ST X-NUCLEO-LED61A1 Manual de usuario

Quick Start Guide

DC-DC LED driver expansion board based on LED6001 for STM32 Nucleo

(X-NUCLEO-LED61A1)

Version 1.0 (December 15, 2015)

Overview 2

Introduction to the STM32 Open Development Environment

STM32 Nucleo DC-DC LED driver expansion board

•Hardware overview

•Software overview

Documents & Related Resources

Setup & Demo Examples

Overview 3

Introduction to the STM32 Open Development Environment

STM32 Nucleo DC-DC LED driver expansion board

•Hardware overview

•Software overview

Documents & Related Resources

Setup & Demo Examples

STM32 Open Development Environment

Fast, affordable Prototyping and Development 4

•The STM32 Open Development Environment (ODE) consists of a set of stackable boards

and a modular open SW environment designed around the STM32 microcontroller family.

www.st.com/stm32ode

Compatibility with multiple Development environments

STM32Cube development software STM32 Nucleo expansion boards

STM32 Nucleo development boards STM32Cube

expansion software

Power supply

through USB or

external source

Integrated debugging

and programming

ST-LINK probe

STM32 microcontroller

Complete product range

from ultra-low power to high-performance

ST morpho extension header

STM32 Nucleo

Development Boards (NUCLEO)

•A comprehensive range of affordable development boards for all the STM32

microcontroller series, with unlimited unified expansion capabilities and integrated

debugger/programmer functionality.

www.st.com/stm32nucleo

Arduino™ UNO R3 extension headers

Move/ActuatePower InteractConnect

Sense

STM32 Nucleo

Expansion Boards (X-NUCLEO)

•Boards with additional functionality that can be plugged directly on top of the STM32

Nucleo development board directly or stacked on another expansion board.

DIL24 support for

new devices

Motion MEMS sensors

Environmental sensors

www.st.com/x-nucleo

Example of STM32 expansion board (X-NUCLEO-IKS01A1)

STM32 Open Development Environment

Software components

•STM32Cube software (CUBE) -A set

of free tools and embedded software bricks

to enable fast and easy development on

the STM32, including a Hardware

Abstraction Layer and middleware bricks.

•STM32Cube expansion software

(X-CUBE) -Expansion software provided

free for use with the STM32 Nucleo

expansion board and fully compatible with

the STM32Cube software framework. It

provides abstracted access to expansion

board functionality through high-level APIs

and sample applications.

www.st.com/stm32cube

•Compatibility with multiple Development Environments - The STM32 Open Development

Environment is compatible with a number of IDEs including IAR EWARM, Keil MDK, and GCC-based

environments. Users can choose from three IDEs from leading vendors, which are free of charge and

deployed in close cooperation with ST. These include Eclipse-based IDEs such as Ac6 System

Workbench for STM32 and the MDK-ARM environment.

Tools&IDEs

Applicationexamples

(e.g.basedon ST OpenSoftwareX)

Hardware

SampleapplicationsApplications

IAREWARM,KeilMDK-ARM,GCC-basedIDEs

(e.g.Ac6SystemWorkbenchforSTM32)

STM32CubeHardwareAbstractionLayer(HAL)

STM32Cube

middleware

Upperlevel middleware

(e.g.ST OpenSoftwareX)

Middleware

Hardware

Abstraction

STM32Cubeexpansionmiddleware

STM32 Nucleo expansion boards (X-NUCLEO)

STM32 Nucleo developer boards

OPEN LICENSE MODELS: STM32Cube software and sample applications are covered by a mix of fully open source BSD license and ST

licenses with very permissive terms.

STM32 Open Development Environment

Building block approach 8

The building blocks Your need Our answer

Move /

Actuate

Connect

Power

Sense

Process

Inertial modules, magnetometer

Proximity, microphone

Pressure, temperature, humidity

Bluetooth LE, Sub-GHz radio

NFC, Wi-Fi, GNSS

Energy management & battery

General-purpose microcontrollers

Stepper motor driver

DC & BLDC motor driver

Audio amplifier

COLLECT

TRANSMIT

ACCESS

CREATE

POWER

PROCESS

Software

Secure microcontrollers

Touch controller

Operation Amplifier

Accelerometer, gyroscope

Translate

Industrial input / output

www.st.com/stm32ode

Overview 9

Introduction to the STM32 Open Development Environment

STM32 Nucleo DC-DC LED driver expansion board

•Hardware overview

•Software overview

Documents & Related Resources

Setup & Demo Examples

DC-DC LED driver expansion board

Hardware Overview 10

X-NUCLEO-LED61A1 Hardware description

•The X-NUCLEO-LED61A1 is aDC-DC LED driver

expansion board based on LED6001 for STM32 Nucleo.

The expansion board is equipped with a single-channel,

constant-current LED driver for boost or SEPIC topologies

Main Features

•Wide DC input voltage range: 8 V –24 V

•Single channel LED Driver, 350 mA constant current

•PWM and analog brightness control with the STM32

Nucleo board

•Selectable boost or SEPIC converter topology

•Up to 92% efficiency (boost converter)

•Compatible with Arduino™ UNO R3 connectors

•Compatible with STM32 Nucleo boards

Order Code: X-NUCLEO-LED61A1

LED6001 STL8N10LF3 STL3N10F7

Arduino UNO R3 connector

Key Products on board

LED6001: PWM dimmable single channel LED driver with

integrated boost controller

STL8N10LF3: N-channel 100 V, 25mΩ typ., 7.8 A, STripFETTM III

Power MOSFET in a PowerFLATTM 5x6 package

STL3N10F7: N-channel 100 V, 0.062 Ohm typ., 4 A STripFET F7

Power MOSFET in a PowerFLAT 2x2 package

Latest info available at

X-NUCLEO-LED61A1
