StarTech.com SAT3510BU3 Manual de usuario

Manual Revision: 01/31/2013

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

SAT3510BU3

3.5in SuperSpeed USB 3.0 SATA Hard Drive

Enclosure w/ Fan

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and

Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction ............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements .............................................................................................................................. 1

Installation ..............................................................................................3

Hardware Installation .............................................................................................................................. 3

Driver Installation ...................................................................................................................................... 3

Verifying Installation ................................................................................................................................ 4

Using the Enclosure ...............................................................................4

Specications ..........................................................................................6

Technical Support ..................................................................................7

Warranty Information ............................................................................7

Instruction Manual

Introduction

The StarTech.com SAT3510BU3 USB 3.0 External Hard Drive Enclosure lets you connect

a 3.5” SATA hard drive through USB 3.0. A cutting edge external storage solution

that lets you harness the speed and performance supported by the SuperSpeed USB

interface. Supporting data transfer rates of up to 5 Gbps, 10x that of USB 2.0, and

60% faster than SATA 3Gbps eSATA, plus backward compatible with USB revisions 2.0

(480Mbps) and 1.1 (12Mbps), so the enclosure can be used with older systems that

don’t support USB 3.0 yet.

Packaging Contents

• SAT3510BU3 enclosure

• USB 3.0 A-B cable

• Universal Power Adapter

• 3 x Power Adapter plugs (NA, UK, EU)

• Foam pad

• Instruction Manual

System Requirements

• Internal 3.5” SATA compatible storage drive

• USB enabled computer system with available port

• Microsoft® Windows® 2000/XP/Server 2003/Vista/Server 2008 R2/7 (32/64-bit) or

Apple® Mac OS® X or Linux®

Instruction Manual

Power switch

USB 3.0

type B Power

connector

Fan switch

Power/Activity

LED

Cooling Fan

Rear View

Side View

Instruction Manual

Installation

WARNING: Hard drives require careful handling, especially when being transported. If

you are not careful with your hard disk, lost data may result. Always handle your hard

drive and storage device with caution.

Hardware Installation

1. Set the enclosure on a at surface, with the cooling fan facing downwards.

2. On the top panel, remove the two small screws at the corners. Remove the top

panel.

3. Located at the opposite end from the internal SATA connectors is a small plastic

wedge. Flip the wedge up and out of the enclosure.

4. Place the 3.5” SATA hard drive into the enclosure and then slide it into the SATA

connectors.

5. Flip the wedge down again, to secure the hard drive. For thinner hard drives, an

optional, thicker foam pad is included.

6. Place the top panel back on to the enclosure and fasten the two corner screws.

7. Connect the external power adapter to the enclosure and ip the power switch to

the “1” position. The enclosure and hard drive will power up.

8. Connect the USB cable from the enclosure to the computer system.

Driver Installation

No driver installation is required for USB enabled operating systems, as this enclosure

uses natively installed drivers. Supported operating systems should automatically

detect and install the enclosure.

Instruction Manual

Verifying Installation

Windows 2000/XP/Server 2003/Vista/7

From the main desktop, right-click on “My Computer” (“Computer” in Vista/7), then

select Manage. In the new Computer Management window, select Device Manager

from the left window panel.

Double-click on the “Disk Drives” option. A new disk drive should be listed under this

category. It will typically contain the make/model of the hard drive you have installed

in the enclosure.

Using the Enclosure

Windows 2000/XP/Vista/7

If you are using a brand new hard drive that does not contain any data, then you will

rst need to prepare the hard drive for use. From the main desktop, right-click on

“My Computer” (“Computer” in Vista/7), then select Manage. In the new Computer

Management window, select Disk Management from the left window panel.

Instruction Manual

Locate the Disk that says it is “Unallocated” (check hard drive capacity to conrm it’s the

correct hard drive) and then right-click in the section that says “Unallocated” and select

“New Partition”.

The New Partition Wizard will appear. Follow the instructions in the wizard to

complete setting up the drive. Once complete, the Disk should show up as “Healthy”

with a drive letter assigned (ie. E:). This drive letter should now appear within My

Computer.

If you are installing a hard drive that already has data on it, then after plugging it in, the

drive should automatically show up with a drive letter assigned within My Computer.

Instruction Manual

Specications

Bus Interface USB 3.0

Chipset ID ASMedia ASM1051

Connectors 1 x USB 3.0 type B

1 x DC Power

Fans 1 x 80mm

LEDs 1 x Power/Activity

Maximum Data Transfer Rate USB 3.0: 5Gbps

Compatible Hard Drives 3.5” SATA drive (internal)

up to 2TB capacity

Power Adapter 12VDC, 2A, center positive

Operating Temperature 0°C ~ 60°C (32°F ~ 140°F)

Storage Temperature 0°C ~ 70°C (-4°F ~ 158°F)

Humidity 10 ~ 90% RH

Dimensions 143.0mm x 52.1mm x 180.0mm

Weight 580g

Compatible Operating Systems

Windows 2000/XP/Server 2003/Vista/

Server 2008 R2/7 (32/64), Mac OS X,

Linux

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.
