SATDOCK4U3RE

4 Bay 1:3 USB 3.0/eSATA to SATA/IDE

Standalone Hard Drive Duplicator Dock

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation.This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and

Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual i

Table of Contents

Introduction............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Front View .................................................................................................................................................... 2

Rear View...................................................................................................................................................... 2

Installation ..............................................................................................3

Hardware Installation (Docking Station/PC Mode)....................................................................... 3

Hardware Installation (Duplicator) ..................................................................................................... 4

Driver Installation...................................................................................................................................... 4

How to Use ..............................................................................................5

Menu Options............................................................................................................................................. 5

Duplicator (Copy) Mode ......................................................................................................................... 6

Specications..........................................................................................7

Technical Support ..................................................................................8

Warranty Information............................................................................8

NOTE: Pressing the power button to turn o a hard drive

will momentarily restart the other drive bays. Ensure the

other drives are not being accessed when powering o

any of the drives.

Instruction Manual 1

Introduction

The SATDOCK4U3RE USB 3.0 and eSATA Standalone 1-to-3 Hard Drive Duplicator

allows for a single SATA hard drive to be duplicated/cloned on up to three other SATA

drives simultaneously. It can also function as a regular 4-bay hard drive docking station

by connecting to a host computer system. Able to perform 1:3 sector duplication,

including HPA, from a single SATA drive onto three others simultaneously at a rate of

up to 72 MB/s, this duplicator can save time and eort. As an external dock, it can be

connected to your host computer through USB 3.0 or eSATA, providing data transfer

speeds up to 5 Gbps or 3Gbps respectively from the hard drives to your computer

system. Features Quick and Secure Erase functions and support for IDE hard drives with

an included SATA to IDE hard drive adapter (SAT2IDEADP).

Packaging Contents

• 1 x SATA Duplicator Dock

• 1 x USB 3.0 Cable

• 1 x eSATA Cable

• 1 x SATA to IDE Adapter

• 1 x 40-pin IDE Cable

• 1 x 44-pin to 40-pin IDE Cable

• 1 x SP4 to LP4 Power Cable

• 1 x Package of Mounting Screws

• 1 x Universal Power Adapter (NA/JP, UK, EU, ANZ)

• 1 x Instruction Manual

System Requirements

• Available USB and/or eSATA* port(s) on computer system

*eSATA port requires Port Multiplier support

• Available AC electrical outlet

• Microsoft®Windows®2000/XP/Server 2003/Vista/Server 2008 R2/7 (32/64-bit), or

Apple®Mac OS®X, or Linux®

*If using USB with the Apple Mac OS operating system, this device will function in USB 2.0 mode only as

USB 3.0 is not currently supported by Apple. eSATA is fully compatible.

Instruction Manual 2

Front View

Rear View

Instruction Manual 3

Installation

WARNING! Hard drives and storage enclosures require careful handling,

especially when being transported. If you are not careful with your hard disk,

lost data may result. Always handle your hard drive and storage device with

caution. Be sure that you are properly grounded by wearing an anti-static

strap when handling computer components or discharge yourself of any

static electricity build-up by touching a large grounded metal surface (such

as the computer case) for several seconds.

Hardware Installation (Docking Station/PC Mode)

1. Connect the external power adapter from the hard drive docking station to an AC

power outlet.

2. Insert 2.5in or 3.5in hard drive(s) into the top loading drive bay(s). Make sure that

the SATA connectors on the hard drive are facing the same corner of the drive bay

that has the 2.5in cutout in the door. The label on the hard drive should face the

front of the SATA docking station.

3. Connect the included USB cable or eSATA cable from the hard drive docking station

to an available USB or eSATA port on the computer system. The computer can be ON

or OFF.

NOTE: If using eSATA, please note that the eSATA port on the host computer

system must provide Port Multiplier support. If the eSATA port does not oer Port

Multiplier support, only one of the installed SATA drives will be accessible.

