Sony Handycam HDR-SR1 Manual de usuario

Read this first

On this “First Step Guide”

Software's on-line help

Picture Motion Browser features

Chapter 1: Setting up for the first time

Preparation flow

Step 1: Installing software

Step 2: Connecting with a USB cable

Chapter 2: Creating a disc with One Touch

Types of discs you can use

Saving videos and still images on a disc with One Touch (One Touch Disc Burn)

Chapter 3: Importing/viewing videos and still images on a computer

Importing entire videos and still images on a computer (Easy PC Back-up)

Importing selected videos and still images on a computer (Media File Import)

Importing images from the DVD drive/Memory Stick slot of a computer

Viewing videos and still images imported to a computer

Chapter 4: Editing the imported videos and still images

Editing videos

Editing still images

Chapter 5: Creating and copying a disc

Creating a disc with HD (High Definition) picture quality

Creating a disc with SD (Standard Definition) picture quality

Creating a disc with saved images from the Playlist on your camcorder (Playlist Disc Creation)

Copying a disc

Types of discs you can use

Chapter 6: Viewing an AVCHD format disc on a computer

Playing an AVCHD format disc with Player for AVCHD

Chapter 7: Exporting videos to your camcorder

Exporting AVCHD 1080i format videos saved on a computer to your camcorder

Chapter 8: Manipulating videos and still images

Saving videos after converting format

Manipulating still images

Troubleshooting

Symptoms

Cause and/or corrective actions

Additional information

System requirements

Trademarks and regulations

On this “First Step Guide”

This “First Step Guide” describes the connections and settings required to use your camcorder with

a computer, and the basic operation of the software on the CD-ROM.

The CD-ROM contains the Picture Motion Browser application for the Windows OS.

You cannot use Picture Motion Browser on a Macintosh computer.

Notes

zThe screenshots in this “First Step Guide” are from Windows XP. The screens may vary depending on the operating

system of the computer.

zBoth a 12 cm and an 8 cm DVDs are described as a “disc” in this “First Step Guide.”

Read this first

Top Next

Software's on-line help

The help provides detailed operating instructions for Picture Motion Browser.

Select [Help] in the [Help] menu of the software to start up the on-line help.

Read this first

Previous Top Next

Picture Motion Browser features

Picture Motion Browser is a set of Windows applications with the following features.

If you double-click the [ ] (Picture Motion Browser) icon on the desktop, [Picture Motion Browser]

starts up.

Notes

zThe picture may not play back smoothly, depending on specifications of your computer. For details about the

recommended specifications, see “System requirements.”

zYou cannot use Picture Motion Browser on a Macintosh computer.

Creating a disc using the One Touch Disc Burn function <Details>

You can save videos and still images recorded on the hard disk of your camcorder on a disc by

pressing the DISC BURN button on your camcorder (One Touch Disc Burn function).

It is an simple operation to save videos and images to a disc.

Videos recorded in HD (High Definition) format are written on a disc with the same picture quality.

Importing videos and still images recorded on the hard disk of your camcorder to a

computer <Details>

You can import videos and still images recorded on the hard disk of your camcorder with a simple

operation.

Videos recorded in HD (High Definition) format are imported to the computer with their original

picture quality.

Viewing videos and still images imported to a computer <Details>

You can manage videos and still images recorded on the hard disk of your camcorder by date, and

select videos or still images you want to view as thumbnails.

These thumbnails can be enlarged and played in a slide show.

Creating a disc with edited videos and still images

You can edit videos and still images imported to a computer. <Details>

You can create a disc with selected videos and still images. <Details>

Creating a disc with videos included in a Playlist on your camcorder <Details>

You can save videos included in a Playlist on your camcorder on a disc with a simple operation.

Copying a disc Video Disc Copier <Details>

You can copy a disc you created as it is.

Playing a disc in AVCHD format Player for AVCHD <Details>

You can play back the disc you just made in AVCHD format on a DVD drive of your computer.

Exporting HD (High Definition) videos from your computer to your camcorder <Details>

You can export HD (High Definition) videos that have been imported to a computer from your

camcorder, back to your camcorder.

