FMB641 General description
Main Page > Professional Trackers > FMB641 > FMB641 Manual > FMB641 General description
Teltonika FMB641 is an updated version of the current most popular GNSS, GSM terminal for
PROFESSIONAL applications FMB640. Compared to FMB640 – FMB641 has a new processor that
improves the device's computation power therefore it can be tailored to more specific use cases.
Switchable CAN terminators that will allow you to use the device in a CAN network with numerous
nodes. Lastly, it can be powered via USB for an easier configuration process. All the features that
are supported by FMB640 are also supported by FMB641, for the purpose of maximizing your fleet
efficiency with features like FMS CAN data (J1939), fuel CAN data (J1708), tachograph live data (K-
Line), remote tachograph file download, various third party RS232 or RS485 devices support and
Dual-SIM or eSIM compatibility. The terminal is suitable for applications like international logistics,
refrigerated transport, agriculture, construction & mining, security & emergency services, and even
more.
Contents
1 Package contents
2 Basic characteristics
3 Technical features
4 Technical information about internal battery
5 Battery tests
6 Electrical characteristics
7 Absolute maximum ratings
Package contents
Usually, the FMB640 device sample is supplied to the customer in a cardboard box containing all the
equipment that is necessary for operation. The package contains:
FMB640 device;
4 screws for assembling device
GPS/GLONASS antenna
GSM antenna
USB cable
Port 1/2 cable
Ni-MH Rechargeable battery, 8.4V, 550 mA.
Input and output power supply cable with 2x10 connection pins.
Basic characteristics
Cellular:
GSM/GPRS technology
2G bands: Quad-band 800/850/900/1900 MHz
GPRS Mobile Station Class B
GPRS Multi-Slot class 12 (up to 240 kbps)
SMS (text, data)
GNSS features:
Tracking: 33/ 99 acquisition channels
-165 dBM sensitivity
Hot start <1s
Warm Start < 25s
Cold start < 35s
NMEA-183 protocol
GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS
Accuracy < 3m
Hardware features:
NXP i.MX RT1064 processor;
2 MB internal Flash memory;
External memory card slot;
Built-in accelerometer;
Ni-Mh 550 mAh internal battery;
Interface features:
Power supply: +8...+32 V;
Integrated KLINE
Dual CAN J1939
J1708 CAN
RS485 and 2x RS232 support
4 Digital Inputs for object status monitoring
4 Digital Open-collector Outputs (controlling external relays, LED, buzzers, etc.)
4 Analog Inputs
1-wire interface
MicroSD card
2 status LED
Dimensions: L(104,1mm)xW(76,8mm)xH(31,5mm)
Configuration and firmware update (via FOTA and USB cable)
External GSM antenna for higher sensitivity
External GNSS antenna for higher sensitivity
Special features:
Fast position fix;
High Quality track even in high density urban canyon;
Ultra small case;
Ready for harsh environment;
Easy to mount in limited access areas;
Firmly fasten;
2 LED status indication;
Real time tracking;
Smart data acquisition based on:
Time;
Speed;
Angle;
Distance;
Ignition or any other I/O event;
Sending acquired data via GPRS;
GPRS and SMS I/O events;
Virtual odometer;
Jamming detection;
Configurable using Secured SMS Commands;
2x SIM card; 1x eSIM;
Switchable CAN terminators
Overvoltage protection (compatible with pulse 5b);
Reverse polarity protection;
Description Voltage Duration
Normal operation +8 ... +32 V Unlimited
Protection turns on, device turns
off 34 V Unlimited
Maximum voltage < 70 V Unlimited
Maximum voltage impulse 90 V 5 ms
Technical features
Part name Physical
specification
Navigation
indication LED
Modem
indication LED
Socket Soldered inner socket
USB Mini USB socket
GNSS External GNSS
antenna
GSM External GSM
antenna
Technical details
2 W max.
Current consumption at 12 V
GPRS: average 67 mA
rms
Nominal: average 39 rms
GNSS sleep: average 24
mA
Deep Sleep: average 7,5
mA
Online Deep Sleep:
average 2,4 mA
2 W max.
Current consumption at 24 V
GPRS: average 35 mA
Nominal: average 20 mA
GNSS sleep: average
12,5 mA
Deep Sleep: average 3,8
mA
Online Deep Sleep:
average 1,3 mA
Battery charge current Average 55 mA
Operating temperature (without battery) -40..+85
Storage temperature (without battery) -40..+85
Storage relative humidity 5..95% (no condensation)
Device + case + battery weight 197 g
Dimension drawing:
Technical information about internal battery
Internal back-up battery Battery
voltage (V)
Nominal
Capacity
(mAh)
Charging
temperature
(°C)
Ni-MH rechargeable battery 8.4～10.0 550 0 – 45
Batteries are covered by 6 month warranty support.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Battery should not be disposed of into general household waste.
