TBK vision RYK777F Manual de usuario
P. 1
2004/02/02 Ver:1.0 No:040032/1
B/W 1/3” CCD CAMERA
CONTENTS Page Page
1. Description................................ 1
2. Main features ............................ 2
3. Cautions on handling ................ 2
4. Cautions on installation............. 2
5. Names of each part................... 3
6. How to operate.......................... 4
7. Auto iris control ........................5
8. Packing .....................................5
9. Specifications ............................6
1. DESCRIPTION
Thank you very much for purchasing our product.
This Black and White Camera use high sensitive 1/3” interline
transfer CCD image Sensor (CCD = Charge Coupled Device), and
all state circuitry which provide extremely long life and high
reliability. This Camera offers excellent image quality with low lag
and high burn resistance, and is not subject to distortions from
magnetic fields. High resistance shock and vibration, easy to install,
this Camera is a very good choice for your B/W CCTV system.
INSTRUCTION
M A N U A L
25
P. 2
2. MAIN FEATURES
B/W camera with SONY 1/3“ Super HAD CCD sensor in metal
case.
Pixel number: EIA=380,000 / CCIR=440,000 (High Resolution)
EIA=270,000 / CCIR=320,000 (Normal Resolution)
Reduced fixed pattern noise and lag. No sticking and no image
distortion. Blooming suppression.
Auto Electronic Shutter(AES),Auto Gain Control(AGC),Back Light
Compensation(BLC),Line Lock(LL),Audio.
Supports both C and CS mount lens.
Supports both Video-Drive & DC-Drive auto iris lens.
3. CAUTIONS ON HANDLING
(1) Be careful, never let any water in this equipment.
(2) Please do not directly touch the CCD element. If necessary, use
soft cloth moistened with alcohol to wipe off the dust.
(3) When any abnormal occur make sure to unplug the unit and
contact your local dealer.
4. CAUTIONS ON INSTALLATION
(1) Please be extra careful not to shake the Camera
(2) Please avoid places where there is direct sunlight
(3) When using this Camera in places where the lighting differs,
greatly, please use the Auto Iris Lens with ND Filter.
(4) Please avoid places where temperatures exceed 50℃or more,
high humidity or where direct rain drops hit.
(5) Please avoid places where frequent vibrations or shocks
(6) If during the night, the minimum brightness of 0.1 Lux can not be
achieved, install appropriate light fixtures.
(7) When the Camera is not used, keep the Lens or the Lens cap
attached to protect the CCD Sensor.
P. 3
5. NAMES OF EACH PART
P. 4
6. HOW TO OPERATE
(1) Remove the cap cover from the top of the Lens Mount 1 .
(2) If CS Mount Lens is used, remove the C Mount ring.
(3) Screw the Lens into the Lens Mount.
(4) Connect the Video Output 3to the monitor or other video
device through a 75 Ohms type coaxial cable.
(5) Connect the power source (either with AC or 12V DC power
source),then the LED indicator 1will lit.
(6) Once the picture appears on the monitor, adjust the focus and
iris of the Lens to obtain the best picture.
(7) If the subject is not in correct focus when adjusting focus of
the Lens, do back focus adjustment as following:
I- Set the Focus ring of the Lens to indefinite position.
II- Take picture of subject at a distance more than 20M away.
III- Loosen the Mount Lens fixing screw (use L wrench).
IV- Turn the Lens and the Mount Lens together so the subject
is in the focus and the picture is clear.
V- Screw the Mount Lens Fixing Screw 2 .
(8) Mount the Camera on the Mounting Bracket by using the
hole 3 on top or bottom of the camera or using the
enclosed 8 mm Mounting block with the 2 screws furnished.
(9) When using an Auto Iris Lens, the Switch-1 5should be in
position AI to disable AES function. Before plug the enclosed
miniature 4 pins to Auto Iris Connector 2, please check the
type of Auto Iris Lens, and also the compatibility on the
polarities.
If the Auto Iris Lens is DC DRIVE (or DIRECT DRIVE), the
Switch 4should be in position DC DRIVE. Adjust the LEVEL
with the VR 8to proper level.
If the Auto Iris Lens is VIDEO DRIVE, the Switch 4should be in
position VIDEO DR.
When using Manual Iris Lens, the Switch-1 5is
select-able depend on application environment.
(10) BLC FUNCTION
Set Switch-26to BLC to enable Back Light
Compensation (BLC) function.
