TI-Innovator™ Hub with

TI LaunchPad™ Board

Getting Started Guide

Learn more about TI Technology through the online help at education.ti.com/eguide.

Important Information

Except as otherwise expressly stated in the License that accompanies a program, Texas

Instruments makes no warranty, either express or implied, including but not limited to

any implied warranties of merchantability and fitness for a particular purpose,

regarding any programs or book materials and makes such materials available solely

on an "as-is" basis. In no event shall Texas Instruments be liable to anyone for special,

collateral, incidental, or consequential damages in connection with or arising out of the

purchase or use of these materials, and the sole and exclusive liability of Texas

Instruments, regardless of the form of action, shall not exceed the amount set forth in

the license for the program. Moreover, Texas Instruments shall not be liable for any

claim of any kind whatsoever against the use of these materials by any other party.

Learning More with the TI-Innovator™ Technology eGuide

Parts of this document refer you to the TI-Innovator™ Technology eGuide for more

details. The eGuide is a Web-based source of TI-Innovator™ information, including:

• Programming with the TI CE Family of Graphing Calculators and

TI-Nspire™Technology, including sample programs.

• Available I/O Modules and their commands.

• Available breadboard components and their commands.

• Available TI-RGB Array and its commands.

• Available TI-Innovator™ Rover and its commands.

• Link to update the TI-Innovator™ Sketch software.

• Free classroom activities for TI-Innovator™Hub.

https://education.ti.com/go/eguide/hub/EN

Apple®, Chrome®, Excel®, Google®, Firefox®, Internet Explorer®, Mac®, Microsoft®,

Mozilla®, Safari®, and Windows® are registered trademarks of their respective owners.

QR Codeëis a registered trademark of DENSO WAVE INCORPORATED.

Select images were created with Fritzing.

Actual products may vary slightly from provided images.

Contents

TI-Innovator™ Hub Overview 1

Learn More 1

What's in the Box 2

TI-Innovator™Hub with On-Board Components 2

Built-in Ports 2

USB Cables 3

Auxiliary Power 3

Connecting TI-Innovator™Hub 3

Connecting to a Graphing Calculator 4

Connecting to a Computer Running TI-Nspire™CX Software 5

Updating the Hub Software 5

What is the TI-Innovator™ sketch? 5

Do I need to update the sketch on the TI-Innovator™ Hub? 5

What is the latest version of the sketch? 6

Why would I update the sketch? 6

How do I load the sketch on the TI-Innovator™ Hub? 6

Can I update multiple TI-Innovator Hubs at the same time? 6

Can the sketch that comes on the TI-Innovator™ Hub be edited to add

functionality but still work with the TI calculator? Is the sketch open source? 6

Hub Programming on TI CE Graphing Calculator 7

Code Examples: TI CE Graphing Calculator 7

Sample Program to Blink an On-Board LED 7

How to Create and Execute a Program 8

Using the Hub Menu to Build Commands 9

Tips for Coding with TI CE Graphing Calculator 10

Learn More 11

TI-Innovator™ Hub App for the TI CE Graphing Calculator(s) 12

Hub Programming on TI-Nspire™CX Technology 15

Code Examples: TI-Nspire™CX Technology 15

Sample Program to Blink an On-Board LED 15

How to Create and Execute a Program 16

Using the Hub Menu to Build Commands 17

Tips for Coding with TI-Nspire™CX Technology 18

Learn More 19

TI-Innovator™ I/O Modules 20

Connecting an I/O Module 22

Sample Program to Blink an LED Module 22

Learn More 22

TI-Innovator™ Breadboard Pack 24

Addressable Components 24

Sample Code to Blink a Breadboard LED 25

iii

Breadboard Basics 26

Learn More 27

Using an Auxiliary Power Source 27

Connecting the Power Source 28

TI-Innovator™ Hub Troubleshooting 29

TI-RGB Array 31

What is TI-RGB Array? 31

TI-RGB Array – Industrial design and markings 31

Requirements for TI-RGB Array: 32

Connecting the TI-RGB Array 32

Connect the TI-RGB Array to the TI-Innovator™ Hub 32

Connect the TI-Innovator™ Hub to a Graphing Calculator 33

Connecting TI-Innovator™Hub 33

Connecting to a Graphing Calculator 33

Connecting to a Computer Running TI-Nspire™CX Software 34

TI-RGB Array Commands 35

Prerequisite: Use the Send "Connect RGB" Command First 35

CONNECT RGB 35

SET RGB 36

SET RGB ALL 37

READ RGB 37

General Precautions 38

TI-RGB Array 38

General Precautions for the TI-Innovator™ Hub 38

TI-Innovator™Hub 38

Breadboard Connector on the Hub 38

Breadboard 38

I/O Modules 39

TI-Innovator™Rover 39

General Information 41

Online Help 41

Contact TI Support 41

Service and Warranty 41

TI-Innovator™ Hub Overview

The TI-Innovator™Hub lets you use your compatible TI graphing calculator or

TI-Nspire™CX computer software to control components, read sensors, and create

powerful learning experiences.

