Speed Limiting Solution FMC130+ETC

Main Page > General Information > Usage scenarios > Speed Limiting Solution > Speed Limiting Solution

FMC130+ETC

Contents

1 Introduction

2 Solution description

3 What you need for a solution?

4 Installation

4.1 A. Installation - Electronic Throttle Controller

4.2 B. Installation - Fuel Pump

4.3 C. Installation - Solenoid Valve

5 Wiring Scheme

5.1 Relay Wiring Scheme

5.2 ETC Wiring Scheme

6 Configuration

6.1 1. Prerequisites:

6.1.1 1.1. Read through First start guide

6.1.2 1.2. Understanding of possible Sleep modes.

6.2 2. Configuration - Speed limiting:

6.3 3. Configuration - Speed Limiting based on Geo-Fence

7 Parsing information

7.1 1.Prerequisites:

7.1.1 1.1. Open TCP/UDP port

7.1.2 1.2. Read Java parser first start guide

7.2 2. Parsing example:

8 Demonstration in Wialon platform

9 Conclusion

Introduction

The loss incurred globally by corporate fleet and insurance businesses due to accidents caused by

over speeding is significant. This can often lead to the loss in productivity and multiple other evident

collateral damage costs. We at Teltonika Telematics have developed a unique solution to help tackle

over speeding in the fleet.

Solution description

Using the combination of Teltonika FM device with the Automotive relay and the Electronic throttle

controller to achieve speed limiter feature.

What you need for a solution?

FMC130 device

Electronic Throttle Controller

Automotive Relay

The SIM card in order to get data to your server

FOTA WEB to remotely send the configuration to the device.

*Solenoid Valve

*Solenoid Valve is optional for one of the wiring schemes shown below

Installation

This solution can be implemented in 3 different ways based on the speed limiting scenario. It’s

important to install the device and the relay in an hidden place inside dashboard.

Although devices have high gain antennas it’s important to mount devices with stickers on top and in

metal-free space. The device should be firmly fixed to the surface or cables. Please make sure, that

device is not fixed to heat emitting or moving parts.

To have a working solution it’s important to properly wire the devices. In the picture below it's

shown how to correctly wire the device when implementing electronic throttle controller solution.

There are 3 ways of connecting the FM device which are displayed below:

A. Installation - Electronic Throttle Controller

B. Installation - Fuel Pump

C. Installation - Solenoid Valve

Wiring Scheme

Relay Wiring Scheme

Relay PIN Relay cable color Connection

30 Blue +VDC (Common connection to NO & NC terminals)

85 Black DOUT of FM Device

86 White +VDC (Coil)

87 Yellow Not Required to connect (Normally Open (NO))

87a Red Green Wire from ETC or Wire to Fuel Pump or Wire

to Solenoid Valve

ETC Wiring Scheme

ETC cable color Connection

Red +VDC (+10...32)

Black Ground

Green PIN 87a (NC of Relay)

White V-/0.40V from Accelerator pedal

Brown V+/0.70V from Accelerator Pedal

Yellow S+/0.70V from ECU

Grey S-/0.40V from ECU

Note: Voltage may vary depending on vehicle model.

During installation please follow recommendations in order to avoid damaging device and vehicle:

while the connecting the wires, please ensure the module is not plugged IN.

Ensure the car ECU falls asleep, measure voltage on the chosen wire if it is still available. It

usually takes 5 to 30 minutes period for the ECU to completely shutdown depending on the

model of the vehicle.

When the module is connected, be sure to measure the voltage again if it did not decrease.

The ground wire is connected to the vehicle frame or metal parts that are fixed to the frame.

Configuration

1. Prerequisites:

1.1. Read through First start guide

1.2. Understanding of possible Sleep modes.

2. Configuration - Speed limiting:

Parameter ID – Parameter name GPRS settings:

2001 – APN

2002 – APN username (if there are no APN username, empty field should be left)

2003 – APN password (if there are no APN password, empty field should be left)

Server settings:

2004 – Domain

2005 – Port

2006 – Data sending protocol (0 – TCP, 1 – UDP)

After successful GPRS/SERVER settings configuration, FM device will synchronize time and

update records to the configured server. Time intervals and default I/O elements can be changed

by using Teltonika Configurator or SMS parameters.

Sleep settings:

102 – Sleep settings(0 – Disable, 1 – Gps sleep, 2 – Deep sleep, 3 – Online Deep sleep, 4 – Ultra

sleep)

Note: This scenario will not work with Deep Sleep and Ultra Sleep modes, since they disable the

device's GSM module to save power.

To setup the speed limiting feature in the configurator we should navigate to Features → Over

Speeding where we would set a priority for the event, speed source and DOUT 1 for the relay to

work properly.

Over speeding settings

11100 – Scenario settings(0 – Disable, 1 – Low Priority, 2 – High Priority, 3 – Panic Priority)

11104 - Max Speed (Default value - 90 km/h)

11103 - Output Control (0 - None (Default), 1 - DOUT1), DOUT1 needs to be enabled to use the

speed limiting feature

Note: Detected speed has to be greater than (configured max speed +3% of configured max

speed) for Over speed start event; detected speed has to be lower than(configured max

speed -3% of configured max speed) for Over speed end event.

