StarTech.com MSTMDP123DP Manual de usuario

Manual Revision: 06/19/2013

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

MSTMDP123DP

3-Port Multi Monitor Mini DisplayPort

to DisplayPort® MST Hub

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Product Overview ..................................................................................1

Front View .................................................................................................................................................... 1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Installation ..............................................................................................2

Microsoft® Windows® Operation ......................................................................................................... 2

Apple OS X® Operation ........................................................................................................................... 5

Supported Video Resolutions............................................................................................................... 6

Specications..........................................................................................7

Technical Support ..................................................................................8

Warranty Information............................................................................8

Instruction Manual

Product Overview

Front View

Packaging Contents

• 1x 3-Port Multi Monitor Mini DisplayPort to DisplayPort® MST Hub

• 1x Power Adapter

• 1x Instruction Manual

System Requirements

• Mini DisplayPort 1.2 enabled computer system/video card

• Up to 3 DisplayPort enabled display devices (e.g. monitor) with cabling

Integrated Mini

DisplayPort

Cable

DP #1 DP #2 DP #3

Instruction Manual

Installation

1. Ensure your computer system and DisplayPort Displays are powered o.

2. Connect the integrated Mini DisplayPort cable into the Mini DisplayPort connector

on the host computer system/video card.

3. Connect the DisplayPort monitor/display device(s) into the DisplayPort #1/#2/#3

connectors on the MSTMDP123DP MST Hub.

4. Power on the monitor/display device(s).

5. Turn on the computer system.

6. The system will now detect the MST Hub, and add the attached displays to the

Display Settings of the System.

Microsoft® Windows® Operation

With a DisplayPort 1.2 compatible video card, Microsoft Windows® will recognize the

individual Displays (up to 3) and can either Extend or Duplicate the main Monitor.

Adjust video settings in Microsoft Windows®

1. Right click the Windows Desktop and select “Screen Resolution”. The Display Settings

window appears.

Instruction Manual

NOTE: Each monitor connected is represented by a number displayed under “Change

the appearance of your displays”. To determine which number corresponds with each

display click the Identify button.

2. To adjust the Resolution, click on the number that corresponds with the monitor

you wish to adjust, and select the drop down menu next to “Resolution:”.

Instruction Manual

3. To Choose whether the Monitor will Duplicate or Extend your main Monitor, select

the number that corresponds with the Monitor you wish to adjust, and select the

drop down menu next to “Multiple Displays:”. “Extend these displays” will extend

your monitor main onto the selected monitor. “Duplicate these Displays” will show

the same image as your main monitor on the selected monitor.

Instruction Manual

Apple OS X® Operation

With a DisplayPort 1.2 compatible video card Apple OS X® will extend your Desktop

onto the secondary monitors, and allow you to span a single Desktop expansion across

each monitor connected to the MSTMDP123DP.

Adjust Video settings to allow Spanning across all connected monitors in Apple

OS X®

1. Click System Preferences-> Displays

2. To Span the length of the attached monitors select a wide resolution from the

“Resolutions”selection pane. Anything beyond your main monitors max resolution

will extend onto the secondary monitors.

Instruction Manual

3. To place your spanned monitors, select the Arrangement tab. Your Main display will

be shown with the spanned monitor next to it. You can click and drag to match your

physical Monitor arrangement.

Supported Video Resolutions

Resolution Refreshing Rate Reduced

Blanking Pixel Frequency

2560 x 1600 60Hz RB 268 MHz

1920 x 1080 60Hz RB 148.5 MHz

1600 x 1200 60Hz 162 MHz

Instruction Manual

Specications

Video Signal DisplayPort

Number of Ports 3

External Connectors 1x Mini DisplayPort Male

3x DP Female

Maximum Display Resolution

One Display: 2560 x 1600

Two Displays: 1920 x 1200

Three Displays: 1920 x 1200
