Swann SWIFI-FLOCAM2 Manual de usuario

Wi-Fi Floodlight Security Camera

Cámara de Seguridad Wi-Fi con Reflector

Caméra de Sécurité Wi-Fi à Projection

Telecamera di Sicurezza Wi-Fi con Faretti

Wi-Fi-Überwachungskamera mit Flutlicht

EN Quck Start Gude ES Guía de Inco Rápdo FR Gude de Démarrage Rapde

IT Guda Rapda DE Schnellstartanletung

SWIFI-FLOCAM2

IMPORTANT SAFETY INSTRUCTIONS

• All electrical connections and wiring of this product must be carried out by a licensed electrician

in accordance with local and national wiring rules (e.g., AS/NZS 3000 Electrical Installations).

Check with local authorities for applicable requirements.

• The product must be mounted on a flat vertical surface capable of supporting the full weight of the

product.

• Ensure the voltage marked on the product is the same as the electrical power supply to be used.

• Do not connect to a dimmer switch or timer.

• Always turn off electricity at the main circuit breaker or fuse box before installation. Failing to do so

could result in serious injury, electrical shock, and/or risk of fire.

• Do not rely on wall switch alone to turn off the power.

• Do not open or disassemble the product. There are no user-serviceable parts inside.

• Before you begin the installation of the product, it is important that you confirm the availability of

Wi-Fi as well as the signal level at the desired installation location.

• Note that Wi-Fi quality can vary significantly at different locations around the home due to

environmental factors such as home construction type and wireless interference from other

electronic devices.

TO CHECK WIFI COVERAGE

1Connect your phone to the 2.4GHz Wi-Fi network band of your internet/broadband router.

Note: The Swann Floodlight Security Camera will only connect to a 2.4GHz network.

2Place your phone where you are planning to install the floodlight unit. If you have Wi-Fi connection

on your phone, the camera will also likely be able to obtain Wi-Fi connection. Check the Wi-Fi icon

on your phone. We recommend a minimum of 1 bar showing on your phone's Wi-Fi icon as shown

below. Further testing should be performed if the Wi-Fi signal strength is only 1 bar.

PREINSTALLATION CHECK

WIFI COVERAGE AVAILABILITY

0 1

Number of bars indicate

Wi-Fi signal strength

ExcellentGoodFairPoorNo connection

2 3 4

PREINSTALLATION CHECK

3To avoid any potential Wi-Fi connection issues later, try playing a video on a media streaming

service app, for example, YouTube™or Netflix™, through your phone. If possible, temporarily pause

activities like online gaming and video streaming on other devices connected to your network

while you perform testing, as this can affect the connection speed and quality.

4If you don't experience any video streaming issues (buffering, stuttering, etc), you can proceed with

the installation of the product. There are also Wi-Fi surveying and speed tools available online that

can help you analyze and test the quality of your Wi-Fi connection including download and upload

speeds (minimum internet upload speed of 1 Mbps is recommended for optimal video streaming).

5If you still have any concerns about your Wi-Fi coverage, consult a licensed electrician on

connecting the Floodlight wiring to a temporary plug and running an extension cord to a wall

outlet so you can power the camera onsite to test Wi-Fi pairing and live video streaming directly

via the Swann Security app. For camera pairing instructions, see page 9.

WIFI WEAK OR OUT OF RANGE

• If you're getting a weak Wi-Fi signal or you can’t connect to Wi-Fi at all on your phone at the

installation site, we recommend moving your router closer, installing a Wi-Fi extender (which can

help improve signal reception) or selecting another location.

• Do not proceed with the installation of this product until you have thoroughly tested and

confirmed the availability and reliability of the Wi-Fi connection at your desired location.

GET THE APP

1Download the latest version of the Swann Security app from the Apple App Store® or Google

Play™ Store on your iOS or Android device. Simply search for "Swann Security".

2Open the app, create your Swann Security account, and sign in. You will need to activate your

account by confirming the email sent to the email account you provided before you can sign in.

