Specialized FireBalls Comp Manual de usuario

The battery pack of your FireBalls

Comp has been shipped dis-

charged. It needs to be completely

charged before your first ride.

Charge the battery continuously for

14 hours before your first ride. After

14 hours, you may remove the bat-

tery from the charger (even if all 5

LEDs on the fuel gauge are not lit).

After your first ride, allow the light

to remain on until the battery is

completely discharged and the light

automatically turns itself off. This will

help the fuel gauge to "learn" the

battery’s capacity. The fuel gauge

will become more accurate after 2

or 3 complete charge/discharge

cycles. Please see the sections titled

"Battery Pack" and "Charging the

Battery" for more information.

FireBalls®Comp Lighting System.

Congratulations on your purchase! You are now the owner of one of the world’s

finest bicycle lighting systems. Your Specialized FireBalls Comp has been designed

to provide the best combination of brightness, run-time, durability, ease of use

and installation.

WARNING: BICYCLING IN THE DARK IS AN INHERENTLY DANGEROUS ACTIVITY. No lighting system will guard

you against inattentive motorists and other nighttime hazards. Always ride with extreme caution. Carry extra bulbs

and some type of auxiliary light with you. Wear reflective clothing. Make sure your bicycle has the legally required

reflectors and your helmet, ankles (or shoes) packs, panniers have reflectors or reflective patches. Specialized

lights and lighting systems are not intended to replace your C.P.S.C. approved reflectors. Never remove the original

reflectors from your bicycle. Always disconnect the battery pack and allow your light to cool before replacing it

in the storage case.

The FireBalls Comp features:

• Retina Optical System – Allows

Independent Adjustment of High

And Low Beams

• Wireless Handlebar Transmitter

• Ultra High-Capacity Nickel Metal

Hydride Battery with Integrated

Fuel Gauge.

• 4 Output settings (6, 12, 20, 32Watt)

• Smart Battery Charger

• Broken Filament Sensing

• Die-cast A1 Premium

Aluminum Housing

• Universal Handlebar Mounts

• Universal Helmet Mount

• Battery Backpack

• 20 Watt Halogen High Beam

• 12 Watt Halogen Low Beam

• Tail-light Port

• Water Resistant Housing

• 1 Year Warranty

What is included in your

FireBalls Comp package:

1. Lamp Housing (1)

2. Electronic Housing (1)

3. Battery Pack (1)

4. Helmet Mount (1)

5. Battery Backpack (1)

6. Handlebar Mounts (2)

7. Transmitter (1)

8. Battery Charger (1)

9. Wall Transformer (1)

10. Long Velcro™Strap (1)

11. Short Velcro Straps (2)

12. Cable Ties (2)

11 12

MOUNTING THE FIREBALLS COMP

Your FireBalls Comp is designed to be

mounted on your handlebars or on

your helmet. Use a 3mm hex-wrench

and the screws provided to install either

the handlebar mounts or the helmet

mount to the lamp housing.

HANDLEBAR – Attach your FireBalls

Comp securely to the handlebars with

the quick-release handlebar mounts.

The lamp housing should straddle the

stem and may be mounted above or

below the handlebars. Always use

BOTH quick-release mounts. Slide the battery pack and electronics housing into one of

your water-bottle cages. Use the long Velcro strap to secure the battery into the cage

by wrapping it completely around the frame tube Secure the power cable to your frame

with the two short Velcro straps. Be sure to leave enough slack in the power cable so

that it will not hinder the rotation of your handlebars. Plug in the electrical connector

between the battery and lamp housing. Make sure the power cable cannot become

entangled in any of the moving components of your bicycle.

HELMET – Attach your FireBalls Comp securely to your helmet by looping the Velcro

strap through the vents. The angle of the helmet mount is adjustable. FireBalls Comp

can be positioned on top or towards the front of your helmet. Secure the power cable

to the back of your helmet with the two short Velcro straps. Drop the battery pack into

the backpack. Be sure the fuel gauge lights can be seen through the slot in the back-

pack. Put on the backpack and make sure all of the straps are secure and cannot

become entangled in any of the moving components of your bicycle. For the most com-

fortable fit use both the waist strap and the sternum strap.

