Swann SW343-DP2 Manual de usuario

Product Code SW343-DP2

UPC 814282011735

EAN 9325481010999

2 months

continuous recording+

320

30ft 9m

good night vision

high video quality

1/3” CMOS 400 TV lines

400

BNC cable x 2

50ft 15m

weather resistant cameras

anti-corrosive casing

easily backup video

incidents to flash drive

easily connects

to your TV

add up to 2 cameras

Channels

www.swannsecurity.com

™

Advanced securit

made eas

plug&playsecurity

Home & Business

Security Monitoring Kit

DVR4-950™ / PNP-150/2™

Monitor up to 4 cameras for peace of mind at an

affordable price, with no ongoing costs

Easily backup & retain video footage if there’s an

incident

Set & forget by recording continuously from 4 cameras

for over 60 days+

Catch suspicious activity, save time & hard drive space

with motion detection

Protect the people you care about & reduce the cost of

crime

Never lose the

remote control again!

Use as a front control panel

or easily detach to use as a

remote control

www.swannsecurity.com

™

Please note that the information contained within this document is subject to change without notification.

Package Contents

• DVR4-950™

• 320GB Hard Drive (installed)

• PNP-150™ Cameras x 2

• RCA to RCA Cable 3ft / 1m

• BNC Cables 50ft / 15m x 2

• Power Adapters

• Remote Control x 2

• BNC to RCA Adapters

• Mounting Screws & Plugs

• Operating Instructions

• Theft Deterrent Stickers x 4

All trademarks remain properties of their respective owners.

™

Advanced securit

made eas

plug&playsecurity

warranty

MONTHS

12 x4

BONUS

STICKERS

SECURITY

Home & Business

Security Monitoring Kit

DVR4-950™ / PNP-150/2™

Speciﬁcations

DVR

Video

Video Format NTSC or PAL

Video Inputs 4CH Composite

Video Outputs 1CH Composite

Display Resolution NTSC: 640 x 448 /

PAL: 640 x 544

Display Frame Rate NTSC: 120fps (4 x 30) /

PAL: 100fps (4 x 25)

Audio

Audio Input 1 RCA Input

Audio Output 1 RCA Output

Recording

Compression Format Advanced MJPEG

Recording Resolution NTSC: 640 x 224 / PAL: 640 x 272

Recording Frame Rate NTSC: 60fps Quad View /

PAL: 50fps Quad View

Recording Modes Manual / Schedule / Motion

Multiplex Operation Triplex

HDD Interface / Memory Type SATA

Hard Drive Support Up to 1TB

General

Operating Power DC 12V

Dimensions 8.9”x 8.2”x 2.1” /

225mm x 208mm x 53mm

Weight 2.8lbs / 1.3kg

Backup Method USB to Flash Drive

Remote Control Yes, 2 in pack

Remote Control Battery Type Lithium battery CR2025 / 3V

Camera

Video

Image Sensor 1/3” CMOS

Video Quality 400 TV Lines

Number of Effective Pixels NTSC: 510 x 492 / PAL: 628 x 582

Minimum Illumination 0 Lux (IR on)

Day/Night Mode Color during day / switches to B&W at night

White Balance Automatic

Signal / Noise Ratio > 50dB

Electronic Shutter 1/60 - 1/15,000 NTSC / 1/50 - 1/15,000 PAL

Gain Control Automatic

Backlight Compensation Yes

Wide Dynamic Range No

Lens 6mm

Viewing Angle 53 degrees

Audio

Microphone No

Night Vision

Night Vision Distance Up to 30ft / 9m

IR Cut Filter No

Number of Infra-Red LEDs 30

Infra-Red Wavelength 850nm

Infra-Red LED Life 10,000 hours

General

Indoor / Outdoor Indoor / Outdoor

Operating Power DC 12V

Operating Temperature 14°F ~ 122°F / -10°C ~ 50°C

Body Construction ABS Plastic

Dimensions - Camera 5.5” x 2.8” x 2.8” /140mm x 70mm x 70mm

Dimensions - Stand 4.5” x 2.3” x 2.3” /120mm x 60mm x 60mm

Weight – Camera 0.4lbs / 180g

Weight – Camera & Stand 0.5lbs / 235g

Cable Length 50ft / 15m

Packaging

Pack Weight 11lbs / 5kg

Pack Dimensions (HxWxD) 15” x 11.2” x 7.1” /

380mm x 285mm x 180mm

Master Pack Quantity 2

Master Pack Dimensions (HxWxD) 14.2” x 17.1” x 25.8” /

360mm x 435mm x 655mm

Channel Select

Operating Controls

Detachable

Remote Control

Power LED

front

320GB Hard Drive

HDD Activity LED

Video Out Power Input

back

Video

In x 4

Audio In

Audio

Out

USB Port

+ based on the lowest recording settings
