GH5200 First Start

From Wiki Knowledge Base | Teltonika Mobility

Main Page > Personal Trackers > GH5200 > GH5200 First Start

GH5200 is an autonomous personal tracker for lone worker protection.

Contents

1 Know your device

2 Set up your device

2.1 How to insert Micro SIM card and connect the battery

2.2 PC Connection (Windows)

2.3 How to install USB drivers (Windows)

2.4 Conguration (Windows)

2.5 Quick SMS conguration

3 Safety information

3.1 Precautions

Saltoniškių g. 9B-1,

LT-08105 Vilnius

Tel. +370 5 212 7472

Faks. +370 5 276 1380

www.teltonika-iot-group.com

[email protected]

Know your device

Saltoniškių g. 9B-1,

LT-08105 Vilnius

Tel. +370 5 212 7472

Faks. +370 5 276 1380

www.teltonika-iot-group.com

[email protected]

Set up your device

How to insert Micro SIM card and connect the battery

1. Remove the cover.

2. Insert Micro-SIM card as shown with PIN request disabled. Make sure that Micro-SIM card cut-o corner is pointing forward to slot.

3. Insert the battery as shown to device. Position the battery in place where it does not obstruct other components.

4. Reattach the cover and tighten the screw.

Saltoniškių g. 9B-1,

LT-08105 Vilnius

Tel. +370 5 212 7472

Faks. +370 5 276 1380

www.teltonika-iot-group.com

[email protected]

Micro-SIM card insertion/removal must be performed when device is powered o and battery is disconnected. Otherwise Micro-SIM

card might be damaged or device will not detect it.

PC Connection (Windows)

1. Turn on your device by holding the power button for around 7 seconds.

2. Connect device to computer using Micro-USB cable or Bluetooth connection:

Using Micro-USB cable

– You will need to install USB drivers, see “How to install USB drivers (Windows)” shown below.

Using Bluetooth

Saltoniškių g. 9B-1,

LT-08105 Vilnius

Tel. +370 5 212 7472

Faks. +370 5 276 1380

www.teltonika-iot-group.com

[email protected]

– GH5200 Bluetooth is enabled by default. Turn on Bluetooth on your PC, then select Add Bluetooth or other device > Bluetooth. Choose your

device named – “GH5200_last_7_imei_digits”, without LE in the end. Enter default password 5555, press Connect and then select Done.

3. You are now ready to use the device on your computer.

How to install USB drivers (Windows)

1. Please download COM port drivers from here. here (https://teltonika-gps.com/downloads/en/fmb120/TeltonikaCOMDriver.zip).

2. Extract and run TeltonikaCOMDriver.exe.

3. Click Next in driver installation window.

4. In the following window click Install button. Setup will continue installing the driver and eventually the conrmation window will appear. Click

Finish to complete the setup.

Conguration (Windows)

At rst GH5200 device will have default factory settings set. These settings should be changed according to the user's needs.

Main conguration can be performed via Teltonika Congurator software. Congurator operates on Microsoft Windows OS and uses

prerequisite MS .NET Framework. Make sure you have the correct version installed.

Saltoniškių g. 9B-1,

LT-08105 Vilnius

Tel. +370 5 212 7472

Faks. +370 5 276 1380

www.teltonika-iot-group.com

[email protected]

MS .NET requirements

Operating system MS .NET Framework

version Version Link

Windows

Vista

Windows 7

Windows

8.1

Windows 10

MS .NET Framework 4.6.2 32 and 64

bit

www.microsoft.com

(https://dotnet.micro

soft.com/en-us/down

load/dotnet-framewo

rk)

Downloaded Congurator will be in compressed archive. Extract it and launch Congurator.exe. After launch software language can be changed

by clicking in the right bottom corner:

Conguration process begins by pressing on connected device:

After connection to Congurator Status window will be displayed:

Saltoniškių g. 9B-1,

LT-08105 Vilnius

Tel. +370 5 212 7472

Faks. +370 5 276 1380

www.teltonika-iot-group.com

[email protected]

Saltoniškių g. 9B-1,

LT-08105 Vilnius

Tel. +370 5 212 7472

Faks. +370 5 276 1380

www.teltonika-iot-group.com

[email protected]

Various Status info tabs display information about GNSS, GSM, I/O, Maintenance and etc. GH5200 has one user editable prole, which can be

loaded and saved to the device. After any modication of conguration the changes need to be saved to device using Save to device button.

Main buttons oer following functionality:

1. Load from device – loads conguration from device.

2. Save to device – saves conguration to device.

3. Load from le – loads conguration from le.

4. Save to le – saves conguration to le.

5. Update rmware – updates rmware on device.

6. Read records – read records from device.

7. Reboot device – restarts device.

8. Reset conguration – sets device conguration to default.

Most important congurator section is GPRS – where all your server and GPRS settings can be congured and Data acquisition – where data

acquiring parameters can be congured. More details about GH5200 conguration using Congurator can be found here.

Quick SMS conguration

Default conguration has optimal parameters present to ensure best performance of track quality and data usage.

Quickly set up your device by sending this SMS command to it:

" setparam 2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0"

GPRS settings:

2001 – APN

2002 – APN username (if there are no APN username, empty eld

should be left)

2003 – APN password (if there are no APN password, empty eld

should be left)

Server settings:

2004 – Domain

2005 – Port

Saltoniškių g. 9B-1,

LT-08105 Vilnius

Tel. +370 5 212 7472

Faks. +370 5 276 1380

www.teltonika-iot-group.com

[email protected]

Note: Before SMS text, two space symbols should be inserted.

Default conguration settings

Movement detection:

Device movement will be detected

by accelerometer

Device makes a record On Moving if one of these events happen:

300 seconds passes

Angle dierence between last coordinate

and current position is greater than 10°

degrees

Traveled distance is more than 100

meters

Speed dierence between last coordinate

and current position is greater than 10

km/h

Device makes a record On Stop if:

1 hour passes while device is

stationary

Records sending to server:

If device has made a record it is sent

to the server every 120 seconds

After successful SMS conguration, GH5200 device will synchronize time and update records to congured server.

2006 – Data sending protocol (0 – TCP, 1 – UDP)

Saltoniškių g. 9B-1,

LT-08105 Vilnius

Tel. +370 5 212 7472

Faks. +370 5 276 1380

www.teltonika-iot-group.com

[email protected]

Safety information

This message contains information on how to operate GH5200 safely. By following these requirements and recommendations, you will avoid

dangerous situations. You must read these instructions carefully and follow them strictly before operating the device!

Precautions
