTE: The maximum RF power transmitted in each WLAN 2.4 GHz band is 22 dBm (EIRP power).

The maximum RF power transmitted in each WLAN 5 GHz band is 23 dBm (EIRP power).

NOTE: The antennas used for this transmitter must be installed to provide a separation distance of

at least 20 cm from all persons, and must not be colocated or operating in conjunction with

any other antenna or transmitter.

Introduction

www.ti.com

6SWRU548–February 2019

Submit Documentation Feedback

CC3235MODSF LaunchPad™ Development Kit (LAUNCHCC3235MOD)

1.1.2 LAUNCHCC3235MOD Key Features

The LAUNCHCC3235MOD SimpleLink LaunchPad includes the following features:

• CC3235MODSF, SimpleLinkTM Dual-Band Wi-Fi®module solution

– Integrated MCU

– 40.0-MHz Crystal

– 32.768-kHz Crystal (RTC)

– 32-Mbit SPI Serial Flash

– RF and Full Power-Management Components

• 40-pin LaunchPad standard that leverages the BoosterPack ecosystem

• TI standard, XDS110-based JTAG emulation with serial port for flash programming

• Supports 4-wire JTAG and 2-wire SWD

• Two buttons and one RGB LED for user interaction

• Back-channel universal asynchronous receiver/transmitter (UART) through USB to PC

• Onboard chip antenna with U.FL for conducted testing selectable using 0-Ωresistors

• Onboard accelerometer and temperature sensor for out-of-box demo with option to isolate the sensors

from the inter-integrated circuit (I2C) bus

• Micro-USB connector for power and debug connections

• Headers for current measurement and external JTAG connection (option to use the onboard XDS110

to debug customer platforms)

• Bus-powered device with no external power required for Wi-Fi

• Long-range transmission with highly optimized antenna (200 m typical in open air using an access

point with 6-dBi antenna AP)

• Can be powered externally, with two AA or two AAA alkaline batteries working down to 2.3-V typical

• Dimensions: 106.1 mm (L) × 58.42 mm (W)

1.1.3 What's Included

1.1.3.1 Kit Contents

• CC3235MODSF LaunchPad development tool (LAUNCHCC3235MOD)

• Micro USB cable

• Quick start guide

1.1.3.2 Software Examples

• Out-of-Box Experience (OOBE) Software

1.1.4 Regulatory Compliance

Certifications in Process

Indoor Usage Restrictions:

The device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency range.

AT BE BG HR CY CZ DK

EE FI FR DE EL HU IE

IT LV LT LU MT NL PL

PT RO SK SI ES SE UK

www.ti.com

Introduction

SWRU548–February 2019

CC3235MODSF LaunchPad™ Development Kit (LAUNCHCC3235MOD)

1.1.5 First Steps: Out-of-Box Experience

An easy way to get started with the EVM is by using its preprogrammed out-of-box experience code. It

demonstrates some key features of the EVM.

1.1.5.1 Connecting to the Computer

Connect the LaunchPad development kit by connecting the included USB cable to a computer. A red

power LED should illuminate. For proper operation, the SimpleLink drivers and Service Pack from the

CC3235 Software Development Kit (SDK) are needed. The SDK is available at

http://www.ti.com/tool/simplelink-cc32xx-sdk.

1.1.5.2 Running the Out-of-Box Experience

The CC3235MODSF LaunchPad development kit's Out-of-Box Experience (OOBE) demonstrates and

highlights the following features:

• Easy connection to the CC3235MODSF LaunchPad:

– Using the SimpleLinkTM Wi-Fi® Starter Pro application (available on iOS and Android™), users can

use Access Point (AP) provisioning or SmartConfig™ provisioning for a fast CC3235MOD

connection.

– Configuring the device in AP mode gives users a direct connection to the CC3235MODSF

LaunchPad.

Once the device is provisioned and connected to an AP in station mode, the profile is stored on the

local file system so that any reset to the CC3235MODSF automatically connects it to the AP.

• Easy access to the CC3235MODSF through its internal web server, using either:

– The SimpleLinkTM Wi-Fi® Starter Pro application

– Any browser; web pages stored on the serial flash are loaded on the browser, to provide ease of

use.

This feature demonstrates configuring and reading onboard sensors.

• Over-The-Air (OTA) updates that demonstrate an update of a full image. OTA service enables in-

system updates of the MCU application, CC3235 firmware releases (Service Pack) made available by

TI, and other vendor files. An update procedure executed in a full-system integrity fashion, such as

failure to upgrade any image components, results in rolling back to the previous valid version.

1.1.6 Next Steps: Looking into the Provided Code

After the EVM features have been explored, the user can open an integrated development environment

and start editing the code examples from the SDK. See Section 1.6.2 for available IDEs and where to

download them. The Out-of-Box source code and more code examples are provided in the CC3235 SDK.

Code is licensed under BSD, and TI encourages reuse and modifications to fit specific needs.

With the onboard XDS110 debug probe, debugging and downloading new code is simple. A USB

connection between the EVM and a PC through the provided USB cable is all that is needed.

