OPERATION

MANUAL

Gaming Mouse

RX-G975

ENG

Gaming Mouse

Congratulations on your purchase of the Sven mouse!

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eorts to make this Manual more exact, some discrepancies may oc-

cur. Theinformation in this Manual is given on «as is» terms. The author and the publisher

donobear any liability to a person or an organization for loss or damage which has arisen

from theinformation contained in this Manual.

BUYER RECOMMENDATIONS

• Unpack the device carefully. Make sure there are no accessories left in the box. Check up

the device for damage; if the product was damaged during transportation, address therm

which carried out the delivery; if the product functions incorrectly, address the dealer at once.

• Check up the package contents and availability of the warranty card. Make sure the war-

ranty card has a shop stamp, a legible signature or the seller’s stamp and purchase date,

andthegoods number corresponds to that in the warranty card. Remember: in case of war-

ranty card loss or discrepancy of numbers you forfeit the right for warranty repairs.

• Before installing and using the speaker system, read this Manual carefully and keep it forfu-

ture reference.

• Shipping and transportation equipment is permitted only in the original container.

• Does not require special conditions for realization.

• Dispose of in accordance with regulations for the disposal of household and computer

equipment.

PACKAGE CONTENTS

• Gaming mouse — 1 pc

• Operation Manual — 1 pc

• Warranty card — 1 pc

APPOINTMENT

RX-G975 gaming mouse is an input device. It is designed for entering (entering) information

into the computer, as well as controlling the operation of the computer

Technical support is on www.sven..

ENG

RX-G975

User Manual

SYSTEM REQUIREMENTS

• ОS Windows.

• Free USB port.

PREPARATION TO WORK

• Connect the gaming mouse to an available USB connector on the PC.

• After connecting to the USB port, the PC will automatically recognize the device.

• To use the built-in mouse memory, adjust the buttons and backlight, you need to install the

software (downloaded from the website www.sven.). Run the previously downloaded file to

install the driver, follow the installer’s advice. Administrator rights may be required.

• After installation, the program will automatically detect the presence of the mouse. You can

call up the control window using the icon in the taskbar or in the Windows system tray.

KEY ASSIGNMENTS AND MOUSE SETTINGS

• Initially all mouse buttons are set to default settings (as shown below). User has the ability

to change the functions of these keys.

• You can reassign buttons by clicking on the menu items on the right in the image or by

clicking on the number markers, calling the menu where you can redefine the keys, assign a

macro (pre-configured keyboard shortcut options), link to the multimedia key volume control,

volume off, player control, etc.

Warning!

The LMB key number 1 can be reassigned only if you reassign the functions of the left mouse

button to any other button, otherwise the software will not allow you to reassign the LMB.

Fig. 1.

ENG

Gaming Mouse

CHANGE MOUSE FUNCTIONS

• The functions of the mouse buttons can be changed by giving other values button. Markers

with numbers on the image correspond to the list numbers from 1 to 10. Click on the marker

or list, opens a window with additional functions that can be reassigned. The following is a

list of default keys.

Note: After all changes in the software, you must click Save to save the changed settings to

the mouse. The Reset button sets the default settings.

PREPARATION FOR WORK

• Key 1 – left mouse button

• Key 2 – right mouse button

• Key 3 – middle button, button under the wheel

• Key 4 – next page

• Key 5 – previous page

• Key 6 – DPI + switching

• Key 7 – DPI – switching

• Key 8 – triple click

• Key 9 – change backlight mode

• Key 10 – precise aiming function

ADDITIONAL FUNCTIONS

• Mouse Function – basic mouse functions.

• Fire Function – hot key function, allows you

to assign mouse buttons, any one button on

the keyboard. Key Value – character input field

from the keyboard, Rate – character input speed,

Times – number of characters per click, option

set Endless – allows you to display a character

while the button is pressed.

• Group Function – combination of multiple

buttons.

• Media Function – media functions: stop,

pause, volume control.

• Macro Function - function allows you to

display a previously recorded macro. How to

create a macro is described in «Creating macro».

Macro runs one-time after pressing the button –

macro launches once after pressing button

• Macro runs endless loop until any button is

pressed – the macro runs an infinite loop until

any button is pressed.

Fig. 2.

Fig. 3.

ENG

RX-G975

User Manual

Macro runs endless loop until button is released –

Macro runs an infinite loop as long as the button

is pressed.

• DPI Function – increase or decrease the

sensitivity of the sensor, DPI LOOP – ability of the

sensor switches in a circle.

Sniper Key - function to reduce DPI expansion to

a minimum, for accurate aiming in games.

• Windows Function –small set of standard

Windows commands.