Read this first

Previous Top

Preparation flow

This gives you an overview of the preparation necessary for the first time you use your camcorder with

a Windows computer.

1If you have not installed the supplied software, install it on your computer.

See “Step 1: Installing software.” <Details>

If you already installed the software according to the Operating Guide supplied with your camcorder,

you do not need to install the software again.

2Make your computer recognize your camcorder by making a first USB connection.

See “Step 2: Connecting with a USB cable.” <Details>

From hereon when you actually use your camcorder with your computer.

Chapter 1: Setting up for the first time

Top Next

Step 1: Installing software

You need to install the software to your Windows computer to enjoy editing your recorded videos

and still images. The installation is required only for the first time.

1Confirm that your camcorder is not connected to the computer.

2Turn on the computer.

Log on as Administrators for installation.

Close all applications running on the computer before installing the software.

3Place the CD-ROM in the disc drive of your computer.

The installation screen appears.

If the screen does not appear

1Click [Start], then click [My Computer]. (For Windows 2000, double-click [My Computer]. )

2Double-click [SONYPICTUTIL (E:)] (disc drive)*.

* Drive names (such as (E:)) may vary depending on the computer.

4Click [Install].

5Select the language for the application to be installed, then click [Next].

Chapter 1: Setting up for the first time

6Click [Next].

7Read [License Agreement], select [I accept the terms of the license agreement] when

you agree, then click [Next].

8Select your camcorder video system, then click [Next].

9Select where to save the software, then click [Next].

10 Click [Install] on the [Ready to Install the Program] screen.

The installation of Picture Motion Browser starts.

11 The following installation screens may be displayed, depending on your operating

environment. In this case, follow the instructions on the screen to install the

software.

zSonic UDF Reader --- Software required to recognize AVCHD format discs

zWindows Media Format 9 Series Runtime (Windows 2000 only) --- Software required to create

DVD video discs

zMicrosoft .NET Framework 1.1 --- Software required to create AVCHD format discs

zMicrosoft DirectX 9.0c --- Software required for handling video

12 Make sure [Yes, I want to restart my computer now.] is selected, then click [Finish].

The computer restarts automatically.

The short-cut icons, such as [ ] (Picture Motion Browser), appear on the desktop.

13 Remove the CD-ROM from the disc drive of your computer.

zFor the information about Picture Motion Browser, visit the following URL:

http://www.sony.net/support-disoft/

Previous Top Next

Step 2: Connecting with a USB cable

The following section describes how to connect your camcorder to a computer using a USB cable and

make the computer recognize your camcorder.

Connection image (USB cable and USB jack)

Before performing the following procedure, make sure you have installed Picture Motion Browser on

your computer. <Details>

Note that if you do not turn on the power and make the connections in the order described in the

following steps, your computer may not recognize your camcorder.

Note

zWhen connecting your camcorder to a computer, make sure you insert the connector in the correct direction. Do not insert

the connector forcibly as it may damage the cable or your camcorder.

Tip

zYour camcorder is compatible with Hi-Speed USB (USB 2.0). You can transfer data at a faster rate using a computer

compatible with Hi-Speed USB (USB 2.0). When you connect a USB interface not compatible with Hi-Speed USB (USB

2.0), the data transfer ratio will be that of USB 1.1 (USB Full-Speed).

1Turn on the computer.

If any software starts on the computer automatically, close it.

2Connect your camcorder to a power source, and turn on your camcorder.

Use the AC Adaptor as the power source.

For operating the POWER switch, refer to the Operating Guide supplied with your camcorder.

3To use still images saved in a “Memory Stick Duo”, insert the “Memory Stick Duo”

into your camcorder.

4Connect the USB cable to the USB jack on the camcorder firmly.

For the location of the USB jack, refer to the Operating Guide supplied with your camcorder.

5Connect the other end of the USB cable to the USB port on your computer.

The [USB SELECT] screen is displayed on the LCD screen of your camcorder.

Tip

zWhen the screen is not displayed, select the item from the menu. For selecting the menu, refer to the operating

instructions supplied with your camcorder.

6To use videos and still images recorded on the hard disk of your camcorder, select [

COMPUTER

]

Chapter 1: Setting up for the first time