Hardware

www.ti.com

8SWRU548–February 2019

Submit Documentation Feedback

CC3235MODSF LaunchPad™ Development Kit (LAUNCHCC3235MOD)

1.2 Hardware

Figure 1-2 shows the CC3235MODSF LaunchPad EVM.

Figure 1-2. CC3235MODSF LaunchPad™ EVM Overview

CC3235

MAC/PHY

WRF_BGN F

BGN

RF_ANT1

32-Mbit

SFlash

External SPI

Programming

40 MHz

32.768 kHz

UART

SPI

nReset

2.3 V to 3.6 V

VBAT

User GPIOx

Aband

5 GHz

SPDT

WRF_A

www.ti.com

Hardware

SWRU548–February 2019

CC3235MODSF LaunchPad™ Development Kit (LAUNCHCC3235MOD)

1.2.1 Block Diagram

Figure 1-3 shows a functional block diagram of the CC3235MODx module.

Figure 1-3. CC3235MODx Functional Block Diagram

CC3235MODSF12MOBR

Acc

BMA280

Temperature

Sensor

TMP116

Two 20-pin LaunchPad headers

(compatible with TI MCU standard)

INT (GPIO13)

I2C

FTDI

FT2232D

and

SWD Circuit

USB

Connector

LDO

3.3 V VCC

Two AA

Battery

Connectors

Reverse

Protection

Push buttons

GPIO13, GPIO22 RGB LED

GPIO9, GPIO10, GPIO11

JTAG and SWD

UART (Flashing)

Hardware

www.ti.com

10 SWRU548–February 2019

Submit Documentation Feedback

CC3235MODSF LaunchPad™ Development Kit (LAUNCHCC3235MOD)

Figure 1-4 shows a functional block diagram of the LAUNCHCC3235MOD SimpleLink LaunchPad.

Figure 1-4. LAUNCHCC3235MOD Functional Block Diagram

Otros manuales para CC3235MODSF SimpleLink

Tabla de contenidos

Otros manuales de Microcontrolador de Texas Instruments

Texas Instruments

Texas Instruments CC3220 Manual de usuario

Texas Instruments

Texas Instruments Delfino TMS320F28377D controlCARD Manual técnico

Texas Instruments

Texas Instruments TLC2543 Manual de usuario

Texas Instruments

Texas Instruments CC2431ZDK Manual de usuario

Texas Instruments

Texas Instruments Hercules TMS570LS31 Manual de usuario

Texas Instruments

Texas Instruments CC2510 Manual de programación

Texas Instruments

Texas Instruments MSPM0L1306 Manual de usuario

Texas Instruments

Texas Instruments Hercules TMS570LS31x Manual de usuario

Texas Instruments

Texas Instruments F280025C Manual de usuario

Texas Instruments

Texas Instruments MSP430F4152IPM Manual de usuario

Texas Instruments

Texas Instruments Errata MSP430FG6426 Manual de usuario

Texas Instruments

Texas Instruments TMS570LS0 32 Series Manual de usuario

Texas Instruments

Texas Instruments Chipcon Products CC2400DK Manual de programación

Texas Instruments

Texas Instruments CC3235 SimpleLink Series Manual de usuario

Texas Instruments

Texas Instruments Chipcon CC2430 Manual de usuario

Texas Instruments

Texas Instruments MSP430 series Manual de usuario

Texas Instruments

Texas Instruments Chipcon Products CC1110DK Manual de programación

Texas Instruments

Texas Instruments Tiva TM4C123GH6PM Manual de usuario

Texas Instruments

Texas Instruments 430BOOST-SENSE1 Manual de usuario

Texas Instruments

Texas Instruments MSP430F67471 Manual de usuario

Texas Instruments

Texas Instruments TIDA-00830 Manual de usuario

Texas Instruments

Texas Instruments AFE4403 Manual de usuario

Texas Instruments

Texas Instruments CC3220 Manual de usuario

Texas Instruments

Texas Instruments MSP430 series Manual de usuario

Manuales populares de Microcontrolador de otras marcas

AMS

AMS AS7261 Demo Kit Manual de usuario

Novatek

Novatek NT6861 Manual de usuario

Espressif Systems

Espressif Systems ESP8266 SDK Guía de configuración

Nuvoton

Nuvoton ISD61S00 ChipCorder Guía

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manual de usuario

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manual de usuario

NEC

NEC 78GK0S/K 1+ Series Instrucciones de instalación y funcionamiento

Mikroe

Mikroe SEMITECH N-PLC Click Instrucciones de instalación y funcionamiento

Intel

Intel Agilex Manual de usuario

Cypress

Cypress CY4607 HX2VL Manual de usuario

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manual de usuario

CYPRES

CYPRES CY14NVSRAMKIT-001 Manual de usuario

Espressif Systems

Espressif Systems ESP8266EX Instrucciones de funcionamiento

Abov

Abov AC33M8128L Manual de usuario

Laird

Laird BL654PA Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F800 Manual de usuario

Energy micro

Energy micro EFM32 Giant Gecko Starter Kit Manual de usuario

Mikroe

Mikroe click Proximity 2 Manual de usuario
