Introduction

Thank you for purchasing a StarTech.com SATA II PCI Express Adapter.

Supporting SATA II data transfer speeds of up to 3.0 Gbps, this dual

port SATA II PCI Express Card offers users a cost-effective solution

for connecting additional SATA II drives and provides RAID capable

operation.

Features

Provides two internal SATA II connections•

Supports two independent SATA II channels (separate logic and•

FIFO)

Supports Native Command Queue (NCQ) operation•

Supports 1-Lane 2.5Gbps Express bus•

Package contents

This package should contain:

1 x PCI Express SATA adapter card•

1 x Driver CD•

1 x Instruction Manual•

1 x Low Proﬁle Bracket•

System Requirements

Microsoft® Windows® 2000/XP/2003/Vista™ or Linux®

PCI Express enabled computer system with available PCI Express slot

Instruction Manual

Installation

Please note: If you are performing a new operating system installation

and wish to boot from one of the drives being connected to PEXSATA22I,

please copy the following ﬁles from the included Driver CD to a blank

ﬂoppy disk that can be used during OS installation:

jgogo.sys

jraid.cat

Jraid.sys

jraid_f.inf

txtsetup.oem

For further instruction on how to install the card and necessary drivers

for use with a fresh (boot) OS drive, please skip to the section entitled

Windows Vista™ Fresh Installation or Windows 2000/XP/2003 Server

Fresh Installation as applicable. Otherwise, if you will be installing

PEXSATA22I to connect a secondary (non-boot) drive, proceed as

follows:

Shut down all power connected to the computer, as well as all1.

devices connected to the computer peripherally (i.e. Printers,

Monitors, Scanners etc.). As an added step to ensure safe

installation, unplug the power supply from the computer.

Remove the computer cover, allowing access to the motherboard2.

and available slots. For more detailed instruction on how to perform

this step, please refer to the documentation that was included with

WARNING! PCI Express cards, like all computer equipment,

can be severely damaged by static electricity. Be sure that you

are properly grounded before opening your computer case or

touching your card. StarTech.com recommends that you wear an

anti-static strap when installing any computer component. If an

anti-static strap is unavailable, discharge yourself of any static

electricity build-up by touching a large grounded metal surface

(such as the computer case) for several seconds. Also be careful

to handle the card by its edges and not the gold connectors.

Instruction Manual

your computer at the time of purchase.

Locate an empty PCI Express slot, removing the metal bracket3.

covering the accompanying empty port/socket on the rear panel of

the computer chassis.

Position the card above the open PCI Express slot, ensuring that the4.

card is properly aligned with the slot. Insert the card ﬁrmly into the

slot, distributing force evenly across the length of the board.

Once inserted, secure the card into the adjoining socket (previously

covered by metal bracket, on the rear panel of the computer

chassis), using the correct size screw (if necessary, please consult

documentation that accompanied purchase of computer).

Connect the desired SATA drives.5.

Driver Installation (Non-boot drives)

Power on the computer.1.

Locate and execute the Setup.exe ﬁle on the Driver CD (included).2.

This program will copy driver ﬁles onto the host system. If you

wish to perform the installation manually, please ensure that you

have speciﬁed the correct ﬁle when asked (titled: JMB36X_WinDrv_

WHQL_R1.17.31WHQL\R1.17.31.00\Driver\x32jraid_i.inf ). Once

the ﬁles have been copied, restart your computer as prompted.

After the system reboots, Windows will locate the new hardware3.

RAID Controller and install the necessary driver.

Replace the computer chassis, and power on the computer.4.

Verifying Successful Driver Installation

Once the computer has been powered on following the driver installation

and the connection of the desired drive, you may wish to verify that the

necessary ﬁles have been installed properly. To do so:

Right-click on1. My Computer and select Manage.

In the left pane of the Computer Management window, select2. Device

Manager.

Instruction Manual

In the right pane of the Computer Management window, click on3.

SCSI and RAID Controllers. Here, you should ﬁnd listed JMicron

JMB36X RAID Controller and JMicron JMB36X RAID Processor,

upon successful installation.

