Sony RCC1000 Manual de usuario

RCC1000

Sony Pan/Tilt/Zoom Camera Controller

User Manual

______________________________________________________________________________

RCC1000

user manual | 2

This controller is designed for Sony pan/tilt/zoom cameras and supports VISCA

protocol. It has all the functions of the Sony PTZ camera handheld remote controller

and adds a touch sensitive joystick control. In addition to the joystick and keyboard, the

controller has an LCD screen for displaying commands and the camera's working

status.

The contents of this manual may be updated periodically without notification.

Controller Features

Supports VISCA protocol

Set and call presets of Sony PTZ cameras

Communication modes: RS232, RS422, RS485

All camera settings/functions can be set conveniently through function keys

Control up to seven Sony PTZ cameras with one controller in a daisy-chain

configuration

Touch sensitive joystick control of pan, tilt and zoom speed

Selectable speed range of pan/tilt control (low, medium or high)

Supports password lock of camera function keys

Key-press sound ('beep') on/off function

Precautions:

The LCD is fragile. Avoid long exposure under strong light.

The controller should be used within the specified temperature and humidity

ranges (see chart below).

Follow the connection method defined in this manual.

Although the controller is of durable metal construction, care must be taken to

avoid dropping the unit as internal parts could be damaged. Product should be

packed in original or adequate packaging whenever transported.

Specifications:

Power Supply 12V +/-10%

Operating Temperature -10°C~55°C

Operating Humidity ⩽90% RH

Communication RS232, RS422, RS485

Baud Rate 2400bps, 4800bps, 9600bps, 19200bps

Ports RS232 and RS422 port

Display Blue LCD screen

Size 4200mm (l) x 260mm (w) x 170mm (h)

Included Accessories:

Power Supply 12 VDC AC Adapter

Cable 8 Foot VISCA EVI CONTROL CABLE (9pin D-Sub

to 8 pin Mini Din)

Instruction Manual

______________________________________________________________________________

RCC1000

user manual | 3

Keyboard

Camera function keys

[Auto] Enable auto focus

[Manual] Enable manual focus

[Preset] Camera preset setup (See 'Setting Up and Recalling Camera

Preset Positions' for more details.)

[Data Screen] Displays on-screen camera menu. At this time, the on-screen

menu cannot be controlled with the RCC1000. These functions

can be accessed/controlled using the [Menu] key on the

controller. See 'Camera Functions' for more details.

[Back Light] Turn on/off back light compensation

[Call] Recall camera preset (See 'Setting Up and Recalling Camera

Preset Positions' for more details.)

[Home] Move camera to home position

[P-T Reset] Reset the camera

[Menu] Display camera functions menu (See 'Camera Functions' for

more details.)

[Power] Press and hold to power on/off camera

[SetID] Camera ID setup (See 'Assigning Camera IDs' for more details.)

[Cam] Select the camera's ID. Used when controlling more than one

camera. (See 'Selecting a Camera ID' for more details.)

______________________________________________________________________________

RCC1000

user manual | 4

Controller function keys

[Esc] Back to previous menu

[Setup] Press and hold to enter controller settings menu information (See

'Controller Settings' for more details.)

[Search] Display controller information (See 'Controller Settings Display' for

more details.)

Number keys

[CLR] Delete all information keyed in

[0] - [9] Number keys: 0,1,2,3,4,5,6,7,8,9

[Enter] Confirm and save all information keyed in

PTZ function keys

[Near] In manual focus mode, focus near

[Far] In manual focus mode, focus far

[Tele] Zoom-in, increase magnification (to zoom-in faster, use joystick and

turn clockwise)

[Wide] Zoom-out, decrease magnification (to zoom-out faster, use joystick

and turn counter-clockwise)

[Open] In manual aperture mode, enlarge camera aperture

[Close] In manual aperture mode, reduce camera aperture

[LR-STD] Change direction of controller; camera moves in same direction as

joystick

[LR-REV] Change direction of controller; camera moves in opposite direction as

joystick

LCD Screen

All operations of keys and joystick will display on LCD screen when pressed. LCD

screen will go into power saving mode (brightness level is reduced) if there is no user

activity for more than 30 seconds.

