StarTech.com PEXUSB4DP Manual de usuario

Manual Revision: 03/30/2011

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

For the most up-to-date information, please visit: www.startech.com

PEXUSB4DP

4 Port PCI Express Low Prole High Speed USB Card

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment

o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit dierent from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected

names and/or symbols of third-party companies not related in any way to StarTech.com.

Where they occur these references are for illustrative purposes only and do not represent an

endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to

which this manual applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges

that all trademarks, registered trademarks, service marks, and other protected names and/or

symbols contained in this manual and related documents are the property of their respective

holders.

Instruction Manual i

Table of Contents

Introduction........................................................................................................................................................1

Packaging Contents ................................................................................................................................1

System Requirements ............................................................................................................................1

Installation............................................................................................................................................................2

Hardware Installation..............................................................................................................................2

Driver Installation......................................................................................................................................3

Verifying Installation................................................................................................................................3

Specications.....................................................................................................................................................4

Technical Support...........................................................................................................................................5

Warranty Information....................................................................................................................................5

Instruction Manual 1

Introduction

This 4 Port Low Prole PCI Express USB 2.0 Adapter Card lets you connect up to four USB

2.0 peripherals (3 external and 1 internal) to your computer at data transfer rates of up to

480 Mbps. Congured with a low prole bracket, it also includes a full standard bracket.

Packaging Contents

• 1 x PEXUSB4DP adapter card

• 1 x Full Prole Bracket

• 1 x Driver CD

• 1 x Installation Manual

System Requirements

• PCI Express (PCIe) enabled computer system

• Microsoft Windows®2000/XP/Vista/7 (32/64-bit), Mac OS®X, or Linux®

Instruction Manual 2

WARNING! PCI Express cards, like all computer equipment, can be severely damaged by static

electricity. Be sure that you are properly grounded before opening your computer case or

touching card. StarTech.com recommends that you wear an anti-static strap when installing

any computer component. If an anti-static strap is unavailable, discharge yourself of any static

electricity build-up by touching a large grounded metal surface (such as the computer case) for

several seconds. Also be careful to handle the card by its edges and not the gold connectors.

Hardware Installation

1. Turn your computer o and any peripherals connected to the computer (ie. Printers, external

hard drives, etc.). Unplug the power cable from the rear of the power supply on the back

of the computer.

2. Remove the cover from the computer case.

3. Locate an open PCI Express slot and remove the metal cover plate on the rear of the

computer case. Note that this card will work in PCI Express slots of additional lanes (ie. x4,

x8 or x16 slots)

4. Insert the card into the open PCI Express slot and screw the bracket to the rear of the case.

NOTE: If the computer case only accepts full prole cards, then remove the low prole

bracket on the card, by removing the screws holding it to the card and replace with the

supplied full sized bracket.

5. OPTIONAL:Plug in the SP4 oppy power connector from the computer power supply to the

card.

6. Place the cover back onto the computer.

7. Insert the power cable into the socket on the power supply.

Installation

Instruction Manual 3

Driver Installation

Windows 2000/XP/Vista, Mac OS X, Linux

No driver installation is required for these operating systems, as this adapter card is natively

supported, so the drivers are already installed.

Verifying Installation

Windows 2000/XP/Vista/7

From the main desktop, right-click on “My Computer” (“Computer” in Vista/7), then select

Manage. In the new Computer Management window, select Device Manager from the left

window panel.

There should be new“VIA” devices listed under the“Universal Serial Bus Controllers”category.

Instruction Manual 4

Bus Interface PCI Express rev 1.1,

x1 connector

USB Specication EHCI rev. 0.95

UHCI rev. 1.1

Connectors

3 x USB type A (external)

1 x USB type A (internal)

1 x SP4 power (internal)

Chipset VIA VT6212L

Pericom PI7C9X110BNBE

Maximum Data Transfer Rate 480 Mbps

Compatible Operating Systems Windows 2000/XP/Vista/7 (32/64-bit),

Mac OS X, Linux

Specications

Instruction Manual 5

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commit-ment to provide industry-

leading solutions. If you ever need help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and downloads.

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials and workmanship for the

periods noted, following the initial date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor

costs only. StarTech.com does not warrant its products from defects or damages arising from misuse,

abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors,

employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, conse-

quential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to

the use of the product exceed the actual price paid for the product. Some states do not allow the exclu-

sion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old

and new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they

need to go. Just talk to one of our tech advisors or visit our website. You’ll be

connected to the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products

and to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