4. Press the power buttons on the top of the hard drive docking station for each of the

bays that contain a hard drive. The Power LED around the power buttons will light

up. The LCD display will also light up and display”PC Mode”. This indicates the unit

is in Docking Station mode.

5. To remove the hard drive, make sure it is currently not being accessed by the

computer and the Activity LED is not ashing, then unmount or uninstall the disk

drive from the operating system (see documentation for your operating system).

Press the appropriate power button to turn o the hard drive and wait for the drive

to power down. Press the drive ejection button on the top of the hard drive dock to

the release the drive, then pull the drive from the slot.

Instruction Manual 4

Hardware Installation (Duplicator)

1. Connect the external power adapter from the hard drive docking station to an AC

power outlet.

2. Insert 2.5”or 3.5”hard drive(s) into the top loading drive bay(s). The drive containing

the data to copy (Source) needs to be inserted into the“Source” bay (HDD4). Make

sure that the SATA connectors on the hard drives are facing the same corner of the

drive bay that has the 2.5in cutout in the door. The label on the hard drive should

face the front of the SATA docking station.

3. Press the power buttons on the top of the hard drive docking station for each of the

bays that contain a hard drive. The Power LED around the power buttons should

light up. The LCD display will also light up and display”PC Mode”.

4. Press the“ENT” button on the front panel of the unit. A message will appear

advising that this will change the unit to Duplicator Mode.

5. Press the“ENT” button again and a conrmation message will appear. Press the

“ENT”button again to switch to Duplicator Mode. Pressing “ESC”will cancel this

action.

6. The LCD display will now show Duplication mode.

7. Press the“ENT” or Up/Down buttons to access the menu options.

Driver Installation

No driver installation is required for the supported operating systems, as this hard

drive dock is natively supported, so the drivers are already installed.

Instruction Manual 5

How to Use

Menu Options

1. Copy HDD

Perform a 1:1 sector clone from the Source disk to the Destination disks. Each disk

sector on the Source disk will be copied, regardless if it contains data or not. If using

a Destination disk larger than the Source, any extra space will be untouched and left

unallocated.

2. Compare HDD

Compares the sectors on the Source disk to the Destination disk. Used to ensure

that the Copy operation was successful.

3. Rescan Bus

Rescans each hard drive bay to detect for new/swapped hard drives.

4. Source Size

Displays the total storage capacity of the Source disk.

Instruction Manual 6

5. Setup

5-1. Auto Compare

Automatically runs the Compare HDD function after copying. OFF by default.

5-2. Button Sound

Turn audio feedback (beeping) ON/OFF. OFF by default.

5-3. Device Info

Lists information about the Source/Destination disks.

6. PC Mode

Returns the Duplicator to Docking Station mode.

7. Advance Setup

7-1. Read Error Skip

Ignore any read errors (sector or block) detected during the copying process.

Normally, read errors result in cancellation of the copying process.

7-2. Quick Erase

Quickly erase all the data on the Source hard drive.

7-3. Secure Erase

Perform the Secure Erase command on any of the connected hard drives.

7-4. System Info

Lists the current rmware version.

Duplicator (Copy) Mode

Use the “UP”and “DOWN” buttons on the duplicator dock to select the Copy HDD

mode and press the “ENT”button to conrm the selection. The duplication will begin

immediately from the Source disk to all available Destination disks. The LCD screen will

display transfer rates, progress percentage, amount of data copied and a countdown

timer to an estimated time for completion.

NOTE: As the duplicator dock creates a 1:1 copy from the Source to the Destination,

the Destination disk(s) must be of equal or greater capacity than the Source disk.

The duplication can be paused at any time by accessing the menu and selecting the

Copy HDD option again. When prompted to conrm pausing the duplication, press

the “ENT”button. When paused, to resume the duplication, select the Copy HDD

option from the main menu.

