USER’S MANUAL

Wireless Optical Mouse

RX-360 Art

Wireless

Congratulations on your purchase of the SVEN PC mouse!

Please read the following instructions carefully before connecting, operating

or adjusting this product. Besides, please keep this Manual in a safe place

for future reference.

This Manual and information contained in it are copyrighted. All rights

reserved.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eﬀorts to make this Manual more exact, some

discrepancies may occur. The information in this Manual is given on “as is”

terms. The author and the publisher do not bear any liability to a person or

an organization for loss or damage which has arisen from the information

contained in this Manual.

CONTENTS

1. SPECIAL FEATURES ....................................................

2. PACKAGE CONTENTS ..................................................

3. SYSTEM REQUIREMENTS ............................................

4. DESCRIPTION ...........................................................

5. INSTALLATION ...........................................................

6. TROUBLESHOOTING ................................

...................

7. TECHNICAL SPECIFICATIONS ...........................

.............

Technical support is on www.sven.ﬁ.

ENG

User’s Manual RX-360 Art

Wireless

1. FEATURES

•Blue LED advanced optical technology

•Stylish ergonomic design

• 2.4 GHz USB nano receiver included (range of action up to 10 m)

•Eﬀective on most surfaces

•High speed operation

•Resolution 1200 dpi

•USB interface

•Battery long service life (1 year)

•Installation drivers for Windows XP/Vista/7/8 are not required

•Сonvenient with laptops

2. PACKAGE CONTENTS

•Optical mouse — 1 рс

•2.4 GHz USB nano receiver — 1 рс

•AA battery — 1 рс

•User’s Мanual — 1 рс

•Warranty card — 1 рс

3. SYSTEM REQUIREMENTS

•Windows XP/Vista/7/8.

•Free USB port.

ENG

Wireless Optical Mouse

4. DESCRIPTION

aScroll wheel

bON/OFF power switch

cBattery compartment

dOptical sensor

eNano receiver

fUSB connector

Fig. 1. Top view

Fig. 2. Bottom view Fig. 3. Nano receiver

5. PREPARATION TO OPERATION

•Open the cover of the mouse battery compartment c, insert the AA

battery into the battery compartment observing the polarity and close the

cover of the battery compartment (see Fig. 4).

•Сonnect the included nano receiver eto a free PC USB port (Fig. 5).

ENG

User’s Manual RX-360 Art

Wireless

ENG

Wireless Optical Mouse

Fig. 4. Battery installation

Fig. 5. Receiver connection

AA battery

Battery

compartment

Improper installation of

batterуcan result in failure

of the mouse!

•Switch on the mouse with the power switch b(ON position). Press any

button of the mouse or rotate the scroll wheel to activate the mouse. If the

mouse has been connected correctly, it will be switched on automatically.

Battery compartment

cover

This device meets the highest standards of energy conservation.

Use the switch bon the bottom of the mouse to switch it on/off –

it will help you to extend the mouse battery life.

Important

•After ﬁnishing your work switch oﬀthe mouse with the power switch b

(OFF position). After this you can extract the receiver efrom the PC USB

port and insert it into the mouse (Fig. 6). When using the receiver again,

extract it from the mouse (Fig. 7) and connect it to the PC USB port again.

•Do not place the receiver in a metal conﬁned space (table drawer, box,

safe), as metal screen does not transmit radio signals.

•If the battery is discharged, the mouse works by ﬁts. It means that the

battery should be replaced with a new one, as it is shown in Fig. 4.

Fig. 6. Fitting the receiver

into the mouse case

Fig. 7. Extraction of the receiver

from the mouse case

ENG

User’s Manual RX-360 Art

Wireless

ENG

Wireless Optical Mouse

Notes:

• Technical speciﬁcations given in this table are supplemental infor-

mation and cannot give occasion to claims.

• Technical speciﬁcations are subject to change without notice due to

the improvement of SVEN production.

TECHNICAL SPECIFICATIONS

Parameter

OS compatibility

Mouse type

Resolution, dpi

Quantity of buttons

Interface

Dimensions, mm

Weight, g

Value

Windows XP/Vista/7/8

wireless 2.4 GHz

1200

2 + 1 (scroll wheel)

USB

94 × 40 × 58

6. TROUBLESHOOTING

Solution

1. Make sure that the nano receiver has been

inserted into a USB port and its distance to

the mouse is less than 10 m.

2. Check whether the battery has been

installed correctly.

3. Check if the battery is charged, replace the

battery with new one if necessary.

4. Address the nearest authorized service center.

Problem

The mouse does not

work.

Модель:

RX-360 Art Wireless

Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024,

РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.

Уполномоченная организация вРоссии:

ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха

Энгельса, д. 75, стр. 5.

Условия гарантийного обслуживания смотрите

вгарантийном талоне или на сайте www.sven.ﬁ.

Гарантийный срок: 12 мес. Срок службы: 2 года.

Производитель: «СВЕН ПТЕ. Лимитед»,

176 Джу Чиат Роуд, №02-02, Сингапур, 427447.

Произведено под контролем «Свен Скандинавия

Лимитед», 48310, Финляндия, Котка,

Котолахдентие, 15. Сделано вКитае.

Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,

№02-02, Singapore, 427447. Produced under the

control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,

Kotka, Finland, 48310. Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland.