______________________________________________________________________________

RCC1000

user manual | 5

Joystick

Rear panel

1 RS-422 Control command output terminal:

connector 1-4 Connect to RS422 terminal of

video conference camera

2 Ground Control line ground terminal Connect to ground RS422

terminal of camera

3 TXD Send command indicator Flickering green light indicates

unit is sending commands

4 RXD Receive command indicator Flickering green light indicates

unit is receiving commands

5 PW Power input indicator Continuous red light indicates

unit is powered on

6 DC-12V Power input port DC 12V input port

______________________________________________________________________________

RCC1000

user manual | 6

Controller Settings

To view/modify the controller settings, press and hold down [Setup]. You will be

prompted to enter the controller password. Enter '8888' and press [Enter].

To scroll through the controller settings item, move the joystick left/right. Press [Enter] to

view/modify a particular setting.

1 EDIT PW - To change the controller password:

You will be prompted to enter the old controller password. Enter the old password

(factory default is '8888') and press [Enter]. You will then be prompted to enter the new

password. Enter the new password and press [Enter]. Re-enter the new password again

when prompted and press [Enter].

2 FACTORY - To revert controller to default factory settings:

You will be asked to verify that you want to revert to default factory settings. Press

[Enter] to proceed or [Esc] to abort.

3 SET SPEED - To set the pan/tilt speed range:

Move joystick left or right to select HIGH or LOW or MEDIUM. Press [Enter] to select a

speed range. Press [Esc] to save selection and return to controller settings menu.

4 SOUND - To turn the key-press sound ('beep') on/off:

Move joystick left or right to select SOUND OFF or SOUND ON. Press [Enter] to make

selection.

5 KB ID: To assign an ID to the controller:

Enter a number [0] - [15] and press [Enter].

6 LOCK SET - To lock camera function keys on controller:

Move joystick left or right to select LOCK OFF or LOCK ON. Select LOCK ON and

press [Enter]. You will be prompted to enter a Lock Password (LOCK PW). Enter a 4-

digit password and press [Enter].

______________________________________________________________________________

RCC1000

user manual | 7

Controller Settings Display

Press [Search] to display the following information about the controller (move joystick

up/down to scroll through dislpay):

MODEL: SONY

SN: RCC1000 serial number (8-digit)

KB ID: Programmable keyboard ID (2-digit)

SOUND: Key-press sound status (ON/OFF)

LOCK: Keyboard lock status (ON/OFF)

______________________________________________________________________________

RCC1000

user manual | 8

Assigning Camera IDs

Assigning a Camera ID for single camera use:

Connect camera to controller, camera ID will be set as '1' automatically after powering

on both camera and controller.

Assigning a Camera ID for multiple cameras:

Connect first camera to controller and subsequent cameras in a daisy chain

configuration. Press and hold [SetID] for 2 seconds. Camera IDs will be set in sequence

as '1', '2', '3', etc.

Selecting a Camera ID

When controlling multiple cameras, to select the camera you would like to control, press

[Cam], enter camera ID number, press [Enter]

For example, to select Camera 2: Press [Cam], Press [2], Press [Enter]

Setting Up and Recalling Camera Preset Positions

Setting Up a Preset Position

Select camera ID and press [Preset]. Adjust the camera to desired position and zoom,

key in a number for this preset (e.g., 1, 2, 3 ...) and press [Enter]. Repeat steps to setup

other presets or press [Esc] to exit.

Recalling a Preset Position

Select camera ID and press [Call]. Key in the preset number and press [Enter]. Repeat

steps to recall other presets or press [Esc] to exit.

