Stealth Cam G34MAX Manual de usuario
G34MAX
Instruction Manual
R3
Notice
To ensure the product is being utilized to its full potential, we recommend checking our website
for new product updates. If your camera is having an issue, please check the website to
determine you are using the latest firmware or software version.
Contact Us
TECHNICAL SUPPORT
EMAIL:
Stealthcam@gsmorg.com
Please allow 48 hours for email
response.
STEALTH CAM LLC
P.O. Box 535189
Grand Prairie, TX 75053-9504
CUSTOMER SERVICE
CONTACT & HOURS
Toll Free: 877‐269‐8490
CALL CENTER HOURS
Mon –Fri / 8 AM –5 PM (CST)
WEBSITE
www.stealthcam.com
Page 2
About Your Camera
Retina Advanced Lowlight
Sensitivity
Enhanced low light
performance for extended night
time coverage and range.
Matrix Blur Reduction
Technology
Advanced blur reduction
dramatically reduces blur
effects resulting in sharper,
clearer images.
Reflex <0.2 Second
Trigger
Ultra-fast trigger speed never
miss a crucial moment.
Multi-Zone Detection
Covers multiple zones of angle
and distance, maximizing the
camera’s triggering accuracy.
Geo-Tag GPS Meta-
Tagging
Track and recall all your favorite
locations with optional GPS
tagging
Triad 3-in-1 Technology
•Hi-Res Still Images
•HD Video records 10-180
seconds w/ Audio
•Time Lapse with PIR override
Quick Set: Fast Simple
Setup
Sets up in seconds with pre-
programmed options.
Burst Rapid-Fire Mode
Rapid-fire Burst Mode, 1-9
exposures per triggering.
Secure Lock Digital
Protection
Secure Lock offers password
protection rendering the
camera access nearly
impossible.
Page 4
Camera Overview
Front Open
Bottom
Page 5
Quick Set-up Guide
Insert Batteries and SD Card
Install 8 AA batteries and a class 10 SD card into camera.
Mount Camera
Mount the camera at the desired location using the strap mount, Python Lock cable,
Articulating Ball Joint Mount, or other desired mounting mechanism. Position the
camera so that it does not face East or West directly as the rising and setting of the
sun can cause false positive triggers.
Activate Camera
Set camera to "On" position, choose your favorite Quick Set, and place in desired
vantage point to start capturing photos of game.
Page 6
Camera Care
Operating Conditions
This camera is designed to function in 14°F –104°F (10°C - 40°C). 20%-85% relative
humidity, non-condensing.
Product Care
❖When not in use, store camera in a cool, dust-free, environment.
❖Handle camera with care
❖Camera is weather resistant only. Do no fully submerge camera in water or other liquid.
Doing so will void camera warranty.
❖Only use same type of batteries to power camera. Do not mix old and new batteries.
❖Do not touch camera lens directly. Clean only with soft lens cloth.
❖Use damp cloth to clan. DO NOT submerge camera.
❖Remove batteries when camera is not in use for an extended time.
❖Do not open camera housing to access internal parts. Doing so could damage camera
and void warranty.
Notice
Camera is an active electronic device. Attempting to service internal parts may expose
you to dangerous voltages and other risks.
Page 7
Camera Setup
Battery Installation
To remove batteries from unit, simply open camera face, and press the eject button on
the bottom right side of camera. With the tray removed, simply insert 8 new AA
batteries, being careful to match orientation marked on tray. After batteries are
inserted replace battery tray into camera. Aligning metal contacts to the bottom of the
case.
SD Card Installation
SD card slot is located on the bottom of the camera,
above the battery compartment. Insert SD card with
the label facing back of camera. Only minimal
resistance should be felt as card is inserted and a
click when the card is fully inserted.
Create QR Code
Use the Stealth Cam PROGRAM app configure custom settings for your camera with
ease. Simply download PROGRAM for iOS or Android and follow on-screen instructions
to configure your camera. When finished, hold QR code up to camera to apply settings.
Page 8
Camera Configuration
The G34MAX features 5 distinct modes of operation:
TEST | Q1 | Q2 | Q3 | CUSTOM.
Our Quick Set (Q1, Q2, Q3) configurations offer presets based off our
most popular configurations.
For alternate configurations, move slider to CUSTOM to begin
configuring options.
Name
Quality
Timeout Delay
Detail
Q1
8.0 MP
30s
3 Photos
Q2
8.0 MP
30s
1 Photo
Q3
720P
30s
10 sec Video
Once slider is in CUSTOM position, press the MENU button on camera to enter camera
configuration. In camera configuration menu, use the UP and DOWN arrows to navigate
through configuration options. To change an option, scroll to it and press ENTER button.
Once option is blinking, use the UP, DOWN, LEFT, and RIGHT arrows to change setting.
When finished, press the ENTER key once more to save configuration.
Page 9
Custom Settings
❖SETUP DATE: This setting is used by the camera to display
the correct date on the Info Bar of the image.
❖SETUP TIME: This setting is used by the camera to display
the correct time on the Info Bar of the image.
❖TIME ZONE: This setting allows you to set your camera to
different time zones.
OPTIONS:
Eastern | Central | Mountain | Pacific | Alaskan |
Hawaiian
❖TIME FORMAT: This setting is used by the camera to
change the display format for the time in the Info Bar of
the image.
OPTIONS: 12 hr | 24 hr
NOTE: If 24 hour format is selected, previous SETUP TIME
will be adjusted and AM/PM will be removed.
❖MODE: This setting will change the operation mode of the
camera. Different operation modes will have different
adjustment settings.
OPTIONS: PIR Photo | PIR Video | Time Lapse
OPERATING HOURS: This option is available for PIR
PHOTO and PIR Video settings. This feature allows you to
designate a time for the camera to be active.
OPTIONS:
24/7: Camera is always on.
SCHEDULED: Selecting this will allow you to enter a
time range for the camera to be active and
operational. Camera will not take photos outside of
defined time range.
START TIME (HH:MM): Start time for camera to
be active.
END TIME (HH:MM): Time at which you want
the camera to no longer be operational.
CAMERA NAME: This setting is used to adjust the camera
name. Camera name can be up to 13 characters long using
alpha (A-Z) numeric (0-9) characters.
TEMPERATURE: This setting is used to change temperature
format on Info Bar.
OPTIONS: Farhenheit | Celsius
INFO BAR: This setting is used to tell the camera whether
the Info Bar should be displayed at the bottom of images
or video.
OPTIONS: On | Off
Page 10
