Sven RX-305 Manual de usuario

www.sven.ﬁ

USER’S MANUAL

Wireless Optical Mouse

RX-305

Wireless

Congratulations on your purchase of the SVEN PC mouse!

Please read the following instructions carefully before connecting, operating

or adjusting this product. Besides, please keep this Manual in a safe place

for future reference.

This Manual and information contained in it are copyrighted. All rights

reserved.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eﬀorts to make this Manual more exact, some

discrepancies may occur. The information in this Manual is given on “as is”

terms. The author and the publisher do not bear any liability to a person or

an organization for loss or damage which has arisen from the information

contained in this Manual.

CONTENTS

1. SPECIAL FEATURES ..................................................

2. PACKAGE CONTENTS ................................................

3. SYSTEM REQUIREMENTS ..........................................

4. DESCRIPTION .........................................................

5. INSTALLATION .........................................................

6. TROUBLESHOOTING ................................

.................

7. TECHNICAL SPECIFICATIONS ...........................

...........

Technical support is on www.sven.ﬁ.

ENG

User’s Manual RX-3o5

Wireless

ENG

Wireless Optical Mouse

1. FEATURES

•Blue LED advanced optical technology

•Power saving wireless technology

•Stylish ergonomic design

• Eﬀective on most surfaces

•High speed operation

•2.4 GHz USB nano receiver included (range of actionup to 10 m)

•Dpi resolution switch

•USB interface

•Battery long service life (1 year)

•Installation drivers for Windows XP/Vista/7/8 are not required

•Convenient for laptop operation

2. PACKAGE CONTENTS

•Optical mouse — 1 рс

•2.4 GHz USB nano receiver — 1 рс

•AAA batteries — 2 рсs

•User’s Мanual — 1 рс

•Warranty card — 1 рс

3. SYSTEM REQUIREMENTS

•Windows XP/Vista/7/8.

•Free USB port.

ENG

User’s Manual RX-3o5

Wireless

Fig. 3. Nano receiver

Fig. 2. Bottom view

4. DESCRIPTION

aScroll wheel

bDpi resolution switch

cOn/oﬀpower switch

dOptical sensor

eBattery compartment

fNano receiver

gUSB connector

Fig. 1. Top view

5. PREPARATION TO OPERATION

•Open the cover of the mouse battery compartment e, insert 2 AAA

batteries into the battery compartment observing the polarity and close the

cover of the battery compartment (see Fig. 4).

•Сonnect the included nano receiver fto a free PC USB port (Fig. 5).

•Then switch on the mouse using the switch cand press any button or

rotate the scroll wheel to activate the mouse. If the mouse has been con-

nected correctly, it will be switched on automatically.

ENG

Wireless Optical Mouse

Fig. 4. Battery installation

Fig. 5. Receiver connection

AAАbatteries

Battery

compartment

Improper installation of the

batteries can result in failure

of the mouse!

Battery compartment cover

ENG

User’s Manual RX-3o5

Wireless

This device meets the highest standards of energy conservation.

Use the switch con the bottom of the mouse to switch it on/off –

it will help you extend the mouse battery life.

Important

•

After ﬁnishing your work, you can pull out the receiver ffrom the PC USB

port and insert it into the mouse (Fig. 6).

When using the receiver fagain,

pull it out from the mouse (Fig. 7) and connect it to the PC USB port again.

•Do not place the receiver into a conﬁned metal space (table drawer, box,

safe), as a metal screen does not transmit radio signals.

•If the batteries are discharged, the mouse works in jerks. It means that the

batteries should be replaced with new ones, as it is shown in Fig. 4.

Fig. 6. Fitting the receiver

into the mouse case

Fig. 7. Extraction of the receiver

from the mouse case

ENG

Wireless Optical Mouse

Notes:

• Technical speciﬁcations given in this table are supplemental infor-

mation and cannot give occasion to claims.

• Technical speciﬁcations are subject to change without notice due to

the improvement of SVEN production.

TECHNICAL SPECIFICATIONS

Parameter

OS compatibility

Mouse type

Resolution, dpi

Quantity of buttons

Interface

Dimensions, mm

Weight, g

Value

Windows XP/Vista/7/8

wireless 2.4 GHz

800/1200/1600

3 + 1 (scroll wheel)

USB

58 × 35 × 100

6. TROUBLESHOOTING

Solution

1. Make sure that the nano receiver has been

inserted into the USB port and its distance to

the mouse is less than 10 m.

2. Check whether batteries have been installed

correctly.

3. Check if batteries are charged, replace the

battery with new ones if necessary.

4. Address nearest authorized service center.

Problem

The mouse does not

work.

Модель:

RX-305 Wireless

Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024,

РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.

Уполномоченная организация вРоссии:

ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха

Энгельса, д. 75, стр. 5.

Условия гарантийного обслуживания смотрите

вгарантийном талоне или на сайте www.sven.ﬁ.

Гарантийный срок: 12 мес. Срок службы: 2 года.

Производитель: «СВЕН ПТЕ. Лимитед»,

176 Джу Чиат Роуд, №02-02, Сингапур, 427447.

Произведено под контролем «Свен Скандинавия

Лимитед», 48310, Финляндия, Котка,

Котолахдентие, 15. Сделано вКитае.

Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,

№02-02, Singapore, 427447. Produced under the

control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,

Kotka, Finland, 48310. Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland.
