TBK vision TBK-6004CHZ Instrucciones de funcionamiento

22x Zoom Auto-Focus Camera

User’s Manual

Version: 1.0

Part Number: 040083/2

SAFETY PRECAUTIONS

CAUTION

RISK OF ELECTRIC

SHOCK. DO NOT OPEN!

CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS.

NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

This label may appear on the bottom of the unit due to space limitations.

The lightning flash with an arrowhead symbol within an equilateral triangle is intended

to alert the user to the presence of uninsulated “ dangerous voltage” within the

product’s enclosure that may be of sufficient magnitude to constitute a risk of electric

shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to

presence of important operating and maintenance (Servicing) instructions in the

literature accompanying the appliance.

WARNING : TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE UNITS NOT

SPECIFICALLY DESIGNED FOR OUTDOOR USE TO RAIN OR MOISTURE.

Attention: installation should be performed by qualified service Personnel only in

accordance with the National Electrical Code or applicable local codes.

Power Disconnect. Units with or without ON-OFF switches have power supplied to

the unit whenever the power cord is inserted into the power source ; however, the unit

is operational only when the ON-OFF switch is in the ON position. The power cord is

the main power disconnect for all unites.

CONTENTS

1. INTRODUCTION...................................................................................................................... 3

2. FEATURES................................................................................................................................. 4

3. ACCESSORIES.......................................................................................................................... 5

4. PRECAUTION........................................................................................................................... 6

5. NAME AND FUNCTION OF EACH PART ........................................................................... 7

6. INSTALLATION........................................................................................................................ 9

6.1 NAT I V E KEYBOARD INSTALLATION ....................................................................................... 10

6.2 PELCO KEYBOARD (OR COMPATIBLE)INSTALLATION........................................................... 10

7. OPERATING PROCEDURE.................................................................................................. 11

7.1 NAT I V E KEYBOARD OPERATION ............................................................................................ 11

7.2 PELCO KEYBOARD (OR COMPATIBLE)OPERATION ............................................................... 12

8. SYSTEM SETUP ..................................................................................................................... 14

8.1 OSD (ON SCREEN DISPLAY)FORMAT ................................................................................ 14

8.2 MENU DESCRIPTIONS ..................................................................................................... 17

8.3 SUB MENU DESCRIPTIONS............................................................................................. 18

9. CAMERA CONTROL COMMAND PROTOCOL.............................................................. 24

9.1 COMMUNICATION FORMAT .................................................................................................... 24

9.2 PC COMMAND....................................................................................................................... 25

9.3 KEY CODE TABLE.................................................................................................................. 59

10. SPECIFICATIONS ................................................................................................................ 62

1. INTRODUCTION

The auto-focus camera is a compact CCTV camera designed for easy integration into surveillance

systems. The Camera's built-in 22x Optical zoom lens spells added user convenience since there

is no need for separate adjustment of the focal distance. Current applications include highway

traffic control, plus security surveillance in such locations as elevators and parking lots.

The advanced DSP technology allows intelligent control for clearer, detailed pictures.

Additionally, the user can perform remote Zoom/ Focus/ Iris/ White Balance operations via either

RS-422/RS-485 or RS-232 (optional) interface. In combination with a highly sensitive 1/4“ CCD

sensor, these features make the auto-focus camera is particularly suitable for surveillance.

•Built-in Optical Zoom Lens - The built-in 22x optical zoom lens is highly reliable and offers

auto focus and auto iris functions. Users can monitor a scene from any desired angle of view.

•High Resolution - The chassis is equipped with a high sensitivity, high-resolution 1/4“ CCD

pickup featuring approximately 380,000 effective pixels. Thanks to a high 450 TV lines

horizontal resolution, picked-up images are reproduced with detail and clarity.

•Setup Menu Function via Keys

Pushing keys on the rear panel of the camera can set each setup menu function. Setup menu

functions are displayed on screen display (OSD).

•Camera Control via either RS-422/RS-485 or RS-232 (optional) interface

Camera control can adjust the camera's zoom, focus, Iris and white balance via either

RS-422/RS-485 or RS-232 (optional) interface.

