Wildview STC-TGL1 Manual de usuario
STC-TGL1
User’s Manual
Toll Free Customer Support 1-888-304-6125
www.wildviewcam.com
Version 1.2 08/06
STC-TGL1
www.wildviewcam.com Toll Free 888-304-6125
2
For Customer Service or Warranty Information Call Toll Free
888-304-6125
WILDVIEW
P.O. Box 535189
Grand Prairie, TX 75053-5189
www.wildviewcam.com
Wildview Scouting Camera Limited Warranty
Your Wildview Scouting Camera is covered by a One Year Limited
Warranty on parts & labor from the date of purchase. The warranty
covers defects in workmanship & materials. The warranty does not
apply to units, which have been damaged or abused intentionally or
unintentionally. Tampering with or altering the unit will void the warranty.
Any unauthorized service will void warranty. Original sales receipt must
be produced for any warranty service. Questions call 888-304-6125.
STC-TGL1
www.wildviewcam.com Toll Free 888-304-6125
3
Manual Contents
Camera overview 4
Camera kit contents 7
Battery and memory Installation 8
Set up & Using the camera 10
Mounting the camera 11
Viewing images 15
Saving and Deleting images 18
Memory compatibility chart 20
Technical Specs 21
General Information 23
STC-TGL1
www.wildviewcam.com Toll Free 888-304-6125
4
Camera overview
Front view Side view
STC-TGL1
www.wildviewcam.com Toll Free 888-304-6125
5
Open view image with major parts indication
STC-TGL1
www.wildviewcam.com Toll Free 888-304-6125
6
Picture / Image Capacity
SD card VGA
300K Pixel
QVGA
76K Pixel
16MB 130 530
32MB 260 1060
64MB 520 2,120
128MB 1,040 4,240
256MB 2,080 8,480
512MB 4,160 16,960
NOTE: Picture / Image Capacity Chart provides approximate number of
images or AVI movies based on resolution setting and the size of
memory card. These figures may vary depending on the amount of
detail in the image.
STC-TGL1
www.wildviewcam.com Toll Free 888-304-6125
7
Camera kit contents
• Model STC-TGL1 VGA Digital Scouting Camera
• CDROM (Contains camera driver only)
• User Manual.
• 1.5M USB cable.
• Strap.
STC-TGL1
www.wildviewcam.com Toll Free 888-304-6125
8
Battery & memory installation
The Wildview STC-TGL1 VGA Digital Scouting Camera is designed
to operate using alkaline batteries.
NOTE: Always have camera in OFF position when installing or
removing batteries.
Batteries “C” cell
The internal battery compartment accepts 4 “C” cell batteries. Be
sure to use high quality brand name alkaline batteries. Install
batteries in correct polarity (+/-) as noted inside battery
compartment.
Memory Options
Your Wildview scouting camera is equipped with 8MB built in
SDRAM memory. The camera is also equipped with an
expandable media card slot capable accepting up to 512MB SD
card (sold separately). With no memory card inserted into the slot,
the camera will use the built in 8MB SDRAM memory. If a SD
card is inserted into the slot then the camera will bypass the built
STC-TGL1
www.wildviewcam.com Toll Free 888-304-6125
9
in memory and utilize the SD memory. The front counter display
will show the number of images on the built in memory unless the
expansion card is inserted at which point the counter will only
show the number of images in the expansion card.
Inserting SD card
Make sure camera is in the OFF position whenever adding or
removing memory.
• Insert SD memory card in to the SD card slot completely and in
the correct direction as shown on the inside of the housing.
• To remove the SD memory card, depress the SD card and pull
out the card gently.
SD cards must be clean (no images from other sources.)
STC-TGL1
www.wildviewcam.com Toll Free 888-304-6125
10
Set up
• Time out: To set the amount of preset time in minutes the
camera will sleep between PIR triggering.
• Resolution: The resolution selection that you have selected.
o High (VGA): Select this option to capture a VGA image
quality.
o Low (QVGA): Select this option to capture a QVGA image
quality.
Using the camera
Select the time out and resolution setting before you turn on the
camera.
1. Select the time out interval by sliding the time out toggle switch to
the desire preset time interval in minutes. 1 / 5 / 10 / 20 minutes.
2. Select the resolution setting by sliding the resolution toggle switch
to the desire resolution setting. Hi / Lo resolution.
Once the program setting has been completed your Wildview scouting
camera is ready for field use.