Windows Vista™ Fresh Installation

Follow the instructions in this section if you are performing a new

(bootable) installation of Windows Vista™ on a drive attached to

PEXSATA22I:

Shut down all power connected to the computer, as well as all1.

devices connected to the computer peripherally (i.e. Printers,

Monitors, Scanners etc.). As an added step to ensure safe

installation, unplug the power supply from the computer.

Remove the computer cover, allowing access to the motherboard2.

and available slots. For more detailed instruction on how to perform

this step, please refer to the documentation that was included with

your computer at the time of purchase.

Locate an empty PCI Express slot, removing the metal bracket3.

covering the accompanying empty port/socket on the rear panel of

the computer chassis.

Position the card above the open PCI Express slot, ensuring that the4.

card is properly aligned with the slot. Insert the card ﬁrmly into the

slot, distributing force evenly across the length of the board.

Once inserted, secure the card into the adjoining socket (previously

covered by metal bracket, on the rear panel of the computer

chassis), using the correct size screw (if necessary, please consult

documentation that accompanied purchase of computer).

Attach PEXSATA22I to the Serial ATA drive, using a SATA (data)5.

cable. Similarly, attach an available SATA power connector (provided

by computer power supply) to the drive.

Repeat steps 4 and 5 for each remaining hard drive that will be6.

connected to PEXSATA22I.

Replace the computer cover and re-connect all power to the7.

computer.

Instruction Manual

Start the computer as you normally would to perform an operating8.

system installation, ensuring that the Windows Vista™ installation

CD/DVD is present in the drive, and the BIOS has been suitably

adjusted to boot from the CD/DVD Drive.

When the Windows Install screen appears, ﬁll in the necessary9.

information and click Next. Follow the operating system instructions

until a page appears asking “Where do you want to install

Windows?”. From here, click on Load Driver.

You will then be asked to provide the necessary driver ﬁles. The ﬁles10.

can be accessed by CD, DVD, or USB Flash Drive. As such, connect

the drivers to the computer using one of these methods, and click

Browse to specify the location of the ﬁles. Then, click Next.

Windows Vista™ will then install the necessary ﬁles, after which the11.

drive connected to PEXSATA22I will be recognized as a usable

drive.

Select the drive on which you wish to install the operating system,12.

and click Next, to resume normal operating system installation

Windows 2000/XP/2003 Server Fresh Installation

Follow the instructions in this section if you are performing a new

installation of Windows 2000/XP/2003, and you wish to boot from a drive

attached to PEXSATA22I.

Note: Ensure you’ve created the necessary boot disk (as outlined on

page 2) prior to installation, as it will be required in order to properly

conduct the OS installation.

Shut down all power connected to the computer, as well as all1.

devices connected to the computer peripherally (i.e. Printers,

Monitors, Scanners etc.). As an added step to ensure safe

installation, unplug the power supply from the computer.

Remove the computer cover, allowing access to the motherboard2.

and available slots. For more detailed instruction on how to perform

this step, please refer to the documentation that was included with

your computer at the time of purchase.

Locate an empty PCI Express slot, removing the metal bracket3.

covering the accompanying empty port/socket on the rear panel of

Instruction Manual

the computer chassis.

Position the card above the open PCI Express slot, ensuring that the4.

card is properly aligned with the slot. Insert the card ﬁrmly into

the slot, distributing force evenly across the length of the board.

Once inserted, secure the card into the adjoining socket (previously

covered by metal bracket, on the rear panel of the computer

chassis), using the correct size screw (if necessary, please consult

documentation that accompanied purchase of computer).

If a ﬂoppy drive is available on the host system, attach PEXSATA22I5.

to the Serial ATA drive(s), using a SATA (data) cable. If no ﬂoppy

drive is available, please skip to the section entitled Installation

Without a Floppy Drive.

Repeat steps6. 1-5 for the remaining hard drives that will be

connected as necessary.

Replace the computer cover and re-connect all power to the7.

computer.

Turn on the computer. Upon ﬁrst boot, Windows will instruct you to8.

Press [ F6 ] for third party SCSI or driver installation. As such,

please hit [ F6 ] to continue.

Press9. [ S ] when setup asks if you want to specify an additional

device, and insert the boot diskette into your ﬂoppy drive, then press

[Enter]

Select [JMicron Serial ATA Adapter], then press [Enter].

