Please read these instructions before operating the product.

SLL360

360° Self-Levelling Multi-Line Laser

77-137

GB

D

F

I

E

PT

NL

DK

SE

FIN

NO

PL

GR

CZ

RU

HU

SK

SI

BG

RO

EE

LV

LT

HR

TR

277-137

A

2

4

3

1

6

5

7

(-)

(+)

8

(-)

(+)

(-)

(+) B

5

9

77-137

Notes

10 77-137

Contents

• Safety

• Product Overview

• Applications

• Keypad, Modes, and LED

• Batteries and Power

• Set Up

• Operation

• Accuracy Check and Calibration

• Specications

User Safety

WARNING:

• Carefully read the Safety Instructions and

Product Manual before using this product.

The person responsible for the instrument must

ensure that all users understand and adhere to

these instructions.

CAUTION:

• While the laser tool is in operation, be careful

not to expose your eyes to the emitting laser

beam (red light source). Exposure to a laser

beam for an extended time may be hazardous

to your eyes.

CAUTION:

• Glasses may be supplied in some of the laser

tool kits. These are NOT certied safety glasses.

These glasses are ONLY used to enhance the

visibility of the beam in brighter environments or

at greater distances from laser source.

Retain all sections of the manual for future reference.

WARNING:

• The following labels are placed on your laser tool

to inform of the laser class for your convenience

and safety. (Text has been translated here for

your convenience)

IEC/ EN 60825-1

LASER RADIATION - DO NOT

STARE INTO THE BEAM

CLASS 1 LASER PRODUCT

Max Output ≤ 1 mW @ 630 - 670 nm

Product Overview

Figure A - Laser Tool

1. Window for Front Horizontal and Vertical Beams

2. Pendulum / Transport Lock

3. Windows for 360° Horizontal Coverage Beams

4. Keypad

5. Battery Cover

6. 5/8 - 11 Threaded Mount

7. 1/4 - 20 Threaded Mount

Figure B - Laser Tool Battery Location

5. Battery Cover

8. Batteries - 3 x “AA” (Included)

Figure C - Pendulum / Transport Lock Positions

Figure D - Keypad

Figure E - Laser Modes

Figure F - Manual Mode

Figure G - Level Beam Accuracy

Figure H - Level Beam Accuracy (Without Vertical Beam)

Figure J- Horizontal Beam Accuracy
