Sony BKDM-7041 Manual de usuario

Digital Sketch Effects Board

BKDM-7041

User’s Guide

Software Version 1.00 and Later

Digital Multi Effects

DME-3000/7000

1st Edition [English]

Serial No. 10001 and Higher

For the customers in Europe

WARNING

This is a Class A product. In a domestic

environment, this product may cause radio

interference in which case the user may be

required to take adequate measures.

Pour les utilisateurs en Europe

AVERTISSEMENT

Il s’agit d’un produit de Classe A. Dans un

environnement domestique, cet appareil peut

provoquer des interférences radio, dans ce cas

l’utilisateur peut être amené à prendre des

mesures appropriées.

Für Kunden in Europa

Warnung

Dies ist eine Einrichtung, welche die Funk-

Entstörung nach Klasse A besitzt. Diese

Einrichtung kann im Wohnbereich

Funkstörungen verursachen; in diesem Fall

kann vom Betreiber verlangt werden,

angemessene Maßnahmen durchzuführen und

dafür aufzukommen.

Für Kunden in Deutschland

Dieses Gerät ist nur für den Gebrauch in

Gewerbe und Leichtindustrie bestimmt. Es

entspricht der Klasse A, es erfüllt nicht die

Grenzwerte der Klasse B. In Deutschland muß

der Erwerber eine spezielle Betriebserlaubnis

bei der zuständigen Außenstelle des BAPT

beantragen, um dieses Gerät betreiben zu

dürfen.

Precautions

If this unit is installed incorrectly, personal

injury or damage to peripheral items may occur

due to fire, shock, or other accidental circum-

stances. To avoid such risks, installation

should be performed by trained service

technicians.

To technician installing unit

Please refer to the Maintenance Manual

supplied with the DME-3000/7000 Digital Multi

Effects for installation instructions.

NOTICE FOR USERS

This manual or the software described herein,

in whole or in part, may not be reproduced,

translated or reduced to any machine readable

from without prior written approval from Sony

Corporation.

SONY CORPORATION PROVIDES NO

WARRANTY WITH REGARD THIS MANUAL,

THE SOFTWARE OR OTHER INFORMATION

CONTAINED HEREIN AND HEREBY EX-

PRESSLY DISCLAIMS ANY IMPLIED WAR-

RANTIES OF MERCHANTABILITY OR

FITNESS FOR ANY PARTICULAR PURPOSE

WITH REGARD TO THIS MANUAL, THE

SOFTWARE OR SUCH OTHER INFORMA-

TION. IN NO EVENT SHALL SONY CORPO-

RATION BE LIABLE FOR ANY INCIDENTAL,

CONSEQUENTIAL OR SPECIAL DAMAGES,

WHETHER BASED ON TORT, CONTRACT,

OR OTHERWISE, ARISING OUT OF OR IN

CONNECTION WITH THIS MANUAL, THE

SOFTWARE OR OTHER INFORMATION

CONTAINED HEREIN OR THE USE

THEREOF.

Sony Corporation reserves the right to make

any modification to this manual or the informa-

tion contained herein at any time without

notice.

The software described herein may also be

governed by the terms of a separate user

license agreement.

Contents

Digital Sketch Effects ...................................................................2

Overview ................................................................................2

BEVELED EDGE Settings – 18 ............................................3

SKETCH Settings – 46...........................................................5

COLOR GRABBER Settings – 78.......................................10

Digital Sketch EffectsDigital Sketch Effects

Overview

The BKDM-7041 consists of an option board and software which

enable the use of the so-called Digital SKETCH™ Effects,

including the BEVELED EDGE and SKETCH effects.

You can use this option not only with the DME-7000 but also with

the DME-3000.

Software versions

To use the BKDM-7041 requires the following software versions

to be running:

DME-7000: software version 1.00 or later

DME-3000: software version 1.50 or later

Effects provided Mounting the BKDM-7041 in a DME-3000/7000 allows you to

use the following extra functions:

BEVELED EDGE: provides a beveled edge to an image.

SKETCH: provides a range of effects based on the outline of the

image, and giving impressions of drawing or relief.

COLOR GRABBER: allows you to extract a color from an input

image for use in a matte.