BATTERY PACK Your FireBalls Comp battery pack features an integrated fuel

gauge that monitors the condition of the battery during use, while

charging and in storage. Because it is located inside the battery

housing, the FireBalls Fuel gauge will always give an accurate

representation of the battery capacity. The five LED indicators show

battery capacity in 20% increments. The lights will illuminate auto-

matically when the light is in use and when the battery is charg-

ing. To check the capacity when the battery is

in storage simply press the button on the bat-

tery. When the battery capacity is below 10%

the first LED will blink. This is an indication that

the pack is very low and should be charged as soon as possible.

Use extreme care to avoid a short-circuit across the battery

contacts. Never allow any metal objects to touch the contacts on the

battery. In the event of a short-circuit, an Internal fuse will be

tripped to avoid damage to the battery. The fuse will reset itself

automatically when the short circuit is removed.

CHARGING THE BATTERY

The FireBalls Comp features the most advanced charging system ever offered in a

bicycle lighting system. The charge cycle is controlled by the fuel gauge located within

the battery pack. The system is designed to allow the battery to be left on the charger

indefinitely, without the risk of overcharging the battery. When the battery is fully

charged, the fuel gauge will signal the charger to stop charging. In order to counteract

the battery’s normal self-discharge characteristics during storage, the fuel gauge will

occasionally turn on the charger to top-off the battery.

To charge your battery pack, plug in the wire from the transformer into the charger

base, unscrew the battery from the electronics housing and drop it onto of the charger.

Be sure the alignment pin of the charger base mates with the hole on the battery pack.

The charger will automatically begin the charge cycle.

There is an LED Charge Indicator located on the front of the battery charger. While

the battery is charging the Charge Indicator will be illuminated. After the charge cycle

is complete the Charge Indicator will turn off and all 5 LEDs on the battery fuel gauge

will be illuminated. It is normal for the Charge Indicator to flash occasionally after the

charge cycle is complete.

There is a temperature sensor inside the battery

pack that will disable the charger if the battery is hot.

If you place the battery on the charge when it is hot (e.g.

immediately after use or if it has been stored inside your

car on a hot day), the charger will wait for the battery

to cool and then automatically resume charging.

The Nickel Metal Hydride batteries in your FireBalls

Comp need to be "exercised" in order to achieve their

maximum capacity. Your burn times may be shorter than

normal for the first few rides. After your batteries are

charged/discharged about 5 times they will reach their

full capacity.

The time to charge a fully discharged battery is

approximately 12 hours. Your actual charge time will

vary according to the condition of your battery.

OPERATION OF YOUR FIREBALLS COMP:

The FireBalls Comp light can be operated by two different methods, the Wireless

Transmitter (See section titled "Wireless Transmitter" for more information) or direct

operation of the buttons on the electronic housing. Each method offers a very simple

two-button operation: one button turning the light on and increases brightness and the

other dims the light and turns it off. The two methods may be used interchangeably.

Note:

The buttons on the Wireless Transmitter are not marked UP or DOWN.

You can choose which is up and which is down depending upon which side of the

handlebar you choose to mount them on. For more information see the section titled

"Wireless Transmitter."

To turn the light on, press the UP button (marked "+" on the electronics housing

button) once. The light will enter the 6-watt "economy mode". If you press the UP

button again it will enter 12-watt mode, the third push of the UP button will turn

on the 20-watt bulb and the fourth push will turn on both bulbs.

To dim and turn the light off: Press the DOWN button (marked "-" on the electronics

housing button). Each time you press the DOWN button the light will select the next

lower output setting. The lamp will turn off if the DOWN button is pushed while in

6-watt mode.

Note:

If you are using the wireless transmitter, you must hold the DOWN

button for three seconds to turn the lamp off.