• You communicate with the Hub through TI Basic programming commands.

• Hosts that are compatible with TI-Innovator™Hub include:

- TI CE Family of Graphing Calculators (TI-83 Premium CE, TI-84 Plus CE, and

TI-84 Plus CE-T) with operating system version 5.3 or later installed. You also

need to install or update the Hub App, which contains the Hub menu.

- TI Nspire™ CX or TI Nspire™ CX CAS handheld with operating system version 4.5

or later installed

- TI Nspire™ computer software version 4.5 or later

•TI-Innovator™Hub. Communicates with the host, the Hub on-board components,

and connected external components. It also distributes power to external

components.

•TI-Innovator™ Components. These components, sold separately, include sensors,

motors, and LEDs that connect to the Hub through its I/O ports and breadboard

connector.

Learn More

For a list of precautions to take while using the Hub and its components, refer to

General Precautions (page 38).

To find information on accessories, external modules, and breadboard components,

visit education.ti.com/go/innovator.

What's in the Box

TI-Innovator™Hub with On-Board

Components

ÀA Light Brightness Sensor at the bottom

of the Hub can be read as

"BRIGHTNESS" in Hub command strings.

ÁRed LED is addressable as "LIGHT" in

Hub command strings.

ÂSpeaker (at back of Hub, not shown) is

addressable as "SOUND" in Hub

command strings.

ÃRed-Green-Blue LED is addressable as

"COLOR" in Hub command strings.

Also visible on the face of the Hub are:

AGreen auxiliary power LED

BGreen power LED,

CRed error LED.

Built-in Ports

Left side-Three ports for collecting data or status

from input modules:

•IN1 and IN2 provide 3.3V power.

•IN3 provides 5V power.

Right side-Three ports for controlling output

modules:

•OUT1 and OUT2 provide 3.3V power.

•OUT3 provides 5V power.

Bottom-Light Brightness Sensor (described earlier)

and two ports:

•I2Cport connects to peripherals that use the I2C

communication protocol.

•DATAMini-B port, used with the appropriate

cable, connects to a compatible graphing

calculator or computer for data and power.

Top-Two connectors:

• USB-Micro connector (PWR) for auxiliary power

required by some components. Also used for

updating the Hub internal software.

• Breadboard Connector with 20 labeled pins for

communication with connected components. A

breadboard and jumper cables are included with

the TI-Innovator™ Breadboard Pack, sold

separately.

USB Cables

ÀUSB Unit-to-Unit (Mini-A to Mini-B)-Connects the Hub to a TI CE Graphing

Calculator or a TI-Nspire™CX Handheld.

ÁUSB Standard A to Mini-B-Connects the Hub to a computer running

TI-Nspire™CXSoftware.

ÂUSB Standard A to Micro-Connects the PWR port of the Hub to a TI approved

power source required by some peripherals.

Auxiliary Power

TIWallCharger - Supplies power through the

TI-Innovator™Hub for components, such as motors,

that require additional power.

The optional External Battery Pack can also provide

auxiliary power.

Note: An auxiliary power LED on the Hub indicates

when the Hub is receiving auxiliary power.

Connecting TI-Innovator™Hub

The TI-Innovator™Hub connects by a USB cable to a graphing calculator or computer.

The connection lets the Hub receive power and exchange data with the host.

Note: Some peripherals, such as motors, may require auxiliary power. For more

information, see Using an Auxiliary Power Source (page 27).

Connecting to a Graphing Calculator

1. Identify the "B" connector on the USB Unit-to-Unit (Mini-A

to Mini-B) cable. Each end of this cable is embossed with

a letter.

2. Insert the "B" connector into the DATA port at the bottom

of the TI-Innovator™Hub.

3. Insert the free end of the cable (the "A" connector) into the USB port on the

calculator.

Hub connected to

TI CE Graphing Calculator

Hub connected to

TI-Nspire™CX Handheld

4. Turn on the calculator if it is not already on.

The power LED on the Hub glows green to show that it is receiving power.

Connecting to a Computer Running TI-Nspire™CX Software

1. Identify the "B" connector on

the USB Standard A to Mini-B

cable for Windows®/Mac®.

Each end of this cable is

embossed with a letter.

2. Insert the "B" connector into

the DATA port at the bottom

of the TI-Innovator™Hub.

3. Insert the free end of the

cable (the "A" connector) into

a USB port on the computer.

The power LED on the Hub

glows green to show that it is

receiving power.

Updating the Hub Software

The TI-Innovator™Hub contains software, TI-Innovator™ Sketch, that interprets Hub

commands and communicates with on-board devices and connected modules. A Web-

based tool lets you update the Sketch. Updated versions contain bug fixes and ensure

that your TI-Innovator™Hub can communicate with the latest components.