About this User’s Guide

This manual describes how to carry out Digital Sketch Effects

from the control panel (BKDM-3010). You can keep this manual

together with the User’s Guide for the operation software control

(BZDM-3020/7020) in the ring binder supplied.

BEVELED EDGE Settings – 18

This gives an image a beveled edge.

LIGHT MATTE

In the BKGD & EDGE menu, select F8 (BEVELED EDGE) to

display the BEVELED EDGE menu.

18.1

EDGE

SOURCE

BEVELLED

EDGE PATTERN EDGE

MODE SOFT

BEVELED EDGE menu soft key indications

The following are some of the operations carried out in this menu.

Applying a beveled edge effect – F1 (BEVELED EDGE)

and F2 (PATTERN)

Use the following procedure.

1Press F1 (BEVELED EDGE), turning it on.

2Press F2 (PATTERN), to select the edge shape.

Pressing this button cycles through the patterns, in the order

four corners, lower right, lower left, upper left, upper right.

You can also select the required pattern by clicking on it.

3Press F3 (EDGE MODE) to select one of the following.

LIGHT: Vary the intensity of the edge.

MATTE: Apply a color to the edge.

For more details, see the section “Selecting the border color

or edge intensity” on the next page.

(Continued)

Digital Sketch Effects

4Adjust the “Width” parameters.

• Left knob (“H”): width of left and right beveled edges (0 to

100%)

• Center knob (“V”): width of top and bottom beveled edges

(0 to 100%)

• Right knob (“All”): width of all beveled edges (***)

(The “All” setting is reflected in the separate horizontal

and vertical settings.)

Making the boundaries of the edges soft – F6 (SOFT)

Use the following procedure.

1Press F6 (SOFT), turning it on.

2Adjust the “Softness” parameters.

• Left knob (“Innr”): degree of softness of the inside of the

edges (0 to 100%)

• Center knob (“Bund”): degree of softness of the boundary

between two edges (0 to 100%)

Selecting the border color or edge intensity – F8 (EDGE

SOURCE)

Use the following procedure.

1Press F8 (EDGE SOURCE).

The EDGE SOURCE menu appears.

EDGE

MODE HUE

ROT

FLAT

COLOR

EDGE SOURCE menu soft key indications (in “MATTE” mode)

2Press F1 (EDGE MODE), to select “MATTE” or “LIGHT”.

3When you selected “MATTE”, for a single hue press F2

(FLAT COLOR), or for a progressively changing hue press F3

(HUE ROT), turning it on.

4Adjust the parameters for the edges.

“MATTE” parameters

• Left knob (“Lum”): luminance (0 to 100%)

• Center knob (“Sat”): saturation (0 to 100%)

When you selected “FLAT COLOR”:

• Right knob (“Hue”): hue (0 to 359.99 degrees)

When you selected “HUE ROT”:

• Right knob (“Sped”): change in hue for each frame (–12 to

+12 degrees)

“LIGHT” parameters

• Left knob (“Lum”): luminance (0 to 100%)

SKETCH Settings – 46

This gives a range of effects based on the outline of the image, and

giving impressions of drawing or relief.

SKETCH DRAW 1 RELIEF

In the VIDEO MODIFY menu, select F6 (SKETCH) to display the

SKETCH menu.

The following are some of the operations carried out in this menu.

Digital Sketch Effects

Applying a sketch effect – F1 (SKETCH) to F3 (NEGA)

Use the following procedure.

1Press F1 (SKETCH), turning it on.

2Press F2 (MODE), to select “SKETCH”.

The soft key indications appear as follows.

SKETCH MODE NEGA

SKETCH menu soft key indications (“SKETCH” mode)

3Adjust the “Contour” parameters.

• Left knob (“Clip”): reference level for outline extraction (0

to 100%)

• Center knob (“Gain”): image gain for outline extraction

(–100 to +100%)

• Right knob (“Mix”): mix amount for input video (0 to

100%)

4Adjust the “Chroma gain” parameters.

• Left knob (“Gain”): chroma gain of sketch image (–100 to

+100%)

5To invert the black/white sense of the image used for outline

extraction, press F3 (NEGA).

When this is set to “ON” the outline is white, and when set to

“OFF” it is black.

Enhancing outlines – F1 (SKETCH) to F5 (EDGE HUE

ROT)

Use the following procedure.