When the battery is consumed to approximately 10% of the total capacity the

FireBalls Comp will begin to cut-back the light output in order to extend its run time.

For example, if you are in 32 watt mode the light will automatically switch to 20 watt

mode, then to 12 watt mode. As the capacity is reduced further the light will switch to

6 watt economy mode. Typically there will be about 15-20 minutes of burn-time

remaining once the light has entered economy mode. The light will turn itself off when

the battery capacity is fully consumed in order to avoid over-discharging the battery.

In the event one of the bulbs of your FireBalls Comp light breaks, the other bulb will

automatically light.

WIRELESS TRANSMITTER

The Wireless Transmitter provided with your FireBalls Comp allows you to operate

your light without removing your hand from the grips. The transmitter sends a unique

digital code to the light. To eliminate interference with other FireBalls lights, there are

128 different transmitter codes.

The buttons of your transmitter are backlit.

When you push one of the buttons, the back-

light will turn on for 10 minutes. With every

subsequent push of the button the 10-minute

timer will reset itself.

The transmitter should be mounted as

close to the grip as possible. You may

mount the transmitter on either the right

or left side of your bars depending upon

your personal preference.

Your FireBalls will need to be trained

to listen to your specific transmitter code. In order to train your light, press and hold

the transmitter button you would like to turn the lights on and press and hold the UP

(marked "+") button on the electronics housing. When one of the lamps flashes quickly,

release both buttons. Next, press and hold the transmitter button you would like to turn

the lights off and press and hold the DOWN (marked "-") button on the electronics

housing. When one of the lamps flashes quickly, release both buttons. Your FireBalls

are now trained to your transmitter code.

To replace the batteries in your transmitter, remove the transmitter from your handle-

bar and unscrew the phillips screw that secures the battery cover. Remove the old

batteries and replace them with 2 new CR2032 lithium button cells. Be sure to note

the polarity of the cells during installation.

RETINA OPTICAL SYSTEM

The Retina Optical System is designed to

allow you to aim both beams of your

FireBalls Comp independently. Each beam

has 20 degrees of angular adjustment. To

adjust, loosen the thumbscrew on the back

of the lamp by rotating it counterclockwise

one-half turn. Aim the lamp by moving the

thumbscrew side-to-side or up-and-down.

When you are satisfied with the direction

you have aimed the beam, tighten the

thumbscrew to lock the lamp in place by rotating the screw clockwise.

Use caution not to over-tighten the thumbscrew.

ELECTRONICS HOUSING

The electronics housing for your FireBalls Comp contains the electronics that control

your light. There are no user-serviceable parts inside. Please do not open the electronics

housing, as this will void your warranty.

There is a port at the top of the electronics housing that will supply power to

Specialized taillights. Use only taillights that are designed specifically to work with the

FireBalls headlights. Never attempt to plug any other connector into this port.

TRANSPORTING

The safest way to transport your FireBalls Comp is to place them inside their steel car-

rying case. To prevent the light from being accidentally turned-on, always disconnect

the battery from the electronics housing before transporting. Always allow the lamp

housing to cool to room temperature before placing the light in the carrying case.

REPLACING THE BULBS

Always remove the battery pack from the electronics housing before servicing your

FireBalls Comp. Replacement bulbs are available from your local Specialized dealer.

To remove one of the bulbs, unscrew the bezel on the front of the lamp housing by

rotating it counterclockwise. Carefully pry the bulb out of the housing with the tip of a

small screwdriver. Replace the blown bulb with one of identical size, voltage and

wattage. Insert the new bulb. Be careful to align the pins on the bulb with the holes

inside the lamp housing. Re-install the bezel by rotating it clockwise.

TROUBLESHOOTING

Light doesn’t turn on.

• Make sure your battery is fully charged. Push the button on the battery pack

and note how many of the lights on the fuel gauge illuminate. If no LEDs turn on

you need to charge the battery.

• Check the batteries in your handlebar transmitter. Does the backlight in the trans-

mitter turn on when you push one of the buttons? If not, replace the batteries.