Quickstart: From default configuration to Speed Limiting solution in one SMS:

" setparam

2001:APN;2002:APN_user;2003:APN_password;2004:Domain;2005:Port;2006:0;102:3;1

1100:2;11104:90;13217:0;13223:8;11103:1;11101:5000;11102:0"

This SMS will set up your device to report the Speed Limiting scenario to the server.

Note: Before SMS text, two space symbols should be inserted if no SMS username or password was

set in SMS \ Call settings.

3. Configuration - Speed Limiting based on Geo-Fence

Manual Geofence settings

20100 – Scenario settings(0 – Disable, 1 – Low Priority, 2 – High Priority, 3 – Panic Priority)

20101 - Generate Event(0 - Disable, 1 - Low Priority, 2 - High Priority, 3 - Panic Priority)

20104 - Shape Type(0 - Circle,1 - Rectangle)

20105 - Radius in Metres

20106 - X1 Coordinate

20107 - Y1 Coordinate

20108 - X2 Coordinate

20109 - Y2 Coordinate

20110 - Overspeeding(0 - Disable, 1- Enable) should be enabled for speed limiting

functionality.

2005 - Max allowed speed km/h.

Note: Detected speed has to be greater than (configured max speed +3% of configured max

speed) for Over speed start event; detected speed has to be lower than(configured max

speed -3% of configured max speed) for Over speed end event.

Parsing information

1.Prerequisites:

1.1. Open TCP/UDP port

1.2. Read Java parser first start guide

2. Parsing example:

Unparsed received data in hexadecimal stream

00000000000000758E010000018494E2DAFA000F0E53AE209AB86A007F00110D000000FF0015000800EF0100F00100500100150300C800009B0300010000B301000A00B5000A00B6000

600423FC9001800000043000000440000001100220012FFBA0013FC34000F0000000200F10000601A0010002D97E0000000000100002136

AVL Data Packet Part HEX Code Part

Zero Bytes 00 00 00 00

Data Field Length 00 00 00 75

Codec ID 8E (Codec 8 Extended)

Number of Data 1 (Number of Total Records) 01

Timestamp 00 00 01 7C B7 A5 73 70 00 (Monday, October

25, 2021 4:30:46 PM GMT+03:00)

Priority 00

Longitude 0F 0E 53 AE

Latitude 20 9A B8 6A

Altitude 00 7F

Angle 00 11

Satellites 0D

Speed 00 00

Event IO ID 00 FF (Over Speeding)

N of Total ID 00 15

N1 of One Byte IO 00 08

1’st IO ID EF (AVL ID: 239, Name: Ignition)

1’st IO Value 01

2’nd IO ID F0 (AVL ID: 240, Name: Movement)

2’nd IO Value 01

3’rd IO ID 50 (AVL ID: 80, Name: Data Mode)

3’rd IO Value 01

4'th IO ID 15 (AVL ID: 21, Name: GSM Signal)

4'th IO Value 01

5'th IO ID C8 (AVL ID: 200, Name: Sleep Mode)

5'th IO Value 00

6'th IO ID 009B (AVL ID: 155, Name: Geofence zone 01)

6'th IO Value 00

7'th IO ID 01 (AVL ID: 1, Name: Digital Input 1)

7'th IO Value 01

8'th IO ID B3 (AVL ID: 179, Name: Digital Output 1 )

8'th IO Value 01

N2 of Two Byte IO 0A

1’st IO ID B5 (AVL ID: 181, Name: GNSS PDOP)

1’st IO Value 00 0A

2’nd IO ID B6 (AVL ID: 182, Name: GNSS HDOP)

2’nd IO Value 00 06

3’rd IO ID 42 (AVL ID: 66, Name: External Voltage)

3’rd IO Value 3F C9

4'th IO ID 18 (AVL ID: 24, Speed)

4'th IO Value 5F

5'th IO ID 43 (AVL ID: 67, Battery Voltage)

5'th IO Value 00 07

6'th IO ID 44 (AVL ID: 68, Battery Current)

6'th IO Value 00 C8

7'th IO ID 11 (AVL ID:17, Axis X)

7’th IO Value 00 22

8'th IO ID 12 (AVL ID:18, Axis Y)

8’th IO Value FF BA

9'th IO ID 13 (AVL ID:19, Axis Z)

9'th IO Value FC 34

10'th IO ID 0F (AVL ID: 15, ECO Score)

10'th IO Value 00 00

N4 of Four Byte IO 00 02

1'st IO ID F1 (AVL ID: 241, Name: Active GSM Operator)

1’st IO Value 00 00 00 10

2’nd IO ID 10 (AVL ID: 16, Name: Total Odometer)

2’nd IO Value 00 2D 97 E0

N8 of Eight Byte IO 00 00

NX of X Byte IO 00 00

Number of Data 2 (Number of Total Records) 01

CRC-16 00 00 7F CF

Demonstration in Wialon platform

Wialon: Open Wialon application → Select unit→ Select Device → Select the date interval → Select

Track→ to access all the information.

Graphical Representation:

Conclusion

Speed limiting is achieved when max speed is exceeded. Relay is activated on DOUT1 which will

disable the acceleration pedal, turn off the fuel pump or close the solenoid valve.

Note: Detected speed has to be greater than (configured max speed +3% of configured max

speed) for Over speed start event; detected speed has to be lower than(configured max

speed -3% of configured max speed) for Over speed end event.