To obtain the latest version of the TI-Innovator™ Sketch go to the following site:

https://education.ti.com/go/innovator

Questions About the Hub Software

What is the TI-Innovator™ sketch?

The ‘sketch’ is the software on the TI-Innovator™ Hub that communicates with the

graphing calculator, processes the commands, and controls the external components.

Do I need to update the sketch on the TI-Innovator™ Hub?

For best results always use the latest version of TI-Innovator™ sketch. To stay informed

on any updates to the TI-Innovator™ Hub, make sure you register your product at

education.ti.com/register or check the TI-Innovator™ website at

education.ti.com/go/innovator.

What is the latest version of the sketch?

For best results always use the latest version of TI-Innovator sketch. You can always

find the latest version of the sketch at education.ti.com/go/innovator.

Why would I update the sketch?

There are a couple of different reasons to upgrade the sketch.

1. To get the latest version from TI that may include new functionality.

2. To restore the TI sketch after loading a custom sketch – This is only needed by

advanced users who use an alternative sketch.

How do I load the sketch on the TI-Innovator™ Hub?

The sketch can be updated through the TI-Innovator Hub Update Software. This

software is a free download on the TI website.

Can I update multiple TI-Innovator Hubs at the same time?

The TI-Innovator Hub Update Software only allows updating a single Hub at a time.

However, the application is designed to allow you to update multiple Hubs without

having to re-launch the software.

Can the sketch that comes on the TI-Innovator™ Hub be edited to add functionality but

still work with the TI calculator? Is the sketch open source?

The code for sketch that is loaded on the TI-Innovator™ has not been published for

others to modify or edit. To maintain compatibility between the TI-Innovator™ Hub and

TI calculator products, only use the officially published sketch for TI-Innovator™ Hub.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Microcontrolador de Texas Instruments

Texas Instruments

Texas Instruments CC3235MODSF SimpleLink Manual de usuario

Texas Instruments

Texas Instruments MSP430F6735A Manual de usuario

Texas Instruments

Texas Instruments MSP430x4xx Family Manual de usuario

Texas Instruments

Texas Instruments SWRU351 Manual de usuario

Texas Instruments

Texas Instruments MSP430 series Manual de usuario

Texas Instruments

Texas Instruments Hercules RM48 Manual de usuario

Texas Instruments

Texas Instruments CC2540 Manual de usuario

Texas Instruments

Texas Instruments TMS570LS0 32 Series Manual de usuario

Texas Instruments

Texas Instruments CC3220 Manual de usuario

Texas Instruments

Texas Instruments PGA460-Q1 Manual de usuario

Texas Instruments

Texas Instruments Silicon Errata TMS320F28379S Manual de usuario

Texas Instruments

Texas Instruments TM4C1294NCPDT Manual de usuario

Texas Instruments

Texas Instruments Chipcon CC2420DK Manual de usuario

Texas Instruments

Texas Instruments MSP-EXPCC430RF Series Manual de usuario

Texas Instruments

Texas Instruments SimpleLink Ethernet MSP432E401Y Manual de usuario

Texas Instruments

Texas Instruments MSP430F563x Manual de usuario

Texas Instruments

Texas Instruments TMS320F2837 D Series Manual de usuario

Texas Instruments

Texas Instruments MSP43 series Manual de usuario

Texas Instruments

Texas Instruments C2000 Piccolo LaunchPad Guía de instalación

Texas Instruments

Texas Instruments CC2531 Manual de usuario

Texas Instruments

Texas Instruments LaunchPad LP-CC1352P7-1 Manual de usuario

Texas Instruments

Texas Instruments LaunchPad MSP-EXP430FR5994 Manual de usuario

Texas Instruments

Texas Instruments DRV8251/AEVM Manual de usuario

Texas Instruments

Texas Instruments CC2520EM Manual de usuario

Manuales populares de Microcontrolador de otras marcas

AMS

AMS AS7261 Demo Kit Manual de usuario

Novatek

Novatek NT6861 Manual de usuario

Espressif Systems

Espressif Systems ESP8266 SDK Guía de configuración

Nuvoton

Nuvoton ISD61S00 ChipCorder Guía

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manual de usuario

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manual de usuario

NEC

NEC 78GK0S/K 1+ Series Instrucciones de instalación y funcionamiento

Mikroe

Mikroe SEMITECH N-PLC Click Instrucciones de instalación y funcionamiento

Intel

Intel Agilex Manual de usuario

Cypress

Cypress CY4607 HX2VL Manual de usuario

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manual de usuario

CYPRES

CYPRES CY14NVSRAMKIT-001 Manual de usuario

Espressif Systems

Espressif Systems ESP8266EX Instrucciones de funcionamiento

Abov

Abov AC33M8128L Manual de usuario

Laird

Laird BL654PA Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F800 Manual de usuario

Energy micro

Energy micro EFM32 Giant Gecko Starter Kit Manual de usuario

Mikroe

Mikroe click Proximity 2 Manual de usuario
