ST B-WB1M-WPAN1 Manual de usuario
Introduction
The B-WB1M-WPAN1 STM32WB connectivity expansion board provides an affordable and flexible way for users to try out new
concepts and build prototypes with the STM32WB series STM32WB1MMC microcontroller module.
The B-WB1M-WPAN1 product requires a separate probe for programming and debugging. The STLINK-V3SET debugger can
be connected through a MIPI10/STDC14 cable.
The B-WB1M-WPAN1 STM32WB connectivity expansion board is provided with a USB Type-C® connector (for power only) on
an add-on STMod+ adapter board.
The B-WB1M-WPAN1 product is provided with the STM32WB comprehensive software HAL library and various packaged
software examples available with the STM32CubeWB MCU Package.
Figure 1. B-WB1M-WPAN1 main board (top view)
Figure 2. B-WB1M-WPAN1 main board (bottom view)
Pictures are not contractual.
STM32WB connectivity expansion board
UM3200
User manual
UM3200 - Rev 1 - November 2023
For further information contact your local STMicroelectronics sales office. www.st.com
1 Features
• STM32WB connectivity expansion board embedding an STM32WB1MMC module including:
–Ultra‑low‑power STM32WB15CCY dual‑core Arm® Cortex®‑M4/M0+, Bluetooth® Low Energy 5.4,
AES‑256, featuring 320 Kbytes of flash memory and 48 Kbytes of SRAM in a WLCSP49 package
– RF transceiver multistandard radio Bluetooth® Low Energy, compliant with Bluetooth® specification
5.4 with 1 and 2 Mbit/s transfer rates
• 256‑Kbit serial I2C bus EEPROM
• MEMS sensors from STMicroelectronics:
– Integrated high-accuracy temperature sensor
– 3D accelerometer and 3D gyroscope
• User LED
• User and reset push-buttons
• Board connectors:
–MIPI® debug
– STMod+
–USB Type-C® for power only on add‑on STMod+ adapter board
• Flexible power supply options: external sources, or USB VBUS from the add‑on board
• Comprehensive free software libraries and examples available with the STM32CubeWB MCU Package
• Support of a wide choice of Integrated Development Environments (IDEs) including IAR Embedded
Workbench®, MDK-ARM, and STM32CubeIDE
Note: Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
UM3200
Features
UM3200 - Rev 1 page 2/38
2 Ordering information
To order the B-WB1M-WPAN1 STM32WB connectivity expansion board, refer to Table 1. Additional information is
available from the datasheet and reference manual of the target microcontroller.
Table 1. List of available products
Order code Board reference Target STM32
B-WB1M-WPAN1 • MB1868(1)
• MB1880(2) STM32WB1MMCH6TR
1. Expansion board
2. STMod+ adapter board
2.1 Codification
The meaning of the codification is explained in Table 2.
Table 2. Codification explanation
B-XXYY-ZZZZT Description Example: B-WB1M-WPAN1
B Expansion board Connectivity expansion board
XX MCU series in STM32 32-bit Arm Cortex MCUs STM32WB series
YY MCU product line in the series STM32WB1M line
ZZZZ Wireless network Wireless personal area network based
on Bluetooth® Low Energy 5.4 certified
T Sequential number First WPAN connectivity expansion
board
UM3200
Ordering information
UM3200 - Rev 1 page 3/38
3 Development environment
The B-WB1M-WPAN1 STM32WB connectivity expansion board runs with the STM32WB1MMC module including
the STM32WB15CCY 32-bit microcontroller based on the dual‑core Arm® Cortex®‑M4/M0+ processor.
Note: Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
3.1 System requirements
•Multi‑OS support: Windows® 10, Linux® 64-bit, or macOS®
•USB Type-A or USB Type-C® to USB Type-C® cable
Note: macOS® is a trademark of Apple Inc., registered in the U.S. and other countries and regions.
Linux® is a registered trademark of Linus Torvalds.
Windows is a trademark of the Microsoft group of companies.
3.2 Development toolchains
•IAR Systems® - IAR Embedded Workbench®(1)
• Keil® - MDK-ARM(1)
• STMicroelectronics - STM32CubeIDE
1. On Windows® only.
3.3 Demonstration software
The demonstration software, included in the STM32Cube MCU Package corresponding to the on-board
microcontroller, is preloaded in the STM32 flash memory for easy demonstration of the device peripherals in
standalone mode. The latest versions of the demonstration source code and associated documentation can be
downloaded from www.st.com.
UM3200
Development environment
UM3200 - Rev 1 page 4/38
4 Conventions
Table 3 provides the conventions used for the ON and OFF settings in the present document.
