Targus AMB04 Manual de usuario
USER GUIDE
Visit our Website at www.targus.com Features and
specifications subject to change without notice.
© 2008 Targus Group International, Inc. and Targus, Inc.
AMB04US / 410-1357-001A
Optical
Bluetooth®
Mouse
30
Bluetooth Qualified Product
B011073
TARGUS OPTICAL
BLUETOOTH®
MOUSE
Introduction
Congratulations on your purchase of the Targus Optical
Bluetooth Mouse. This mouse uses Bluetooth wireless
technology which provides seamless connections up to
33ft (10M) in range.
System Requirements
Hardware
• Bluetooth-enabled notebook or desktop computer
Operating System
• Windows® 2000/XP
• Windows Vista™
• Mac OS X
1
Targus Optical Bluetooth Mouse
Installing the Batteries
• Use the two AAA-size batteries
• Remove the battery cover from the back of the mouse
by sliding off the cover while pressing the release button
at the bottom of the mouse.
• Insert the batteries, making sure that the positive (+)
and negative (-) ends of each battery match the polarity
indicators inside the battery housing
• Snap the battery cover back into position
2
Targus Optical Bluetooth Mouse
• Turn on the mouse by sliding on/off switch on the bottom
to the “on” position.
Low Battery Power Indicator
WHEN THE BATTERY POWER IS LOW, THE SCROLL WHEEL WILL FLASH RED.
PLEASE REPLACE THE BATTERIES.
Using the enhanced Resolution
feature (DPI switching)
This Bluetooth mouse has a special enhanced resolution feature.
By activating this feature, the mouse will change its tracking
sensitivity from 1600 DPI to 800 DPI. Higher DPI will improve
the precision of the mouse pointer for fine details with increased
speed. To change the DPI, simply press and hold both, the scroll
wheel and the right mouse buttons for 3 seconds. The scroll wheel
will then flash green and then turn off. Repeat this step to change
between the two DPI settings.
3
Targus Optical Bluetooth Mouse
Initial Conguration
Before you can begin using your Bluetooth mouse, you will
first need to perform some initial setup steps.
The Bluetooth Optical notebook mouse is designed
to work with the four major software stack (protocol)
standards: WIDCOMM, Toshiba, Microsoft and Mac OS
X. Please check your computer’s documentation to see
which software stack your computer has. Please contact
your system vendor if your system does not support one
of the listed Bluetooth software standards.
NOTE: PLEASE USE THE LATEST BLUETOOTH DEVICE DRIVER. INSTRUCTION
SCREENS MIGHT VARY DEPENDING ON THE VERSION OF YOUR BLUETOOTH
DEVICE DRIVER.
4
Targus Optical Bluetooth Mouse
Connecting with Bluetooth Software:
WIDCOMM or Microsoft (Windows XP & Windows Vista)
1. Go to the Bluetooth Places icon located on your desktop or in the
system tray and double click, then click Add a Bluetooth Device.
2. The Bluetooth Wizard screen will prompt. Please follow the
onscreen instructions.
(Windows XP)
(Windows Vista)
(Windows Vista)
(Windows XP)
5
Targus Optical Bluetooth Mouse
3. Please turn on the mouse and press the connection ID button
located at the bottom of the mouse until the LED on the mouse
blinks green (discovery mode). Click Next to continue pairing and
the computer will search for the mouse.
4. The confirmation window will appear after the computer finishes
detecting the Bluetooth devices. Select the Bluetooth Wireless
Mouse and click Next to continue. (There may be one or more
different Bluetooth devices detected.) If the mouse is not detected,
please make sure the power is on and in discovery mode. Press
Search Again to re-pair the device.
(Windows Vista)
(Windows XP)
6
Targus Optical Bluetooth Mouse
5. After selecting the correct device, the computer will finish
establishing the connection. Please wait until the setup is
completed.
(Windows Vista)
(Windows XP)
(Windows Vista)
(Windows XP)
7
Targus Optical Bluetooth Mouse
Connecting with Bluetooth Software:
TOSHIBA (Windows Vista)
1. Double click on the Bluetooth Manager icon in the system tray,
and then click Add New Connection.
2. Please turn on the mouse and press the connection ID button
located at the bottom of the mouse until the LED on the mouse
blinks green (discovery mode). Click Next to continue pairing and
the computer will search for the mouse.
8
Targus Optical Bluetooth Mouse
3. The computer will now search for the Bluetooth mouse and
other Bluetooth devices. Please wait until the search is completed.
Choose the device you wish to connect. There may be more than
one Bluetooth device detected. Select Bluetooth Wireless Mouse
and click Next to continue. If the mouse is not detected, please
make sure the mouse is in discovery mode and click Refresh.
4. The computer will begin connecting with the device.
9
