Targus AKB32UK Manual de usuario
N2953
410-2189-203A / AKB32UK
User Guide
BLUETOOTH
WIRELESS KEYBOARD
for iPad
QD ID : B015144
©2011 Manufactured or imported by Targus Europe Ltd.,
Feltham, Middlesex TW14 8HA, UK. All rights reserved.
Targus is either a registered trademark or trademark of
Targus Group International, Inc. in the United States
and/or other countries. Features and specications are
subject to change without notice. All trademarks and
registered trademarks are the property of their respec-
tive owners.
Targus Bluetooth Wireless Keyboard for iPad
2
Targus Bluetooth Wireless Keyboard for iPad
3
Targus Bluetooth Wireless Keyboard for iPad
4
Targus Bluetooth Wireless Keyboard for iPad
5
Targus Bluetooth Wireless Keyboard for iPad
6
Targus Bluetooth Wireless Keyboard for iPad
7
GB - Introduction Installing the Batteries
Battery Life Indicator
Contents
System Requirements
Thank you for your purchase of the Targus Bluetooth Wireless Keyboard for
iPad. This keyboard uses Bluetooth technology which provides a seamless
connection up to 33 feet (10 m) away. This keyboard is iPad and Mac OS
compatible. Its compact size is ideal for portability and travel.
1 Remove the battery cover located on the bottom of the keyboard.
2 Insert the supplied batteries, making sure that the positive (+) and negative
(-) ends of each battery match the polarity indicators inside the battery
compartment.
• Battery life indicator will blink twice every second when the power level drops
below 15%. Replace the batteries as soon as possible.
• Keyboard will shut down when power level is below 10%.
• Targus Bluetooth Wireless Keyboard
• 2 x AAA Energizer® MAX® Batteries
• User Guide
Hardware
• iPad
• Mac Bluetooth enabled device
Operating System
• Mac OS X v10.4 or later
Targus Bluetooth Wireless Keyboard for iPad
8
Targus Bluetooth Wireless Keyboard for iPad
9
CONNECT
OFFON
Establishing the Connection
1. Turn on the keyboard by sliding the power button to the ON position.
2. Switch ON the Bluetooth function of your iPad.
3. Press the Connect button on the back of your Targus Bluetooth Wireless
Keyboard to enable discovery mode. The low power indicator light will ash
blue when the keyboard is in discovery mode.
4. Once the Bluetooth keyboard is listed as a found device in the bluetooth
menu on the iPad, tap on the name and you will be prompted to enter a pass
key as shown.
5. Enter the passkey shown on the pop up message, followed by the enter key.
6. Bluetooth Keyboard is now connected with your iPad and the blue light will
stop ashing.
“Bluetooth Keyboard” would like to
pair with your iPad.
Enter the passkey “XXXXXX” on
“Bluetooth Keyboard”, followed by
the return or enter Key.
Cancel
Targus Bluetooth Wireless Keyboard for iPad
10
Targus Bluetooth Wireless Keyboard for iPad
11
Using the Hot Keys
Key Function
Home Screen
Search
iPad will enter Photo Frame mode
Show and hide the Keyboard on your display
Rewind or go to previous song, movie, or slideshow
Fast Forward or go to next song, movie, or slideshow
Play or pause songs, movies, or slideshows
Mute the sound on the iPad
Decrease the volume on the iPad
Increase the volume on the iPad
Lock your display
Bluetooth Connection: Mac
1. Go to the Bluetooth icon located on your desktop or in the system bar and
click the icon to begin setup. Select “Turn Bluetooth On” to activate the
Bluetooth function on your Mac.
2. Scroll down the list and select “Set up Bluetooth Device...”
3. The Bluetooth Setup Assistant will begin. Please follow the on-screen
instructions.
4. Select “keyboard” and click continue to proceed with setup. Your keyboard
will need to be in “discovery” mode to connect.
5. Press the Connect button on the back of your Targus Bluetooth Wireless
Keyboard to enable discovery mode. The low power indicator light will ash
blue when the keyboard is in discovery mode.
6. Your computer will begin to search for the keyboard. Once the keyboard is
found, it will show up in the list. Highlight “Bluetooth Keyboard” and press
continue.
7. The Bluetooth keyboard will now begin pairing. Click continue to proceed.
8. Congratulations. Your Bluetooth keyboard is setup and ready to use. You
can choose to set up another device or click Quit to exit setup.
Targus Bluetooth Wireless Keyboard for iPad
12
Targus Bluetooth Wireless Keyboard for iPad
13
Targus Bluetooth Wireless Keyboard for iPad
14
Targus Bluetooth Wireless Keyboard for iPad
15
CONNECT
OFFON
Targus Bluetooth Wireless Keyboard for iPad
16
Targus Bluetooth Wireless Keyboard for iPad
17
Targus Bluetooth Wireless Keyboard for iPad
18
Targus Bluetooth Wireless Keyboard for iPad
19
