TBK vision RYK416HB Manual de usuario

Color DSP CCD Camera

Instruction Manual

VER.:1.0, NO.:040045A

Thank you very much for purchasing our product. Before operating this

product, please read this instruction manual carefully to ensure proper use.

1. Safety Precautious

CAUTION

RISK OF ELECTRIC

SHOCK. DO NOT OPEN!

CAUTION : TO REDUCE THE RISK OF ELECTRIC

L SHOCK, DO NOT OPEN CO

ERS.

NO USER SER

ICE

BLE P

RTS INSIDE. REFER SER

ICING TO QU

LIFIED

SER

ICE PERSONNEL.

Disposal of Old Electrical & Electronic Equipment (Applicable in

the European Union and other European countries with separate

collection systems).

Please avoid places where there is direct sunlight

If any abnormality occurs, make sure to unplug the unit and

contact your local dealer.

When using this Camera in places where the lighting differs

greatly, please use an Auto Iris Lens with a ND Filter.

Please avoid places where temperatures exceed 50℃or more,

high humidity and/or direct rainfall, frequent vibrations, or

shocks occur.

If the minimum brightness of 0.1 Lux cannot be achieved, install

the appropriate light fixtures.

When the Camera is not used, keep the lens or the lens cap

attached to protect the CCD Sensor.

2. Description

The color camera uses SONY high sensitive super HAD 1/3” interline

Charge Coupled Device (CCD) image sensor, employs Digital Signal

Processor (DSP) chip-set for image control, and all integrated state

circuitry which provides extremely long life and high reliability.

High resistance shock and vibration, easy to install, this camera

is a very good choice for your color CCTV system.

3. Features

Color camera with a SONY 1/3“ Super HAD CCD sensor.

Employed Digital Signal Processor(DSP)chip-set for image

control.

Pixel Number: NTSC=380K / PAL=440K (High Resolution)

NTSC=270K / PAL=320K (Normal Resolution)

High Sensitivity, Low Smear, High Anti-Blooming, and a high S/N

ratio.

Functions Supported: Auto Electronic Shutter (AES), Auto

Iris(AI), Auto Gain Control (AGC), Auto White Balance (AWB),

Manual White Balance (MWB), Back Light Compensation (BLC),

Flickerless mode (FL), Line lock (for AC-Type only).

Supports Auto Iris Lens: both Video-Drive & DC-Drive lens.

Supports both C and CS mount Lenses.

Built-in anti-aliasing and IR-cut optical filter.

4. Name of Each Parts

5. Installation & Operation

Please refer to Fig. 1 or Fig. 2 (P3) and setup guide below:

1. Remove the cap cover from the top of the lens mount.

2. Screw the lens into the lens mount.

3. Connect the video output (9) to the monitor or other video device

through a 75 Ohms type coaxial cable.

4. Connect the power source (6), AC with the power cord, or DC by

using the DC Jack (+12V DC in jack center), then the LED indicate (7)

will lit.

5. Once the picture appears on the monitor, adjust the focus and iris

of the lens to obtain the best picture.

6. If the subject is not in correct focus when adjusting focus of the

lens, do back focus adjustment as following:

•Set the focus ring of the lens to indefinite position.

•Take picture of subject at a distance more than 20M away.

•Loosen the lens mount fixing screw (use L-wrench).

•Turn the lens and the lens mount together, so that the subject

is in focus and the picture is clear.

•Screw the lens mount fixing screw.

7. Mount the camera on the mounting bracket by using the hole (1)

on top or bottom of the camera or using the enclosed 8 mm

mounting block with the 2 screws furnished.

8. DIP Switch (2) Setting

AWB/ MWB FUNCTION

•AWB mode--In this mode, camera automatically aligns the

white balance, the operation color temperature range is

from approximately 2500K to approximately 9500K.

•MWB mode--In this mode, you can use MWB/ Phase (8)

up-key and down-key to adjust color the temperature from

approximately 2500K to approximately 9500K.

AUTO IRIS FUNCTION

•When using an auto iris lens, DIP S.W switch (2) should be

in position with OFF to disable AES function. Before

plugging the enclosed miniature 4 pins to the auto iris

connector (4), please check the type of auto iris lens, and

also the compatibility on the polarities.

•If the auto iris lens is setup to the DC Drive (or Direct

Drive), the Switch (5) should be in position with the DC

Drive. Adjust the VR (3) to the proper level.

•If video drive iris lens is used, the switch (5) should be in

position with the Video DR.

•When using manual iris lens, DIP S.W switch (2) is select-able

depending on the environment.

BLC FUNCTION

Set switch-OFF/ BLC to BLC to enable back light compensation

(BLC) function.

AGC-HI / AGC-LO FUNCTION

AGC maximum gain setup to high/ low (AGC-Hi

mode--The maximum AGC gain is approximately 26dB.

AGC-Lo mode--The maximum AGC gain is approximately

16dB).

FLICKERLESS FUNCTION

Set the switch-OFF/ FLON. Set to FLON to enable flickerless

function, in this mode, the switch-AES/ OFF is auto

disabled.

LINE LOCK FUNCTION (for AC-Type only)

When using line lock function, the switch-INT/L.L. should

be in position with L.L. and adjust MWB/ Phase (8), use

up-key and down-key to adjust the proper phase (Note: If

you want to adjust the phase, the switch-AWB/ MWB

should be in position with AWB).

6. Auto Iris Control

Pin VIDEO DRIVER DC DRIVER

(Direct DRIVE)

VDC OUT

IRIS OUT

N.C.

GND

DAMP-

DAMP+

DRIVE+

DRIVE-

Auto Iris Lens Connector

7. Packing

1 Camera

1 Allen Wrench

1 4-Pin Connector for Auto Iris Lens

1 Instruction Manual

8. Specification

Image Device 1/3” Color Sony

Super HAD

1/3” Color Sony

Ex-View Super HAD

1/3” Color Sony

Hi-Res. Super

HAD

1/3” Color Sony

Hi-Res. Ex-View

Super HAD

Picture Elements NTSC：510×482,

PAL：500

582

NTSC：768×494,

PAL：752

582

Resolution 380 TVL 470 TVL

Min. Illumination 0.1 Lux/ F1.2 0.05 Lux/ F1.2 0.2 Lux/ F1.2 0.07 Lux/ F1.2

S/N Ratio more than 48 dB.

Electronic Shutter NTSC:1/60s~1/100,000s, PAL:1/50s~1/110,000s

Flickerless Mode NTSC: 1/100s, PAL:1/120s (ON/OFF Switch-able)

Iris Control Video/ DC-Drive

Gamma 0.45

Lens Mount C/ CS

Gain Control Hi/ Low

White Balance Auto/ Manual

Back Light Comp. On/ Off

Sync. System Internal/ Line Lock (for AC type only)

Video Output 1 Vp-p/ 75 Ohms

Power Supply DC12V±10%, AC24V, AC110V, AC100~240V (optional)

Power Consumption DC/ 250mA max.

AC/ 4.5W max.

DC/ 295mA max.

AC/ 5W max.

DC/ 250mA max.

AC/ 4.5W max.

DC/ 295mA max.

AC/ 5W max.

Operating Temp. -10℃to 50℃(14℉to 122℉)

Note: Design and specifications are subject to change without prior notice.