______________________________________________________________________________

RCC1000

user manual | 9

Camera Functions

To access camera functions, press and hold [Menu]. You will be prompted to enter the

Camera Functions Menu password: '6666'

To scroll through the menu items, move the joystick up/down.

To select a menu item option, move the joystick left/right.

When finished making selections, there are two options for saving the settings:

1. Press [Enter] to save current settings until it is modified by user (settings will be

saved even if controller is powered off).

2. Press [Esc] to save current settings only until controller is powered off.

The following camera functions can be operated by the controller. Refer to your camera

manual for more information on each function.

DZOOM

Digital Zoom: Move joystick left or right to select OFF or ON

DZOOMMODE

Digital Zoom Mode: Move joystick left or right to select COMBINE or SEPARATE

AF SENSITIVITY

Auto Focus Sensitivity: Move joystick left or right to select NORMAL or LOW

AF MODE

Auto Focus Mode: Move joystick left or right to select NORMAL AF or INTERVAL AF or

ZOOM TRIGGER

WB MODE

White Balance Mode: Move joystick left or right to select AUTO or INDOOR or

OUTDOOR or ONE PUSH or ATW or MANUAL

AE MODE

Automatic Exposure Mode: Move joystick left or right to select AUTO or MANUAL or

SHUTTER PRIORITY or IRIS PRIORITY or BRIGHT

SHUTTER MODE

Shutter Mode: Move joystick left or right to select AUTO or MANUAL

EXP COMP MODE

Exposure Compensation: Move joystick left or right to select OFF or ON

SPOT AE MODE

Spot Exposure Mode: Move joystick left or right to select OFF or ON

______________________________________________________________________________

RCC1000

user manual | 10

LR REV MODE

Mirror Image: Move joystick left or right to select OFF or ON

FREEZE MODE

Freeze: Move joystick left or right to select OFF or ON

PIC EFFECT

Picture Effect: Move joystick left or right to select OFF or NEGATIVE ART or B&W

ICR MODE

IR Cut Removable Mode: Move joystick left or right to select OFF or ON

AUTO ICR MODE

Auto IR Cut Removable Mode: Move joystick left or right to select OFF or ON

Note: If a camera feature is not available for the connected camera, the LCD screen will

display 'RE DATA UNKNOWN'.

Tabla de contenidos

Otros manuales de Controladores de Sony

Sony

Sony UPA-PC700 Manual de usuario

Sony

Sony JumboTron Manual de usuario

Sony

Sony JumboTron JTC-C200 Manual de usuario

Sony

Sony JunboTron JME-SA200 Manual de usuario

Sony

Sony DSBK-2020 Manual de usuario

Sony

Sony RM-AV2100B Operating Instructions (primary... Manual de usuario

Sony

Sony PlayStation DualSense Edge Manual de usuario

Sony

Sony HomeShare RMN-U1 Manual de usuario

Sony

Sony HKSP-R80 Manual de usuario

Sony

Sony UPA-PC500 Manual de usuario

Sony

Sony DualSense CFI-ZCT1W Manual de usuario

Sony

Sony PlayStation DualSense CFI-ZCT1G Manual de usuario

Sony

Sony MJ100 Manual de usuario

Sony

Sony WX-C570 Manual de usuario

Sony

Sony PlayStation Portable Manual de instalación y funcionamiento

Sony

Sony RM-E300 Manual de usuario

Sony

Sony PlayStation DualSense Edge CFI-ZCP1 Manual de usuario

Sony

Sony PS4 DUALSHOCK 4 Manual de usuario

Sony

Sony M-Crew PCLK-MN10A Guía de configuración

Sony

Sony BKSI-2440 Series Manual de usuario

Sony

Sony HKDV-900 Manual de usuario

Sony

Sony D-LIGHT SYNC Manual de usuario

Sony

Sony HKSP-300 Manual de usuario

Sony

Sony CSP-5000E Manual de usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