•Built-in Pan Tilt Zoom (PTZ) Protocols

The camera automatically recognizes four protocols, such as native protocol, PELCO (D and

P protocol) and LG protocol. Camera parameters can easily be setup via native keyboard

(RS-485) or PELCO keyboard (RS-422).

2. FEATURES

•1/4“ High Resolution Color CCD Camera.

•Supports powerful function: Auto Iris Control (AIC), Auto White Balance (AWB), Auto Gain

Control (AGC), Auto Back Light Compensation (ABLC), Flickerless (FL) and Auto Focus

(AF).

•22x Optical Zoom Lens and 16x Digital Zoom. (Total 352x Zoom).

•On Screen Display (OSD) Setup Menu.

•Camera Control via either RS-422/RS-485 or RS-232.

•Supports AUTO/ NATIVE/ PELCO (D and P)/ LG Protocol.

•Remote Control via 6-pin Dry Contact Connector.

•Built-in 5 keys to Control Zooming and Focusing Function, and Setup Menu adjustment.

•Built-in Audio.

3. ACCESSORIES

•Mounting Block ×1 and Screws ×2

•Camera Control 4-pin Connector ×1

•User’s Manual ×1

4. PRECAUTION

Please do not directly touch the zoom lens. If it is necessary to clean the zoom lens, use soft

cloth moistened with alcohol to wipe off any dust.

Please be extra careful not to shake the product.

Please avoid places where frequent vibrations or shocks

Do not install the product in extreme temperature conditions.

Only use the camera under conditions where temperatures are between -10℃and +50℃. Be

especially careful to provide ventilation when operating under high temperatures.

Do not install the product in an environment where the humidity is high.

Unless the product is waterproof or weatherproof, otherwise it can cause the image quality to be

poor.

Never keep the product to direct strong light or sunlight.

It can damage the product.

Do not spill liquid of any kind on the product.

If it gets wet, wipe it dry immediately. Alcohol or beverage can contain minerals that corrode the

electronic components.

If during the night, the minimum brightness of 0.7 Lux cannot be achieved, install

appropriate light fixtures.

When any abnormal occur make sure to unplug the unit and contact your local dealer.

5. NAME and FUNCTION of EACH PART

Front View

Figure 5-1

Side View

Figure 5-2

Rear View

AUDIO RS-232

GND

12V

VIDEO RS-485

R+

R- T-

T+

Figure 5-3

(1). Power Input：DC 12V ±10% (Recommendation 12 ±0.5V) Max 4.1W.

(2). Video Output：Composite Video 1Vp-p, 75 Ohms, BNC

(3). Audio Output：2Vp-p, 50 Ohms

(4). Remote Control (6-pin Dry Contact Connector) / Key Control：

No. Name Function

1 Tele/SZoom Tele or Up (S)

2 Wide/TZoom Wide or Down (T)

Near/

＋

Focus Near or Increase (

＋

)

Far/

－

Focus Far or Decrease (

－

)

5 Menu Enter or Exit Setup Menu

6 GND Ground

It is either open under normal status (Normal Open) or close to GND under active status

(connected to GND).

CAUTION: To prevent damage on the camera, do NOT apply voltage to the dry

contact connector.

(5). Camera Control：2.4K/ 4.8K/ 9.6K/ 19.2K BPS (Please refer to OSD setup MENU).

Optional: RS-232

Name Function

RD, TD Use for RS-232 Control

GND Pair GND for RS-232

Optional: RS-422/ RS-485

Name Function

R+, R-, T+, T- Use For RS-422/RS-485 Control

6. INSTALLATION

GND

1 Frame GND

2 RD

3 TD

4 DTR

5 Signal GND

6 DSR

7 RTS

8 CTS

9 RI

Camera

RS-232 Interface

RS-232C D-Sub Connector

Figure 6-1

R+

T-

T+

R-

R+

R-

T+

T-

Camera

RS-422 Interface 232 to 422 Converter

To PC or

Controller

Figure 6-2

R+

T-

T+

R-

D+

D-

Camera

RS-485 Interface 232 to 485 Converter

To PC or

Controller

D-

D+

Figure 6-3