• Is your FireBalls Comp programmed to your transmitter code? Follow the instructions

under the section titled "Wireless Transmitter"

• Is one or both of your bulbs blown? Replace the questionable bulb with

a known-good one.

Battery won’t charge

• Is your battery pack hot? Allow the pack to cool. The charger will automatically

begin the charge process as soon as the pack cools.

• Is the transformer plugged into the wall and into the charger base?

• Is there power at the wall outlet into which the transformer is plugged?

IMPORTANT!

• Pay attention to traffic and road conditions at all times. Your first obligation is

to be attentive and to ride safely.

• During use, the housing will become quite hot. Use caution not to touch the lamp

housing while the lamp is on.

• Never put your FireBalls light away hot. Always allow the lamp housing to cool

before placing it in the storage case.

• In cold weather (below 50ªF or 10ªC) the capacity of your battery pack may be

reduced. Plan your ride accordingly.

• Do not submerge your FireBalls under water. It is designed to be water-resistant,

not waterproof.

• Do not drop your FireBalls light. Dropping it can cause it to fail prematurely.

• Do not disassemble your FireBalls lighting system.

• Keep the lights and all of their components tightly attached, and check them

regularly. If any of the components loosen, it could become tangled in your spokes

and cause an accident.

• See your authorized Specialized dealer if you have any trouble installing or

maintaining your lights.

• Clean the unit with a mild detergent and a soft dry cloth. Never use any kind

of solvent or alcohol.

• The FireBalls Comp is intended for use on bicycles only and should not be

used on any motorized vehicle.

• Never look directly into the light beam.

SPECIFICATIONS

Battery Voltage 14.4 Volts DC (nominal)

Battery Capacity: 59 Watt/Hours

Charge time after full discharge ≈12 hours

Idle current <18mA

Voltage Regulation Method: Pulse-Width-Modulation (PWM)

Battery Fuse 3.5A self-resetting

Low Beam Lamp 12 watt halogen

High Beam Lamp 20 watt halogen

Transmitter Batteries (2) CR2032 Lithium

Transmitter Battery life Approx. 100hrs

Transmitter Frequency 315 Mhz USA, Canada, South America

433.92 Mhz Europe, Asia

Ambient Operating Temperature 40°F to 104°F (4°C to 40°C)

Specifications subject to change without notice.

The following replacement parts are available from your Specialized dealer:

Description Part#

NiMH Battery 499-3250

Handlebar Mounts 499-3252

12 Watt Halogen Bulb 499-3202

20 Watt halogen Bulb 499-3201

Wireless Transmitter 499-3204

Transmitter Battery 481-3004

ONE YEAR LIMITED WARRANTY

Specialized Bicycle Components Inc. warrants the Original Purchaser of this product

that the product is free from defects of material and workmanship under normal use

and service for a period of one (1) year from the date of the original purchase. If with-

in one (1) year from the date of that original purchase, this product is found to be

defective in material or workmanship under normal use or service, Specialized Bicycle

Components Inc. will, at its sole option, repair or replace the product without charge;

provided that the Original Purchaser returns the product, securely packaged, postage

prepaid to: Specialized Bicycle Components Inc., 15130 Concord Circle, Morgan Hill,

CA. 95037, Attn: FireBalls Warranty. Be sure to include a letter indicating the specific

reasons for returning the product and proof of date of purchase.

THIS WARRANTY DOES NOT APPLY TO, AND IS VOID AS TO, DEFECTS OR PHYSI-

CAL DAMAGE RESULTING FROM ABUSE, NEGLECT, IMPROPER REPAIR, IMPROPER

FIT, ALTERATIONS, MODIFICATIONS OR USE CONTRARY TO THAT INTENDED BY

THE MANUFACTURER. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW,

ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR

USE OR PURPOSE IS LIMITED IN DURATION OF THIS LIMITED WARRANTY. SPECIAL-

IZED BICYCLE COMPONENTS, INC. SHALL NOT BE LIABLE FOR ANY ACCIDENTAL

OR CONSEQUENTIAL DAMAGES ARISING FROM ANY BREACH OF ANY

EXPRESSED OR IMPLIED WARRANTY ON THIS PRODUCT. THIS WARRANTY IS EXCLU-

SIVE AND IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, AND ALL

OTHER REMEDIES, GUARANTIES OR LIABILITIES ARISING BY LAW OR OTHERWISE.

