Read This First

Preface

About This Manual

This user’s guide describes the TPS793xxEVM LDO regulator evaluation

module (SLVP191). Each EVM package contains one SLVP191 test board,

with either a TPS79301DBV linear regulator or a TPS79328DBV linear

regulator,aswellassupportingpassivecomponents.TheSLVP191testboard

providesaconvenientmethodofevaluatingtheperformanceoftheTPS793xx

linear regulator family as well as other SOT–23 packaged linear regulators

with the same pinout.

How to Use This Manual

-Chapter 1—Introduction

-Chapter 2—EVM Test Setup

-Chapter 3—Test Results

Related Documentation From Texas Instruments

-TPS793xx data sheet (literature number SLVS348)

Running Title—Attribute Reference

vii

Contents

1 Introduction 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.1 TPS793xx Family of LDO Regulators 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 EVM Design Strategy 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 Schematic 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.4 Bill of Materials 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.5 Board Layout 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 EVM Test Setup 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Test Results 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figures

1–1 TPS79301 Board Schematic 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1–2 TPS79328 Board Schematic 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1–3 Top Layer 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1–4 Bottom Layer 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1–5 Assembly Drawing—Top 1-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–1 Recommended TPS793xxEVM Test Setup 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–1 Line Transient Response 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–2 Ripple Rejection 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Tables

1–1 SLVP191 Bill of Materials 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

viii

1-1

Introduction

This user’s guide describes the TPS793xxEVM LDO regulator evaluation

module (SLVP191). Each EVM package contains one SLVP191 test board,

with either a TPS79301DBV linear regulator or a TPS79328DBV linear

regulator, as well as supporting passive components.

Topic Page

1.1 TPS793xx Family of LDO Regulators 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 EVM Design Strategy 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 Schematic 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.4 Bill of Materials 1–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.5 Board Layout 1–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 1

TPS793xx Family of LDO Regulators

1-2 Introduction

1.1 TPS793xx Family of LDO Regulators

Like all LDO linear regulators, the TPS793xx family of LDO regulators use a

series pass element and feedback network, including an error amplifier and

voltagereference, to providea regulated outputvoltage from aslightly higher,

possibly varying input voltage. However, these regulators have been

optimized to reduce ripple and noise on the output. For example, advanced

feedbackcompensationtechniqueswereusedtoincreasethebandwidthand

open loop gain of the feedback network while maintaining stability with any

2.2-µFceramiccapacitor.SincePSRRisdirectlyproportionaltothefrequency

response of the loop of the error amplifier, these regulators’higher loop gain

and larger bandwidth result in better PSRR over a wider range of frequencies

than standard regulators. In addition to circuit design optimization to reduce

circuitnoise,theprimarycontributortothenoiseofany regulator,thebandgap

reference, has been pinned out to allow further noise reduction through the

use of a filtering capacitor. Capabilities of this regulator include:

-200-mA load current

-TPS793xx family is available in 1.8-V, 2.5 V, 2.8 V, 2.85 V, 3.0 V, 3.3-V,

4.75-V, and adjustable with positive ENABLE.

-PSRR of 75 dB at 10 kHz

-Approximately 30-µV output noise

-Start-up in approximately 60 µs

-Excellent line and load transient responses

-Very low dropout voltage

-5-Pin SOT23 (DBV) package to minimize board space consumption

1.2 EVM Design Strategy

The purpose of this EVM is to facilitate evaluation of the TPS793xx family of

LDO regulators. Each EVM package contains one SLVP191 test board, with

either a TPS79301DBV linear regulator or a TPS79328DBV linear regulator,

as well as supporting passive components. The TPS79301DBV adjustable

device has been configured to provide 1.5-V output, and the TPS79328DBV

provides a 2.8-V output. The board’s small size and side clips facilitate

attaching it to other PCBs as a power module.

The board has additional passive components that can be configured to test

other SOT–23 packaged regulators with the same pin-out.