(11) Line Lock Function (Line Lock Model only)
When using line lock function, the switch-3 7should be in
position L.L, and adjust VR 9to proper phase.
P. 5
1
3
2
4
7. AUTO IRIS CONTROL CONNECTOR
Pin
V
IDEO DRIVER
1
2
3
4
+12V DC
IRIS OUT
GND
GND
Video Driver Lens Connector
8. PACKING
1 Camera
1 C Mount ring
2 Screws
1 L Wrench
1 Connector 4 Pins for Auto Iris Lens
1 Instruction Manual
P. 6
9.SPECIFICATIONS
Model Type
B/W Analog Type
B/W 1/3” Exview CCD
High Resolution
B/W 1/3” Exview CCD
Normal Resolution
B/W 1/3” CCD High
Resolution
B/W 1/3” CCD Normal
Resolution
Image Pick-up Device SONY 1/3” EXview
HAD CCD sensor
SONY 1/3” EXview
HAD CCD sensor
SONY 1/3” Super
HAD CCD sensor
SONY 1/3” Super
HAD CCD sensor
Effective Picture Elements (HxV) EIA: 768x494,
CCIR: 752x582
EIA: 510x492,
CCIR: 500x582
EIA: 768x494,
CCIR: 752x582
EIA: 510x492,
CCIR: 500x582
Horizontal Resolution 600 TV lines 420 TV lines 600 TV lines 420 TV lines
Minimum Illumination 0.01 LUX @ F2.0 0.02 LUX @ F1.2 0.1 LUX @ F1.2 0.05 LUX @ F1.2
S/N Ratio More than 48 dB
Auto Electronic Shutter EIA:1/60s~1/100,000s, CCIR:1/50s~1/110,000s ON/OFF Switchable.
Auto Iris Control Video-Drive Lens & DC-Drive Lens both can be used.
Gamma Characteristic 0.45
Lens Mount C or CS Mount can be used.
Auto Gain Control Yes
Back Light Compensation ON/OFF Switch-able.
Synchronous System Negative sync. Internal / Line Lock (Optional)
Line-Lock Function (Optional) Phase adjustable, 300°max.
Video Output 1 Vp-p / 75 Ohms. BNC or F connector.
Audio Output (Optional) 2 Vp-p / 50 Ohms. RCA connector.
Power Supply AC 24 / 110 / 220 / 240V / DC12V ±10%
Power Consumption AC24 / 110 / 220 / 240V : 2.75 W , DC 12V : 1.65 W
Operating Temp. -10℃to 50℃(14℉to 122℉)
Model Type.
B/W Digital Type
B/W 1/3” Exview CCD
High Resolution
B/W 1/3” Exview CCD
Normal Resolution
B/W 1/3” CCD
High Resolution
B/W 1/3” CCD
Normal Resolution
Image Pick-up Device SONY 1/3” EXview
HAD CCD senso
r
SONY 1/3” EXview
HAD CCD senso
r
SONY 1/3” Super
HAD CCD senso
r
SONY 1/3” Super
HAD CCD senso
r
Effective Picture Elements (HxV) EIA: 768x494,
CCIR: 752x582
EIA: 510x492,
CCIR: 500x582
EIA: 768x494,
CCIR: 752x582
EIA: 510x492,
CCIR: 500x582
Horizontal Resolution 710 TV lines 510 TV lines 710 TV lines 510 TV lines
Mini Illumination 0.03 LUX @F2.0 0.02 LUX @F2.0 0.03 LUX @F2.0 0.02 LUX @F2.0
S/N Ratio More than 48 dB
Auto Electronic Shutter EIA:1/60s~1/100,000s, CCIR:1/50s~1/110,000 On/Off Switch-able
Auto Iris Control Video-Drive Lens & DC-Drive Lens both can be used
Gamma Characteristic 0.45
Lens Mount C or CS Mount can be used.
Auto Gain Control Yes
Back Light Compensation ON / Off Switch-able
Synchronous System Negative sync. Internal / Line Lock (Optional).
Line-Lock Function (Optional) Phase adjustable, 300°max.
Video Output 1 Vp-p / 75 Ohms. BNC or F connector.
Power Supply AC 24 / 110 / 220 / 240V / DC12V ±10%
Power Consumption AC24V (2.7 W) AC110V (2.8 W) AC220V (2.4 W) AC240V (2.6 W) DC12V (1.38 W)
Operating Temp. -10 to 50℃(14 to 122℉)
Note: Design and specifications are subject to change without prior notice.