1Press F1 (SKETCH), turning it on.

2Press F2 (MODE), to select “ENHANCE”.

The soft key indications appear as follows.

SKETCH NEGAMODE EDGE

FLAT EDGE

HUE ROT

SKETCH menu soft key indications (“ENHANCE” mode)

3Adjust the “Contour” parameters.

• Left knob (“Clip”): reference level for outline extraction (0

to 100%)

• Right knob (“Mix”): mix amount for input video (0 to

100%)

4Adjust the “Chroma gain” parameters.

• Left knob (“Gain”): chroma gain of sketch image (–100 to

+100%)

5To interchange the outline portions and non-outline portions,

press F3 (NEGA).

6To apply a single hue to the outline portions, press F4 (EDGE

FLAT), turning it on, and to use a progressively changing hue

press F5 (EDGE HUE ROT), turning it on, then adjust the

parameters.

For details of the parameter settings, see the section

“Selecting the border color or edge intensity” (page 4).

Applying a drawing effect – F1 (SKETCH) to F8

(CANVAS FRM MEM)

Use the following procedure.

1Press F1 (SKETCH), turning it on.

2Press F2 (MODE), to select “DRAW1” or “DRAW2”.

DRAW1: use a two-valued outline extraction signal.

DRAW2: use a continuous outline extraction signal.

The soft key indications appear as follows.

SKETCH NEGAMODE EDGE

FLAT EDGE

HUE ROT CANVAS

FLAT CANVAS

HUE ROT CANVAS

FRM MEM

SKETCH menu soft key indications (“DRAW1” or “DRAW2” mode)

(Continued)

Digital Sketch Effects

3Adjust the “Contour” parameters.

• Left knob (“Clip”): reference level for outline extraction (0

to 100%)

• Right knob (“Mix”): mix amount for input video (0 to

100%)

4To apply a color to the outline portions, press F4 (EDGE

FLAT) or F5 (EDGE HUE ROT), turning it on, then adjust the

parameters.

For details of the parameter settings, see the section

“Selecting the border color or edge intensity” (page 4).

5To apply a color or insert an image in the portions other than

the outlines, press one of F6 (CANVAS FLAT) to F8

(CANVAS FRM MEM), turning it on.

F6 (CANVAS FLAT): any single hue

F7 (CANVAS HUE ROT): a progressively changing hue

F8 (CANVAS FRM MEM): an image from frame memory

The color settings when you select F6 or F7 are the same as

for the outline portions. For details of the frame memory

selected by F8, refer to the BZDM-7020 User’s Guide, or the

supplement to the BZDM-3020.

6To interchange the outline portions and non-outline portions,

press F3 (NEGA).

Otros manuales de Unidad de control de Sony

Sony

Sony KCC-PCH Manual de usuario

Sony

Sony HSCU300RF Manual de usuario

Sony

Sony HSCU300RF Manual de usuario

Sony

Sony CCU-TX50 Manual de usuario

Sony

Sony CCU-TX50 Manual de usuario

Sony

Sony HDCU4300 Manual de usuario

Sony

Sony FCB-EX780S Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Sony

Sony BKM-15R Manual de usuario

Sony

Sony MSU-900 Manual de usuario

Sony

Sony HXCU-FB80 Manual de usuario

Sony

Sony HKCU-FP2 Manual de usuario

Sony

Sony CCP-6224 CCP-6324 MKS-8010B MKS-8011AMKS-8013A MKS-8014A MKS-8015A MKS-8017AMKS-8018A MKS-8019A MKS-8020A... Manual de usuario

Sony

Sony PVE-500 Manual de usuario

Sony

Sony HXCU-FB70 Manual de usuario

Sony

Sony IFU-WLM2 Manual de usuario

Sony

Sony CCU-700A Manual de usuario

Sony

Sony NXLK-IP45F Manual de usuario

Sony

Sony BVE-700 Manual de usuario

Sony

Sony HDCU2000 Manual de usuario

Sony

Sony HDCU1000 Manual de usuario

Sony

Sony HDCU3500 Manual de usuario

Sony

Sony FCB-ER8550 Manual de usuario

Sony

Sony BKM-34H Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario

Flyron

Flyron FN-BC04 Manual de usuario
