StarTech.com S3520BU33ER Manual de usuario

Manual Revision: 09/16/2013

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

S3520BU33ER / S3520WU33ER

USB 3.0/eSATA Dual 3.5” SATA HDD

Enclosure

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Product Diagram ....................................................................................2

Front View .................................................................................................................................................... 2

Rear View...................................................................................................................................................... 2

Hardware Installation............................................................................3

Congure RAID .......................................................................................6

RAID Modes................................................................................................................................................. 6

Set RAID........................................................................................................................................................ 6

How to Use ..............................................................................................7

Connecting the Hard Drive.................................................................................................................... 7

LED Indicator .............................................................................................................................................. 7

Disconnecting the Hard Drive.............................................................................................................. 7

Initializing the Hard Drive ...................................................................................................................... 8

Specications..........................................................................................9

Technical Support ..................................................................................10

Warranty Information............................................................................10

Instruction Manual

Introduction

Packaging Contents

• 1 x USB 3.0/eSATA HDD RAID Enclosure

• 1 x USB 3.0 Cable

• 1 x eSATA Cable

• 1 x Universal Power Adapter and Clips (NA/UK/EU)

• 1 x Rubber foot set

• 1 x Instruction Manual

System Requirements

• 1 x Computer system with available USB 3.0 (5 Gbit/s) port/USB 2.0 port (480Mbps)

or eSATA port / Microsoft® Windows® 2000/XP/Server 2003/Vista/Server 2008 R2/7/8

(32/64-bit) / Apple® Mac® OS 9.x/10 / Linux®

• 2 x 3.5” SATA hard drives

Instruction Manual

Product Diagram

Front View

1. Front Panel

2. Drive Activity LEDs

3. Power Button

Rear View

1. eSATA Port

2. RAID Switch

3. Set RAID Button

4. USB 3.0 Port

5. Power Jack

6. Drive Fan

12 3

Instruction Manual

2. Slide the “front panel” upward toward the top of the enclosure.

Hardware Installation

WARNING! Hard drives and storage enclosures require careful handling, especially

when being transported. If you are not careful with your hard disk, lost data may

result. Always handle your hard drive and storage device with caution. Be sure that

you are properly grounded by wearing an anti-static strap when handling computer

components or discharge yourself of any static electricity build-up by touching a large

grounded metal surface (such as the computer case) for several seconds.

1. Using a Phillips® head screw driver (not included) remove the screw from the

bottom of the enclosure.

Instruction Manual

4. Slide each of your hard drives into the bay

3. Lift the panel o to reveal the drive bays.

Instruction Manual

5. Place the front panel back on by placing it over the drive bay, and sliding it

into place.

6. Replace the screw using the Phillips head screw driver.

7. (optional) If using eSATA, connect the the included eSATA cable from an available

eSATA port on your computer system to the eSATA port on the enclosure.

8. (optional) If using eSATA, connect the the included eSATA cable from an available

eSATA port on your computer system to the eSATA port on the enclosure.

9. (optional) If using USB, connect the the included USB 3.0 cable from an available

USB port on your computer system to the USB 3.0 port on the enclosure.

10. Turn on the unit, by Pushing the Power button on the front panel.

Instruction Manual

Congure RAID

RAID Modes

JBOD JBOD

COMBINE Span (Big)

MIRRORING RAID1

STRIPING RAID0

Set RAID

1. Turn o the unit, by Pushing the Power button on the front panel.

2. Set the RAID switch to the RAID mode of your choice.

3. Press and hold the “Set RAID button” as you power on the enclosure by pressing the

“Power button”.

4. Once the enclosure has turned on, release the “Set RAID button”.

5. Your Desired RAID conguration is now set.

Note: When changing RAID conguraitons, follow the above steps to set the unit back

to JBOD (JBOD), before setting to a dierent conguration.

Instruction Manual

How to Use

Connecting the Hard Drive

Once the enclosure has been attached to a computer, and your RAID conguration has

been set the drivers will install automatically, and the inserted drives will be accessible

as though they were installed within the system.

Prior to using the drive array, it will need to be formatted according to your operating

system requirements. Refer to Initializing the Hard Drive

LED Indicator

The hard drive enclosure oers LED indicators for each drive, so you can monitor drive

activity. The LED will ash while the hard drive is being accessed. Do not remove the

enclosure from the host computer while the LED is ashing, as it could damage the

drive or the enclosure, resulting in data loss.

Disconnecting the Hard Drive

Windows

1. Select the “Safely remove Hardware and Eject Media” icon, located in the task bar.

2. Select the Mass Storage Device from the list that appears.

3. Wait for the message indicating that it is now safe to remove the device.

Note: Removing the connected drive prior to receiving notication that it is safe to

do so, could result in losing or corrupting data stored on the drive. Once the Safe

to Remove Hardware message appears, please disconnect the enclosure from the

computer by removing the USB connection.

Mac OS X

To safely disconnect the attached drive from the host computer, close any windows

listing the contents of the removable drive. Once all windows are closed, click on the

USB storage icon on the desktop, and drag it to the Trash Can icon on the desktop.

Allow 5 seconds before physically removing the enclosure/drive from the computer.