Press [Enter] again to ﬁnish driver installation, then follow the on-

screen instructions to complete the Windows installation.

Please note: If a Security Alert warning pops up, click Yes to

proceed. Follow the setup instructions to select your choice for

partition and ﬁle system. After setup examines your disks, it will copy

ﬁles from the CD to the hard drive selected above, and restart the

system. After restart, the setup process will resume installing the

new drive(s).

Instruction Manual

Specications

Bus Interface PCI Express 1.0a (x1 connector)

Chipset JMicron JMB363

Connectors 2 x SATA 7-pin male

Maximum Data Transfer Rate 3Gbps

Compatible Operating Systems Windows 2000/XP/Server 2003/

Vista/7 (32/64-bit), Linux

Regulatory Certiﬁcations CE/FCC/ROHS

Weight 44.2 g (1.42 oz )

Dimensions (L x W x H) 102 x 120 x 20mm

(1.7 x 4.74 x .78”)

Otros manuales para PEXSATA22I

Tabla de contenidos

Otros manuales de Tarjeta PCI de StarTech.com

StarTech.com

StarTech.com PEXUSB311AC2 Manual de usuario

StarTech.com

StarTech.com PEXSATA22 Manual de usuario

StarTech.com

StarTech.com 8STPEXUSB3S25 Manual de usuario

StarTech.com

StarTech.com PEXUSB3S2E2I Manual de usuario

StarTech.com

StarTech.com PEX8S1050LP Manual de usuario

StarTech.com

StarTech.com PEX8S1052 Manual de usuario

StarTech.com

StarTech.com PEX400USB2 Manual de usuario

StarTech.com

StarTech.com PEXHDCAP4K Manual de usuario

StarTech.com

StarTech.com PEX100SFP Manual del sistema

StarTech.com

StarTech.com PEXUSB311AC2 Manual de usuario

StarTech.com

StarTech.com PEX16S952LP Manual de usuario

StarTech.com

StarTech.com PEX2S553B Manual de usuario

StarTech.com

StarTech.com PEX2S1050 Manual de usuario

StarTech.com

StarTech.com PEXUSB312C Manual de usuario

StarTech.com

StarTech.com PEX4S553S Manual de usuario

StarTech.com

StarTech.com 8P6G-PCIE-SATA-CARD Manual de usuario

StarTech.com

StarTech.com PEX2S953 Manual de usuario

StarTech.com

StarTech.com PEXESATA2 Manual de usuario

StarTech.com

StarTech.com PEX1000MMSC Manual de usuario

StarTech.com

StarTech.com PEX2S952PW Manual de usuario

StarTech.com

StarTech.com PEXUSB7LP Manual de usuario

StarTech.com

StarTech.com PEXSAT34RH Manual de usuario

StarTech.com

StarTech.com PCIESATA2I Manual de usuario

StarTech.com

StarTech.com PEXUSB312A3 Manual de usuario

Manuales populares de Tarjeta PCI de otras marcas

ERMA

ERMA SSI 1417 Manual de usuario

SIIG

SIIG CyberSerial Dual PCI Instrucciones de montaje

Moxa Technologies

Moxa Technologies CP-102E Manual de usuario

I-Bus

I-Bus IBC2602 Manual de usuario

Exsys

Exsys EX-60102 Manual de usuario

Chelsio Communications

Chelsio Communications T5 Series Manual de usuario

Conrad Electronic

Conrad Electronic 97 46 71 Manual de usuario

Micro Innovations

Micro Innovations USB650A Manual de usuario

KTI Networks

KTI Networks KF-310 Manual de usuario

Asus

Asus SpaceLink WL230 Manual de usuario

SIIG

SIIG SC2475 Manual de usuario

TRENDnet

TRENDnet TEW-703PI Manual de usuario

Belkin

Belkin F5D7000F Manual de usuario

Pericom

Pericom PI7C7100 Manual de usuario

ADLINK Technology

ADLINK Technology cPCI-3548 Manual de usuario

Digium

Digium TE200 Series Manual de usuario

Allo.com

Allo.com 2nd Gen E1/T1/J1 Manual de usuario

Western Digital

Western Digital FireWire PCI Adapter Manual de usuario