Table 3. ON/OFF convention
Convention Definition
Jumper JPx ON Jumper fitted
Jumper JPx OFF Jumper not fitted
Jumper JPx [1-2] Jumper fitted between Pin 1 and Pin 2
Solder bridge SBx ON SBx connections closed by 0 Ω resistor
Solder bridge SBx OFF SBx connections left open
Resistor Rx ON Resistor soldered
Resistor Rx OFF Resistor not soldered
Capacitor Cx ON Capacitor soldered
Capacitor Cx OFF Capacitor not soldered
UM3200
Conventions
UM3200 - Rev 1 page 5/38
5 Quick start
The B-WB1M-WPAN1 STM32WB connectivity expansion board is an easy-to-use and low-cost development kit
used to evaluate and start development quickly with an STM32WB1MMC module. Before installing and using the
product, accept the evaluation product license agreement from the www.st.com/epla webpage. For more
information on the B-WB1M-WPAN1 STM32WB connectivity expansion board and demonstration software, visit
www.st.com.
5.1 Getting started
Follow the sequence below to configure the B-WB1M-WPAN1 STM32WB connectivity expansion board and
launch the demonstration application (refer to Figure 4 for component location):
1. Check jumper positions on board, JP1 (IDD) ON. The default jumper position on the board is explained in
Table 4.
2. Choose one of the several possibilities to supply the B-WB1M-WPAN1 STM32WB connectivity expansion
board (MB1868) with power. For example, connect a supply cable to CN4 to supply the board with an
external 5 V supply source (E5V).
3. Press on the reset button (B2) of the B-WB1M-WPAN1 STM32WB connectivity expansion board (MB1868)
and the demonstration starts.
4. This demonstration application software is available on the www.st.com website.
Table 4. Jumper default configuration
Jumper Definition Position(1) Comment
JP1 IDD ON For STM32WB1MMC current
measurements (RF part)
1. The default jumper state is shown in bold.
UM3200
Quick start
UM3200 - Rev 1 page 6/38
6 Hardware layout and configuration
6.1 Connectivity expansion board (MB1868)
The CEB (connectivity expansion board) MB1868 is designed around the STM32WB1MMC module, which
includes an STM32WB15CCY microcontroller. Figure 3 shows the connections between the STM32WB1MMC
module and its peripherals, push-buttons, LEDs, USB, and sensors. Figure 4 and Figure 5 show the location of
these features on the CEB MB1868. The mechanical dimensions of the board are shown in Figure 6.
Figure 3. MB1868 hardware block diagram
DT59181V1
I2C
SPI
VCP SWD
GPIO
STM32WB15CCY
XTAL 32
MHz
XTAL 32
kHz SMPS
IPD Antenna
matching
Internal
antenna
STM32WB1MMC
(CN1)
(U4)
DEBUG
(CN3)
STMod+ connector
Temperature
sensor
(U1)
Accelerometer
Gyroscope
(U2)
EEPROM
(U3)
User
button
(B1)
User
blue LED
(LD1)
Reset
button
5V_PWR
green LED
(B2)
(LD2)
E5V
E3V3
(CN4) (CN5)
UM3200
Hardware layout and configuration
UM3200 - Rev 1 page 7/38
6.1.1 MB1868 layout
Figure 4. MB1868 top layout
DT59182V1
Product sticker
STM32WB1MMC (U4)
SMA (CN2)
USER button (B1)
RESET button (B2)
USER LED (LD1)
5V_PWR LED (LD2)
IDD jumper for current
measurement (JP1)
STDC14 programming and
debug connector (CN3)
E3V3 connector supply (CN5)
E5V connector supply (CN4)
Temperature sensor (U1)
3D accelerometer
and 3D gyroscope (U2)
I2C EEPROM (U3)
STMod+
connector
(CN1)
Figure 5. MB1868 bottom layout
DT59183V1
STMod+
connector
(CN1)
Board sticker
UM3200
Connectivity expansion board (MB1868)
UM3200 - Rev 1 page 8/38
6.1.2 MB1868 mechanical drawing
Figure 6. MB1868 mechanical drawing (in millimeters)
UM3200
Connectivity expansion board (MB1868)
UM3200 - Rev 1 page 9/38
6.2 STMod+ adapter board (MB1880)
The MB1880 STMod+ adapter board is a very simple board that allows the MB1868 connectivity expansion board
to become a host with the add-on STMod+ connectors (female).
Figure 7 shows the basic hardware block diagram. Figure 1 and Figure 2 show the location of the main
components of the MB1880 board. The mechanical dimensions of the board are shown in Figure 10.
Figure 7. MB1880 basic hardware block diagram
DT59131V1
JP1
STMod+
connector
(CN2)
STMod+
connector
(CN3)
USB C
(CN1)
JP2
6.2.1 MB1880 layout
Figure 8. MB1880 top layout
DT59132V1
STMod+
connector
(CN2)
Jumper
(JP1)
5V test point
(TP2)
GND test point
(TP1)
Jumper
(JP2)
STMod+
connector
(CN3)
ESDA7P60-1U1M
ESD protection
(U1)
USB Type-C®
connector
(CN1)
UM3200
STMod+ adapter board (MB1880)
UM3200 - Rev 1 page 10/38