Instruction Manual 7

Specications

Hard Drive Bays 4

Host Interface SuperSpeed USB 3.0

SATA revision 2.x

Chipset ID JMicron JMB394 + JMS539

External Connectors

1 x USB 3.0 type B female

1 x eSATA female*

1 x DIN (4-pin) Power female

LEDs 4 x Power/Activity

Fans 2 x 60mm

Insertion Rating 15,000 cycles per bay

Maximum Data Transfer Rate USB: 5 Gbps

eSATA: 3 Gbps

Duplication Rate Up to 72 MBps

Compatible Hard Drives 2.5in and 3.5in SATA revision 1/2/3 hard

drives

Power Adapter 12VDC, 6500mA

Operating Temperature 5°C ~ 80°C (41°F ~ 176°F)

Storage Temperature -40°C ~ 70°C (-40°F ~ 158°F)

Humidity 8% ~ 90% RH

Dimensions 170.0mm x 290.0mm x 83.0mm

Weight 1110g

Compatible Operating Systems

Windows 2000/XP/Server 2003/Vista/

Server 2008 R2/7 (32/-64-bit), Mac OS

X, Linux

*eSATA connection requires host computer with Port Multiplier support

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Estación de acoplamiento de StarTech.com

StarTech.com

StarTech.com DK30C2DPEP Manual de usuario

StarTech.com

StarTech.com 116N-USBC-DOCK Manual de usuario

StarTech.com

StarTech.com SDOCKU33EBV Manual de usuario

StarTech.com

StarTech.com Thunderbolt 3 TB3DKM2DPL Manual de usuario

StarTech.com

StarTech.com UNIDOCK3U Manual de usuario

StarTech.com

StarTech.com TB3DKM2HD Manual de usuario

StarTech.com

StarTech.com USBVGADOCK2 Manual de usuario

StarTech.com

StarTech.com InfoSafe SATDOCKU2GB Manual de usuario

StarTech.com

StarTech.com SDOCK4U33E Manual de usuario

StarTech.com

StarTech.com SATADOCKU2 Manual de usuario

StarTech.com

StarTech.com DK30ADD Manual de usuario

StarTech.com

StarTech.com SATDOCK4U2E Manual de usuario

StarTech.com

StarTech.com SATDOCK4U2E Manual de usuario

StarTech.com

StarTech.com 101N-USBC-DOCK Manual de usuario

StarTech.com

StarTech.com USB3DOCKHDPC Manual de usuario

StarTech.com

StarTech.com DK30BACDD Manual de usuario

StarTech.com

StarTech.com DKM31C3HVCPD Manual de usuario

StarTech.com

StarTech.com SATADOCK525 Manual del sistema

StarTech.com

StarTech.com SDOCK2U33EB Manual de usuario

StarTech.com

StarTech.com DK30CHHPD Manual de usuario

StarTech.com

StarTech.com USB3SDOCKDD Manual de usuario

StarTech.com

StarTech.com SDOCK1EU3P Manual de usuario

StarTech.com

StarTech.com SATADOCK22UE Manual de usuario

StarTech.com

StarTech.com SATADOCKU2 Manual de usuario

Manuales populares de Estación de acoplamiento de otras marcas

Sony

Sony Dream Machine XDR-DS12iP Manual de usuario

Acer

Acer USB Type-C Dock II Manual de usuario

ATEN

ATEN UC-2000 Manual de usuario

Xcellon

Xcellon HDD-202 Manual de usuario

Dok

Dok CR09 Manual de usuario

Philips

Philips BTM630/12 Manual de usuario

IOGear

IOGear Travel Pro GUD3C09 Manual de usuario

RKI

RKI SDM-E2 Manual de usuario

iHome

iHome iP15 Manual de usuario

VITURE ONE

VITURE ONE MOBILE DOCK Manual de usuario

Lindy

Lindy 42984 Manual de usuario

CipherLab

CipherLab 8001 Manual de usuario

Pyle

Pyle PIPDSP2 Manual de usuario

Avol

Avol AS2350 Manual de usuario

Datalogic

Datalogic JoyaTouch Manual de usuario

Philips

Philips DC190/79 Manual de usuario

Targus

Targus DOCK315EUZ Manual de usuario

Akasa

Akasa DuoDockX3 AK-DK08U3-BK Manual de usuario