Bring damaged or worn-out batteries to your local recycling center or dispose them into a
battery recycle bin commonly found in supermarkets.
Battery tests
The amount of time the device will work from internal battery depends on the battery health, how
often the device saves/sends information to the server, external peripherals connected to the device
and the results may also differ depending on firmware used.
For general comparison purpose, and to see what results can be achieved, you can refer to the
following internal test results in different modes and sending frequencies:
Mode:
Min Period (data
saving
frequency)
Send Period
(data sending
frequency)
Starting
Voltage
Cut off
Voltage Time achieved
Operatin
g10 seconds 60 seconds 10,1V 8,3V 471 min (7 hours
51 minutes)
Operatin
g60 seconds 60 seconds 10,2V 8,3V 546 min (9 hours
16 minutes)
Deep
Sleep 12 hours 12 hours 10,0V 8,2V 15120 min (252
hours 0 minutes)
Online
Deep
Sleep
12 hours 12 hours 10,2V 8,6V 6480 min (108
hours 0 minutes)
Electrical characteristics
Characteristic description Value
Min. Typ. Max. Unit
Supply Voltage:
Supply Voltage
(Recommended Operating Conditions) +8 +32 V
Digital Output (Open Drain grade):
Drain current (Digital Output OFF) 120 µA
Drain current
(Digital Output ON, Recommended
Operating Conditions)
0.5 A
Static Drain-Source resistance
(Digital Output ON) 400 300 mΩ
Digital Input:
Input resistance (DIN1) 15 kΩ
Input resistance (DIN2) 15 kΩ
Input resistance (DIN3) 15 kΩ
Input voltage
(Recommended Operating Conditions) 0
Suppl
y
voltag
e
V
Input Voltage threshold (DIN1) 7.5 V
Input Voltage threshold (DIN2, DIN3, DIN4) 2.5 V
Analog Input:
Input voltage
(Recommended Operating Conditions),
Range 1
0+10 V
Input resistance, Range 1 120 kΩ
Input voltage
(Recommended Operating Conditions),
Range 2
0+30 V
Input resistance, Range 2 147 kΩ
Output Supply Voltage 1-Wire:
Supply voltage +4.5 +4.7 V
Output inner resistance 7 Ω
Output current (Uout > 3.0 V) 30 mA
Short circuit current (Uout = 0) 75 mA
CAN Interface:
Internal terminal resistors CAN bus 120/6
0Ω
Differential input resistance 19 30 52 kΩ
Recessive output voltage 2 2.5 3 V
Differential input resistance 0.5 0.7 0.9 V
Common mode input voltage -30 30 V
Power supply current (Hardware version
with internal battery):
Deep Sleep, average, Icc.ds 2.5 4 mA
Sleep, average, Icc.ds, Vcc=10V 45 mA
Sleep, average, Icc.ds, Vcc=30V 25 mA
Ucc=12.6V, all modules fully working,
internal battery is charging, Icc1 350 mA
Ucc=12.6V, all modules fully working,
internal battery is charging, Icc2 300 mA
Ucc=25.2V, all modules fully working,
internal battery is charging, Icc3 195 mA
Ucc=25.2V, all modules fully working,
internal battery is charging, Icc4 140 mA
RS232/RS485 Input Voltage:
RS485 input voltage range on A or B pin
(common-mode voltage) -7 +12 V
RS232 input voltage range (common-mode
voltage) -15 +15 V
Analog Input error margin can increase if temperature varies.
Absolute maximum ratings
Characteristic description Value
Min. Typ. Max. Unit
RS232 Input Voltage
(Absolute Maximum Ratings) -25 +25 V