NOTE:

This warranty does not pertain to bulbs or batteries.

No person or representative is authorized to assume any liability on behalf of

Specialized Bicycle components, Inc. in connection with the sale of this product. Some

states do not allow the exclusion or limitation of incidental or consequential damages

or limitations on how long an implied warranty lasts, so the above limitation or exclu-

sion may not apply to you. This warranty gives you specific legal rights, and you may

also have other rights which vary from state to state.

FireBalls is a registered trademark of Specialized Bicycle Components Inc.

Tabla de contenidos

Otros manuales de Accesorios para bicicletas de Specialized

Specialized

Specialized Transition Carbon-All Models Manual

Specialized

Specialized Stumpjumper Adjustable Dropout Manual de usuario

Specialized

Specialized Speedzone Sport CR2032 Manual de usuario

Specialized

Specialized Turbo Elite Manual de usuario

Specialized

Specialized TURBO SPORT CYCLOCOMPUTER 2004 Manual de usuario

Specialized

Specialized SPEEDZONE SPORT DOUBLE WIRELESS Manual de usuario

Specialized

Specialized Speedzone Comp CR2302 Manual de usuario

Specialized

Specialized SpeedZone P-Brain Manual de usuario

Specialized

Specialized HPRT-0027 Manual de usuario

Specialized

Specialized SpeedZone Elite Manual de usuario

Specialized

Specialized Command Post 34.9 Manual de usuario

Specialized

Specialized Globe Throttle Manual de usuario

Specialized

Specialized SPEEDZONE SPORT CYCLOCOMPUTER Manual de usuario

Specialized

Specialized AFR Rear Shock EPA Manual de usuario

Specialized

Specialized Speedzone Pro Cyclocomputer Manual de usuario

Specialized

Specialized Elite CylcoComputer Manual de usuario

Specialized

Specialized Command Post Adjustable Height Seat Post Manual de usuario

Specialized

Specialized SpeedZone Manual de usuario

Specialized

Specialized SpeedZone Sport Bicycle Manual de usuario

Specialized

Specialized Snell Helmet Manual de usuario

Specialized

Specialized Transition Transition Bicycles Manual de usuario

Specialized

Specialized Roval Rapide Wheelset None Manual de usuario

Specialized

Specialized Turbo Comp Manual de usuario

Specialized

Specialized S-WORKS CARBON HARDTAIL Manual

Manuales populares de Accesorios para bicicletas de otras marcas

Sigma

Sigma BC 16.16 Manual de usuario

Playcore

Playcore Dero Setbacks Manual de usuario

VDO Cyclecomputing

VDO Cyclecomputing x3dw Manual de usuario

Cateye

Cateye RAPID X2 Manual de usuario

buratti meccanica

buratti meccanica Clorofilla Trail Manual de usuario

Shimano

Shimano SG-8R20 Instrucciones de funcionamiento

BOB

BOB YAK Manual de usuario

APLIC

APLIC 303303/20190717TW012 Manual de usuario

SRAM

SRAM AXS BlipBox Manual de usuario

Garmin

Garmin EDGE 500 Manual de usuario

Shimano

Shimano FD-RX810 Manual de usuario

Cateye

Cateye V2C - Manual de instrucciones

KMART

KMART 43115907 Manual de usuario

SIGMA SPORT

SIGMA SPORT Buster 2000 Manual de usuario

NVO Components

NVO Components STEM Manual de usuario

DAXYS

DAXYS BP188 Manual de usuario

XLC

XLC BV-W17 Manual de usuario

Deda Elementi

Deda Elementi SUPERBOX Manual de usuario