GET THE SWANN SECURITY APP

INSTALLATION EXAMPLE DIAGRAM

Microphone

Washer

Cap

Night Detection Sensor

Adjustment KnobLocking NutFoam Gasket

Junction Box

Cable Clamp

Cable

Grommet

Terminal Block

LED Indicator

Speaker (Siren)

Slow Blinking Blue Wi-Fi Pairing Mode Solid Red Live streaming/Motion recording

Fast Blinking Blue Connecting to Wi-Fi Blinking Purple Low Wi-Fi signal

LED Indicator Guide

Resetting the Camera

Open the port cover on the back of the camera. Press and hold the Reset button for 10 seconds.

(Active)

(Neutral)

(Earth)

Brown

Blue

Green/Yellow

Floodlight wiring

True Detect™

Passive Infrared (PIR)

Motion Sensor

Locking Collar

Reset Button

Infrared LEDs

QR Code

(for device pairing)

INSTALLATION INSTRUCTIONS

This unit is designed to be mounted on a standard wiring junction box and requires connection to a

100-240VAC power supply. For optimum results, install the unit at least 2.4m (8ft) above the ground.

Read "IMPORTANT SAFETY INSTRUCTIONS" and "PRE-INSTALLATION CHECK", and make sure the

installation site is Wi-Fi ready before installing the unit.

INSTALLATION AND WIRING MUST BE CARRIED OUT BY A LICENSED ELECTRICIAN.

IMPORTANT! TURN POWER OFF AT CIRCUIT BREAKER OR FUSE BOX.

When installing the unit refer to the Installation Example Diagram on page 6.

1Cut a small entry hole in the cable grommet enabling the electrical supply cable to enter the

provided junction box. Make sure the supply cable coming from the wall is long enough to route

through the cable grommet to the terminal block.

2Attach the junction box securely to the wall using the appropriate fixings for the wall type.

3Peel the backing off the adhesive foam gasket and stick it to the back of the floodlight unit.

4Unscrew the cable clamp from the junction box. Connect the active, neutral, and earth wires to the

terminal block in the junction box as marked according to the connection diagram as shown on the

next page. Make sure each wire is firmly screwed to its corresponding terminal.

INSTALLATION INSTRUCTIONS

Earth

Live

Neutral

Brown Floodlight Wire Brown (Active Supply Wire)

Green/Yellow Floodlight Wire Green/Yellow (Earth Supply Wire)

Blue Floodlight Wire Blue (Neutral Supply Wire)

TERMINAL BLOCK

5Fasten the electrical supply cable to the junction box using the cable clamp. Screw the cable

clamp down tightly.

6Place the floodlight unit (make sure the “UP” arrow on the back is pointing up) against the junction

box, aligning the center mounting holes and lock it securely with the provided long mounting

screw and washer.

7Insert the provided screw cap firmly into the center mounting hole on the floodlight unit.

8Apply silicone weather sealant (not included) around the back of the junction box and mounting

surface for moisture seal. Installation is complete. Remove the protective film from the camera.

9Turn the electricity back on and allow the camera to power up. This can take up to a minute.

When the camera starts blinking blue, it is ready to be paired with your Wi-Fi network.

TIP If you have a light switch that controls the floodlight unit, remember not to turn off the switch

as this will also turn off the camera. The camera needs to be powered at all times to stay connected

to your Wi-Fi. Put a sticker label on the light switch so that people know not to turn it off.

Learn more about using your camera to view live video and recorded clips as well as camera settings

to adjust floodlight brightness and siren duration, by downloading the Swann Security manual from the

app menu .

SET UP THE CAMERA

Open the Swann Security app on your phone and sign in. Tap the Pair Device button on the screen (or

open Menu and select Pair Device) and follow the in-app instructions to set up your new camera.

TIPS

Angle Adjustments

To adjust the direction of the lamps and the camera, loosen the corresponding adjustment knob or locking nut/collar.

Less

sensitive

Motion Detection

• The camera's motion sensor is more sensitive to

the movement of heat across the coverage area

and less sensitive to movement directly towards

or away from it.

• Position the camera tilted slightly downwards so

that the likely approach path occurs across the

coverage area (see figure on right). When walking

directly towards or away from the motion sensor

the detection range will be reduced. Note that

detection range may also alter with changes in

ambient temperature.

TIPS