• Gun Function – choice of weapons 1, 2, 3.

Fig. 4.

Fig. 5.

CREATING MACROS

Macros are sequences of events (keystrokes,

keystrokes, and delays) that can be recorded

and later played back to simplify repetitive

tasks. They are also possible use to play

sequences that are long or difficult to execute.

Macro Editor tab allows you to create precise

sequences of keystrokes.

Fig. 6.

ENG

Gaming Mouse

To create a macro, follow these steps:

1. On the main page, click on Macro Editor line.

2. In window, click New button, the name of the new macro will appear in the window on the

right Macro Name. The new macro will be named Macro_0.

3. To record a macro, press Start Record button (the button will change its value to Stop Record),

enter a combination of numbers, letters, or function keys on the keyboard. The entered

characters will appear in Action window.

4. Click Stop Record button, the macro recording is complete. The created macro can now be

assigned to any user-friendly mouse button. A list of available macros will appear in the button

settings menu.

If you want the macro to repeat the required number of times, enter the number of iterations

in Times window. Set Delay checkbox implements the delay between pressing and releasing

the keys.

SETTING FIRING PARAMETERS

Gun editor editor tab allows you to adjust the accuracy of shooting (self-suppressing the recoil

of the weapon), shooting mode, several times at a time. Shots are concentrated for the most

accurate shooting.

On the left in the screenshot (Fig. 7.), pre-settings are available for different types of weapons,

all settings for six types of weapons.

Select gun – select the weapon that will be available in Gun Function menu when setting the

button to change the weapon.

Fire regulation:

Rate – magnitude of the pause between shots.

Times – number of repetitions, from 1 to 255. If you set Endless option, the repetitions will

be while the fire button is pressed.

Adjustment of shots from the weapon can also be made by changing the position of the red

dot.

Fig. 7.

ENG

RX-G975

User Manual

FREQUENCY OF THE MOUSE

The polling frequency is a characteristic that shows

how often the processor polls the matrix. In the

program you can set the mouse polling frequency

from 125 to 1000Hz. In Report Rate line, select the

desired sensor polling frequency.

Fig. 8.

SYSTEM SETTINGS

Mouse Speed – speed of the cursor

DoubleClick Speed – double click speed

Number of Rows – number of scroll lines

Scroll one Screen – postorinkova scrolling

Fig. 9.

DPI SETTINGS (SENSOR RESOLUTION)

Mouse Speed – speed of the cursor on the screen

DoubleClick Speed – double click speed

Number of Rows – number of scroll lines

Scroll one Screen – postorinkova scrolling

Fig. 10.

Fig. 11.

MOUSE BACKLIGHT SETTINGS

In Light field you can select lighting modes, light

effects can be selected by clicking on the pop-up

menu, a total of 11 modes are available. Brightness –

brightness of illumination. Color – color selection for

static backlight modes. Use the color switch from 1 to

8 to assign a color from an existing palette or create

your own. You can also enter the RGB color code.

ENG

Gaming Mouse

TECHNICAL SPECIFICATIONS

Parameter, measurement unit Value

Q-ty of buttons 9 + 1 (scroll wheel)

OS compatibility Windows

Interface USB

Resolution, DPI 200-10000

Сable length, m 1.8

Dimensions, mm 132 × 76 × 42

Weight, g 138

Notes.Technical specifications given in this table are supplemental information and cannot

give occasion to claims. Technical specifications are subject to change without notice due to

the improvement of SVEN production.

Gaming Mouse

RX-G975

Model: RX-G975

Importer: Tiralana OY, Office 102, Kotolahden-

tie 15, 48310 Kotka, Finland.

Импортер вРоссии: OOO «Регард», 105082,

г.Москва, ул. ФридрихаЭнгельса, д.75, стр.5.

Уполномоченная организация в России:

ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха

Энгельса, д. 56, стр. 1. Условия гарантийно-

го обслуживания смотрите вгарантийном

талоне или на сайте www.sven.fi. Гаран-

тийный срок: 12 мес. Срок службы: 5 лет.

Производитель: «СВЕН ПТЕ. Лимитед», 176

Джу Чиат Роуд, №02-02, Сингапур, 427447.

Произведено под контролем «Свен Скан-

динавияЛимитед», 48310, Финляндия, Кот-

ка, Котолахдентие, 15. Сделано в Китае.

Manufacturer: SVEN PTE. LTD, 176 Joo Chiat

Road, № 02-02, Singapore, 427447.

Produced under the control of Oy Sven Scan-

dinavia Ltd. 15, Kotolahdentie, Kotka, Finland,

48310. Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland.
